Summary of Contents for MBC SSC 06
- Page 1 INSTALLATION AND USER MANUAL...
-
Page 3: Explanation Of Symbols
THANK YOU FOR CHOOSING OUR EXPLANATION OF SYMBOLS: MBC MARINE PRODUCT! Professional installation is the key to efficient and safe operation ATTENTION!! of the equipment so please read the following installation and Ignoring this information may cause material damage operating instructions carefully before installing the unit. - Page 4 PART 1. SAFETY AND FIRE PROTECTION WARNINGS SAFETY INFORMATION: SAFETY WARNING: It is strictly forbidden to install the air condition- The manufacturer assumes no liability for damage ing unit in a place where it is possible for the to the device in the following cases: equipment to deliver carbon monoxide, harmful gas of the engine or any other toxic substance •...
- Page 5 PART 2. INSTALLATION GUIDE, INSTALLATION PLAN Before starting the installation it is important to plan the location of all the components of the system in advance, including: • marine a/c units and electric box, • air ducts and water pipes, •...
-
Page 6: Typical Installation
PLACEMENT OF THE AIR-CONDITIONING UNIT TYPICAL INSTALLATION: See the picture below for the installation of a self-contained air conditioner unit. Scoop Type Thru-Hull Ball Valve Sea Water Strainer Sea Wtaer pump A/C unit Return Air Grille Flexible Duct Duct Ring Transistion Box 10. -
Page 7: Installing The Display
INSTALLATION GUIDE INSTALLING THE DISPLAY Before installing the display observe the following guidelines: Install the control panel only on a surface that is situated higher than the center SAFETY WARNING! of the cabin and is protected from external and internal heat and light IDo not install the air conditioner in the bilge or engine com- sources. - Page 8 AIR SUPPLY OF THE UNIT The proper air supply of the unit is essential for the 3.0” [76mm] Minimum dearance in operation of the appliance so when installing the air front of condenser or /evapolator coils. inlet consider the air volume demand of the certain type and choose the size of the air inlet according TOP VIEW OF to the unit’s specifications!
- Page 9 SETTING THE FAN’S AIR OUTLET MOUNTING THE MARINE A/C UNIT Before installation (if necessary) set the fan in the direction which The basic package of the unit has 4 mounting brackets. During allows the most direct airflow through the air pipes. The air outlet installation - if possible - these should be positioned at equal dis- direction of the unit’s fan can be adjusted horizontally or verti- tance on the edge of the drop pan.
-
Page 10: Installing The Air Duct
INSTALLING THE AIR DUCT INSTALLING THE AIR OUTLET Unimpeded air flow is of paramount importance for the system For better efficiency place the unit’s air outlets as high as possi- to achieve its proper performance. Always use the right size and ble in the boat and also set the air vents slats up. -
Page 11: Safety Notice
THE WATER SYSTEM OF THE UNIT SAFETY NOTICE! If you do not have sufficient training to install the water system of the unit consult a qualified boat technician.. In saltwater environment - in case of longer stops - it is recommended to remove seawater from the system. Frost protection should be applied during fresh water use below -5C! Follow the PUMP HEAD... - Page 12 MAGNETIC DRIVEN PUMP PLACEMENT: The water-inlet must be positioned as deep as possible on the bottom of the boat. For better efficiency it is important to make sure to have the cold- The place of the centrifugal pump and the water strainer should est water possible in the condenser.
-
Page 13: Operation Control
PART 3. OPERATION - CONTROL • Place the water strainer so that it remains accessible during cleaning following the flow direction on the water strainer. Before starting to operate the device check the entire system • Connect the water pipe from the water inlet fitting to the water as follows: strainer, from the water strainer to the pump and then to the lower condenser input - marked with an arrow - of the marine a/c unit. - Page 14 PART 4. OPERATING INSTRUCTIONS Use the touch buttons on the keypad to set the operating mode, fan VENTILATOR (picture) speed, and desired temperature. The display also provides information Press the button to select automatic or manual fan mode. In on the operation of the equipment for each operating mode as follows: manual fan mode by pressing the fan button again will cause the fan speed to be higher first and lower afterwards and then 3 way valve is in operation...
- Page 15 PART 5. WIRING DIAGRAM (230V UNITS SSC SCP)
-
Page 16: Main Board
WIRING SHEME (SDC 12-24-48 V AC UNIT) Towards AC Unit SDC 12-24 MAIN BOARD A/C UNIT Return temp. sensor Energy Supply harness to battery 12V DC Brown wire pump + Blue wire pump - Battery 12V DC To pump... - Page 17 IN CASE OF SOFT STARTERS USAGE KM-6 START COMP-R CAPACITOR 110μF Soft Starter WIRING DIAGRAM RUNNING CAPACITOR YE/GN YE/GN COMPRESSOR HEAT HIGH PRESSURE SW. sensor(freeze TEMP) sensor(PIPE TEMP)
-
Page 21: Troubleshooting
PART 6. PART 7. TROUBLESHOOTING ERROR CODES TABLE The electronic control of the unit detects possible errors and categories ERROR ERROR DESCRIPTIONS THREATMENTS RESUMES them as follows: CODE Return air temperature sensor Turn off the The device shall restart • device failure - after trouble- •... -
Page 22: Warranty
TEIL 8. PART 9. WARRANTY TECHNICAL DATA TECHNICAL PARAMETERS NOTE! SSC 06 SSC 08 SSC 10 SSC 13 SSC 16 OF THE A/C UNIT Failure to properly ground and connect the unit Cooling capacity Btu/h 6000 8000 10000 13000 16000... -
Page 23: Ce Manufacturer's Declaration Of Conformity
CE MANUFACTURER’S DECLARATION OF CONFORMITY as the following: Name and address of manufacturer: PRODUCT FEATURES RESULT TESTING/EVALUATION METHOD MBC Marine Ltd., Vízesés st. 8/A Budapest, 1028 08 November 2019. Disturbance power emission Pass EN 55014-1 We hereby certify that the designing and manufacturing of...
