Step 3
Step 4
1.) Hang the Metal Plate (E) on the left
or right side of the cart. Lock the hook in
the middle of the Metal Plate (E) onto the
edge of the second Metal Bin (A).
(H)
Bolt
Qty: 12
Using a Phillips Screwdriver and Bolt (H), attach
Metal Bin (A) to the Frame.
Step 5
Place accessories (D, F & G) on
the cart.
R
Assembly Manual
3 - Tier Utility Cart
THIS ASSEMBLY MANUAL CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Made in China
Advertisement
Table of Contents
Summary of Contents for Designa CP-JJ-CWC-0010
- Page 1 Step 3 Bolt Assembly Manual Qty: 12 3 - Tier Utility Cart Using a Phillips Screwdriver and Bolt (H), attach Metal Bin (A) to the Frame. Step 4 Step 5 1.) Hang the Metal Plate (E) on the left Place accessories (D, F & G) on Made in China or right side of the cart.
- Page 2 Components Step 1 A..Metal Bin ..3 Wrench Caster With Lock Caster B..Upper Frame ..2 Qty: 1 Qty: 2 Qty: 2 C..Lower Frame ..2 D..Accessories ..2 E..Metal Plate ..1 F ..Accessories ..2 G..Accessories ..1 1.) Attach casters with lock (J) to the bottom of Lower Frame (C) using Wrench (I).
