  • Page 1 Offroader Series Owner's Manual Suitable For: Rogue Dual Motor Rogue Dual Motor Max...
  • Page 2 Because to us at Voltrium, it's more than just a scooter. Hi, it's Jeff & Daniel here, the founders of Voltrium. We'll be popping up throughout this manual when we have a pro tip or valuable insider information to share about our scooters!

  • Page 3: Inside The Box

    INSIDE THE BOX Woohoo! You have received the scooter. Now let's unbox it and hit the paths. Voltrium Offroader(Max) Charger Seatpost & Saddle Emergency Toolkit Accessories (If optioned) Pro Tip: Use this checklist and tick the boxes as you remove the packaging to ensure you have received everything.
  • Page 4 GETTING STARTED Let's Unfold the scooter, it's as easy as 123 Remove the Rogue Offroader scooter from the box. Remove the Safety Pin from the folding mechanism Push the folding lever downwards towards the footboard, whilst pulling the steering column in the opposite direction to unfold the scooter.
  • Page 5 GETTING STARTED Now, we'll attach the handlebars Remove the 4 bolts holding the top half cap of the handlebar clamp. Once the half cap is removed, place handlebars onto the clamp, ensuring it is centred and oriented correctly. Once the alignment and positioning of the handlebars are correct, reinstall the top half cap with the 4 bolts to secure the bar.
  • Page 6 GETTING STARTED Attaching the Seat Offroader: Insert Seat pole into the socket Offroader Max: Insert the seat base through the slits of the foot board. Push forward until seat locks into the two side tabs. Fasten the rear knob to secure seat.
  • Page 7 GETTING STARTED Attaching the headlights Dual Motor: Attach Single headlight to the headlight bracket Dual Motor Max: Attach Dual headlight Assembly to headlight bracket Connect the headlight(s) to the scooter's wiring harness. There will be vacant plugs coloured red that will extend to the headlight(s) vicinity.
  • Page 8 GETTING STARTED Charging the scooter Locate the charge port on the side of the scooter. Open the cap. Locate the charger. Plug the 3 prong end into the scooter charge port. There will only be 1 orientation the plug will engage. When the RED and GREEN LED's are illuminated, the scooter is charging.

  • Page 9: Pre-Ride Checks

    PRE-RIDE CHECKS To ensure you get the most of your first ride, follow this checklist: Charge Scooter - Until the charger shuts off and illuminates green light Check Tyre Pressure - Ensure front and rear are at 40psi Ensure all nuts and bolts are tight on the scooter. Adjust steering column and or seat to a comfortable height Familiarise with the controls of the scooter.
  • Page 10 Check with your local State or Territory regarding specific laws governing the use of personal mobility devices (PMD). States and Territories have different laws in place that can prohibit the use of a Voltrium Scooter Do not ride in a manner that will endanger yourself and surroundings. High Performance riding should only be performed on private property Always ride whilst wearing safety gear.
  • Page 11 Front Brake Lever Rear Brake Lever Mulfi Function Display Ignition Key. Half Twist Throttle. Light & Horn Switch CONTROLS...

  • Page 12: Starting The Scooter

    STARTING THE SCOOTER Insert ignition key, Turn one click clockwise to enter accessory mode On the Multifunction display, press and hold the middle power button until the screen illuminates. The scooter will now move under it's own power, control your speed with the throttle.
  • Page 13 USING THE MFD Used to cycle through ECO and HIGH mode. Used to turn the scooter / MFD on and off. Used to cycle through information such as Odometer, Trip Meter and Error codes. Pro Tip: The cruise control will only engage when there is still some throttle applied by the rider.

  • Page 14: Maintenance

    Servicing is recommended to be carried out by specialists or trained technicians. Pro Tip: Voltrium stocks the full range of parts and we have the most common consumables ready on hand usually. You can contact your local scooter shop or visit the Voltrium online parts shop to order in spares.
  • Page 15 Modifications that obstruct or disrupt the normal repair / servicing process will incur extra labour cost during servicing / repair time. Pro Tip: Consult with Voltrium's support team if you are planning to modify the scooter in any shape or form to prevent your warranty from being void.
