Summary of Contents for MAKS 4M PPB30
- Page 1 Operation manual MODEL PPB30 Operation manual Maks 4M OOD © 2016 , All rights reserved. MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 1/25 tel.:0879990 542...
- Page 2 Operation manual MODEL PPB30 „MAKS 4M“ OOD 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street Bulgaria E-mail: marketing@prity-eu.com tel.:0879990542 Technical support +359 878700840 selling@prity-eu.com We have taken all possible measures to guarantee the accuracy and completeness of the present documentation. Since we cannot exclude the possibility for an error, we will be grateful if you share your suggestions or any further information, which could improve this documentation.
- Page 3 Operation manual MODEL PPB30 Notes related to the documentation Always keep this documentation safe! This documentation is part of the product. For this reason, keep safe the documentation for the entire period of operation of the product. Hand over the documentation to any subsequent user. Make sure that the documentation will be supplemented by remarks and additional documents concerning any upgrade or modification introduced.
-
Page 4: Important Notes
Legal framework 4 Modifications Maks 4M OOD reserves its right to introduce any kind of modifications and revisions, aiming at improving the performance and technical progress. All third party products shall be mentioned without reference to their patented rights and thus, any presence of ones is possible. - Page 5 The pellet burner comes with factory pre-configured hardware and software, which meet individual requirements. Maks 4M OOD shall not be held liable in cases of unauthorized modification to the controller’s hardware or software, as well as in case of its use not as intended.
- Page 6 Operation manual MODEL PPB30 Safe distances! Install away from flammable objects! Safe distances, which must be observed during installation of burners, stoves, boilers and flue pipes must be minimum of 200 mm, in case there are materials with flammability class А, В, С1 nearby and minimum of 400 mm in case there are materials with flammability class С3 nearby.
-
Page 7: Description Of The Device
Description of the device Smart pellet controller (SPC) for PPB20, PPB30, PPB50 is a multi-functional electronic controller, which is integral part of the common system for control and automation „Smart Home”. It is designed to perform flexible control of complex systems of actuating mechanisms and devices, by means of reading and analysis of all incoming input signals following dedicated pre-set algorithms. - Page 8 Operation manual MODEL PPB30 Functionality: The controller provides: Preliminary purging /cleaning/ of the firebox Control of flame put-out Process control of burning intensity. Visual and acoustic signalling for running the program, visualized on a bright display including text and graphics.
-
Page 9: Specifications
Operation manual MODEL PPB30 3.1. Specifications: Description Parameters Heating capacity 10 ~50 kW Consumption of pellets First stage 2 kg/h Second stage 7 kg/h Third stage 10 kg/h Required electrical power for ignition 0,4 kW Required electrical power for burning 0,1 kW №... -
Page 10: Wiring Diagram
Operation manual MODEL PPB30 3.2. Wiring diagram: 3.3. Options: № Description Operator panel HMI/V1 Sensor panel Be150302 Software SPC/W/A/B Wi-Fi module wi-fi GSM module Communication cable to the USB port USB Com Remote access Data Server Mobile version SPC/App * connection of several simultaneously operating operator or sensor panels is possible. - Page 11 Operation manual MODEL PPB30 Dimensions of the burner. MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 11/25 tel.:0879990 542...
-
Page 12: Schematic Diagram
Operation manual MODEL PPB30 Schematic diagram. 1. Control panel 8. Main power supply 2. Pellets input 9. Feeding auger 3. Connection flange with sealing 10. Auger pipe 4. Firebox with heater and grate 11. Gear motor 5. Body of the burner 12. -
Page 13: Installation Instruction
Operation manual MODEL PPB30 Installation instruction. 6.1. Connection to the pellet hopper: The pellets are stored in a hopper, where the auger pipe is inserted at an angle of approx. 45 degrees. In case the pipe was installed under greater angle, there is a possibility that the auger will be blocked as a result from the hindered movement of pellets. -
Page 14: Operator Display
Operation manual MODEL PPB30 6.4. Connection of the pellet feeding auger: Position the auger conveyor so that loading it with pellets from the hopper will be unobstructed. The auger conveyor is supplied with power using plug connector. Its initial filling is performed automatically, along with starting-up of the burner. - Page 15 Operation manual MODEL PPB30 Standby The burner is ready for work. 15.03.2015 11:25 No command for working has been issued. Required conditions to move to the next mode: * Command for starting of the burner: Pressing and holding the button Start for Готовност...
- Page 16 Operation manual MODEL PPB30 Burning up Transitory mode to establish stable burning process. 15.03.2015 11:25 *Loads time for this mode (parameter) *Fan capacity fan is set by a parameter; *Up and down time of the feeding auger is pre-set by parameter;...
-
Page 17: Main Menu Structure
Operation manual MODEL PPB30 Main menu structure MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 17/25 tel.:0879990 542... - Page 18 Operation manual MODEL PPB30 MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 18/25 tel.:0879990 542...
- Page 19 Operation manual MODEL PPB30 MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 19/25 tel.:0879990 542...
- Page 20 Operation manual MODEL PPB30 MAKS 4M OOD E-mail: marketing@prity-eu.com 5100 Gorna Oryahovitsa, 4А Ivan Momchilov Street 20/25 tel.:0879990 542...
-
Page 21: Emergency Situations
Operation manual MODEL PPB30 Emergency situations The controller of PPB20/30/50 burner runs a priority parallel process of following the emergency situations occurred. The emergency situations are indicated by an acoustic signal and message displayed at the control panel. In the middle of the screen the icon remains active, to inform about the current emergency situation. - Page 22 Operation manual MODEL PPB30 Interrupted power supply Interruption of the power Short-time interruption of the Check the main power supply supply. power supply, of the burner The burner continues working photosensor reads presence in „modulation“ mode, and of fire only the message is displayed...
-
Page 23: Factory Settings
Operation manual MODEL PPB30 11. Factory settings: № Parameters Value Limits Ignition Duration 60 sec ÷ 1000 sec 20% ÷100% Initial filling 20 sec ÷ 150 sec Auger feeding 1 sec ÷ 5 sec Auger interval 5 sec ÷ 120 sec External auger 10 sec ÷... - Page 24 Operation manual MODEL PPB30 Hysteresis 2⁰С ÷ 10 ⁰С DHW temperature 30 ⁰С ÷ 70 ⁰С Hysteresis 2⁰С ÷ 10 ⁰С Water pump Temperature of switching on 30 ⁰С ÷ 70 ⁰С Hysteresis 2⁰С ÷ 10 ⁰С DHW temperature of switching on 30 ⁰С...
-
Page 25: Warranty Terms And Conditions
Operation manual MODEL PPB30 12. WARRANTY TERMS AND CONDITIONS The manufacturer warrants the correct and flawless operation of the product only if all requirements for installation and operation, commissioning and maintenance service have been complied with. THE WARRANTY SHALL BE VOID...
