Ds600
Quick Start Guide
快速操作指南
Copyright
2022 Hobby Model Technology co.,ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hobby Model Technology DS600

  • Page 1 Ds600 Quick Start Guide 快速操作指南 Copyright 2022 Hobby Model Technology co.,ltd ①...
  • Page 2 Antenna CH1-joystick CH2-joystick [Left: Fixed speed] [Middle: Power [Right: Mixed control] Ch2/ TH.TRIM Ch1/ ST.TRIM Switch CH 3 CH 6 CH 5 CH 4 Constant Charging speed port ②...
  • Page 3 Operation Guide Binding instructions A. Power on the receiver first; B. Press the 【 】 button on the receiver again; BING C. Finally power on the transmitter. ※ Receiver light status: 【 】 Slow flashing means no signal 【 】 Quick flashing indicates matching status 【...
  • Page 4 CH1/CH2 mixed control 1. Function description The 1-channel/2-channel mixed control mode allows the 1-channel and 2-channel to control 2 motors at the same time for the forward and backward of the accelerator and the differential steering function. 2. Setting method A.
  • Page 5 Channel positive and negative 1. Function description This remote control can set the forward and reverse direction of channel 1/channel 2. 2. Setting method A. The remote controller is in the off state, B. Press and hold the 【 】 channel button first; C.
  • Page 6 Fail Safe Instructions 1. Function Description Loss of control protection is a protection function for the receiver to lose the signal, so as to avoid loss due to loss of control. It is mainly to set the throttle channel. When the receiver cannot receive the transmission signal, the throttle channel of the receiver will run to the set value.
  • Page 7 Charging instructions 1. Instructions for use A. Built-in remote control: 1200 mAh lithium battery, with charging function, please choose the charger: mobile phone charger with a voltage of 5V; please turn off the remote control during charging; there is an indicator light on the charging port, red light charging, green light full.
  • Page 8 产品规格: Copyright 2022 Hobby Model Technology co.,ltd 更 多 介 绍 视 频 可 扫 码 进 入 或 直 接 搜 索 : HOTRC : For details, please scan the code or search HOTRC ⑧...
