Assembly Guide
Assembly Guide
IMPORTANT NOTICE:
IMPORTANT NOTICE:
Place all wooden parts on a clean and smooth surface such as a rug or
carpet to a void scratching the parts.
Check to be sure that you ha ve all parts and hardw are.
Remove all wrapping materials, including staples & packing straps before
you start to assemble.
Keep all hardw are parts and packaging out of reach of children.
Two person assembly recommended.
Archeus
Archeus
# Part
#
Part
A
Hole
cover
B
Short
Screw
20mm
C
Long
Screw
35mm
D
Allen
Wrench
E
Casters
F
Chair
Lift
Qty Image
Qty
# # Part
8
G
4
H
8
I
J
1
5
K
1
Part
Qty Image
Qty
Cylinder
1
1
Base
Arms
2
1
Back
Seat
1
1
Advertisement
Summary of Contents for AON Archeus AON001BK Series
- Page 1 Archeus Archeus Assembly Guide Assembly Guide # Part Part Qty Image Image # # Part Part Qty Image Image Hole Cylinder cover Short Base Screw 20mm Long Arms Screw 35mm Allen Back Wrench Casters Seat Chair Lift IMPORTANT NOTICE: IMPORTANT NOTICE: Place all wooden parts on a clean and smooth surface such as a rug or carpet to a void scratching the parts.
- Page 2 Step 1: Attach Casters (E) to Chair Base (H) by sliding them into the holes on the under side of the base. Step 2: Slide Cylinder (G) into hole on top of the Base(H). Cylinder clicks into place, no tools are required. Missing Parts? Assembly Thank you for your Questions?
- Page 3 Step 3: Place Chair Lift (F) on back of the Chair Seat (K), making sure to align the arrows on the Lift with the front of the Seat. Attach using 4 Small Screws (B). Front of Seat Back of Seat Front of Seat Back of Seat Step 4:...
- Page 4 Step 5: Use 2 Hole Covers (A) to cover screws. Step 6: Place assembled Arms and Seat onto the Cylinder and Base. Missing Parts? Assembly Thank you for your Questions? purchase! Happy with your chair? Call us at 1-866-816-3822 or email help@regencyof.com for Be sure to lea ve a review immediate assistance.
- Page 5 Step 7: Screw Back(J) onto Seat and Arms using 2 Long Screws one each side of the chair. NOTE: Assembly is easiest if the two bottom screws are inserted and screwed first, then the top two. Step 8: Cover Screw holes with Hole Covers(A). Missing Parts? Assembly Thank you for your Questions?
- Page 6 AoN Archeus Gaming Chair Features: Comfort & Support Comfort & Support Padded lumbar and headrest will keep you supported and comfortable. independent tilt independent tilt Control the seat back angle, forw ard tilt and infinite tilt positioning independently. tilt tension...
- Page 7 Items to Pair with Your Chair Double Screen Regency Center Dra wer Articulating Moni- tor Mount KBARTR LEDTL24/LEDTL60 Articulating Key- Regency 24 in. or 60 board Tray in. LED Task Light Thank you for your purchase... Please be sure to lea ve a review with your retailer! Satisfied with your purchase? Be sure to lea ve us a review.
