- Page 1 LDS02 - LoRaWAN Door Sensor User Manual last modified by Xiaoling on 2023/01/03 15:57...
-
Page 2: Table Of Contents
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Table of Contents 1. Introduction ..................................4 1.1 What is LDS02 LoRaWAN Door Sensor ........................4 1.2 Features ..................................4 1.3 Applications ..................................5 1.4 Dimension ..................................5 1.5 Firmware Change log .............................. - Page 3 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Table of Contents: • 1. Introduction • 1.1 What is LDS02 LoRaWAN Door Sensor • 1.2 Features • 1.3 Applications • 1.4 Dimension • 1.5 Firmware Change log •...
-
Page 4: Introduction
~ 70,000 uplink packets. After battery running out, user can easily open the enclosure and replace with 2 common AAA batteries. The LDS02 will send periodically data every day as well as for each door open/close action. It also counts the door... -
Page 5: Applications
3. How to install LDS02 When install the LDS02 on wall. Please make sure install as below so the marks will close to each other when close the door. Open/Close threshold range: ~ 10mm ... -
Page 6: Operation Mode
4.1 How it works? The LDS02 is configured as LoRaWAN OTAA Class A mode by default. It has OTAA keys to join network. To connect a local LoRaWAN network, user just need to input the OTAA keys in the network server and power on LDS02. - Page 7 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual The LDS02 in installed on the door edge to detect the open / close event. And send the status to LoRaWAN server. The LDS02 will uplink two type of messages to the server.
- Page 8 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Page 8 / 21 - last modified by Xiaoling on 2023/01/03 15:57...
- Page 9 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Add APP KEY and DEV EUI Page 9 / 21 - last modified by Xiaoling on 2023/01/03 15:57...
-
Page 10: Uplink Payload
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Step 2: Power on LDS02 and it will auto join to the TTN V3 network. After join success, it will start to upload message to TTN V3 and user can see in the panel. -
Page 11: Type Code 0X01
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual RESET 0x04 Set confirmed mode 0x05 Clear Counting 0xA6 Enable/Disable Alarm 0xA7 Control ADR/DR 0xA8 Set Alarm Timeout 0xA9 Example Downlink payload setting in TTN V3: Type Code 0x01 If the payload=0100003C, means to control the LDS02’s Keep Alive interval to 0x00003C=60(S) -
Page 12: Type Code 0Xa8
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual 0xA7 00 : Equal to AT+DISALARM=0 Type Code 0xA8 Format: 0xA8 aa bb aa: 1: Enable ADR; 0: Disable ADR (Same as AT+CADR command) bb: set DR (Same as AT+CDATARATE ,only valid after ADR=0) - Page 13 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Page 13 / 21 - last modified by Xiaoling on 2023/01/03 15:57...
- Page 14 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Step 3: Create an account or log in Datacake. Step 4: Search LDS02 and add DevEUI. Page 14 / 21 - last modified by Xiaoling on 2023/01/03 15:57...
-
Page 15: Alarm Base On Timeout
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual 4.6 Alarm Base on Timeout LDS02 can monitor the timeout for a status change, this feature can be used to monitor some event such as open fridge too long etc. -
Page 16: Battery & How To Replace
5. Battery & How to replace 5.1 Battery Type and replace LDS02 is equipped with 2 x AAA LR03 batteries. If the batteries running low (shows 2.1v in the platform). User can buy generic AAA battery and replace it. Note: 1. - Page 17 User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual In PC, User needs to set serial tool(such as putty, SecureCRT) baud rate to 115200 to access to access serial console of LDS02. Below is the output for reference: The AT Access password is 123456.
-
Page 18: Faq
AT Command Manual 7. FAQ 7.1 How to upgrade the image? User can upgrade the of LDS02 for bug fix, new features, or change working region. The upgrade instruction is here: Firmware Upgrade Instruction 7.2 How to change the LoRa Frequency Bands/Region? If user has for example US915 frequency and want to change it to AS923 frequency. -
Page 19: How To Change Sub-Band For Lds02
firmware: LDS02 works in Subband 2 by default in AU915 / US915 band. So if the LoRaWAN server works in other subband, there will be issue for LDS02 to Join the server. In this case, User can use AT COmmand to change the subband. See AT Command chapther for the hardware connection. Below are the steps to change sub-band: •... -
Page 20: My Sensor Works For Helium Au915 Before But Not It Doesn't Work, Why
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual Since firmware v1.6: LDS02 works in chn mask 0x0000. where cover all subbands. so no need to use AT Commands to change subband and it can works for every subband 7.5 My sensor works for Helium AU915 before but not it doesn't work,... -
Page 21: Packing Info
User Manual for LoRaWAN End Nodes - LDS02 - LoRaWAN Door Sensor User Manual 9. Packing Info Package Includes: • LDS02 x 1 Dimension and weight: • Device Size: 69.2 x 29.2 x 14.8 mm 10. Support • Support is provided Monday to Friday, from 09:00 to 18:00 GMT+8. Due to different timezones we cannot offer live support.
