MICREAL MRN027WL User Manual

USB NES/SNES classic mini wireless controller
T
hank you for purchasing the MICREAL product. Please read
this [User Manual] carefully before using the product, and
retain in for future use. If you have any ques�ons or sugges�ons
about our products, please contact: support@szmicreal.com.
Detatils Description
D-Pad 8-way
USB Charging Port
SELECT START
Link Indicate: Red LED
Recharge Indicate: Blue LED

Fast Installation and Startup

1. Plug the USB receiver with NES adapter
to NES Classic Mini Console, then press
the START bu�on of Controller.

Change the Input Mode Of USB Adapter

1. Plug the USB receiver to PC USB Socket.
2. Press and hold the START+SELECT+A for 1s the USB
SELECT START
B A
3. Press and hold the START+SELECT+B for 1s the USB
Note: A�er the controllers are connected to the PC or Raspberry Pi gaming
pla�orm via the USB receiver, if there is a incompa�bility , try to change the
working mode of the controllers to Dinput or Xinput (Factory default).

Controller Working States

1. Pairing Mode:
Press and hold START+SELECT+UP for 1s un�l Red LED flashes quickly, which
means the controller enter into pairing mode. and wai�ng for a new USB receiver
to pairing.
2. Link Mode:
If Controller and Receiver connect successfully, Red LED will light up. At this
moment, you can play games.
3. Standby Mode:
Without no opera�ons in 30s, Controller will enter into standby mode, and
LED will turn off. Press any bu�on can wake it up.
4. Sleep Mode:
without no opera�ons a�er 10 mins, Controller will enter into sleep mode
only START bu�on can wake it up.
5. Power off:
When the ba�ery in your controller are out, the controller will power off
automa�cally.
① NES Wireless Receiver:
For NES Classic mini
Two Fire Bu�ons
② USB Wireless Receiver:
For Windows XP/7/8/10, Mac OS,
Linux, Raspberry Pi.
B A
Start/Wakeup
Bu�on
NES Classic
Select Bu�on
Mini Adapter
SELECT START
B A
2. Plug the USB receiver to PC or other
game console, then press the START
bu�on of Controller.
Receiver will enter Direct Input mode;
Receiver will enter XBOX Input mode;

Low Battery and Charging Reminder

When the controller ba�ery capacity is less than 30%, The RED light will blink.
It prompt you to charge the controller ba�ery.
Red LED blink
You can use the USB cable included in the package to connect to any standard USB
power supply to charge the controller, When the controller is charging, the Blue LED
will light up, A�er full charged the Blue LED will be off automa�c.

Turbo Function Setting

The bu�ons A and B of the wireless controller can
be set with Turbo func�on. In the game, if the bu�ons
has turbo func�on, you cab keep pressing A or B
without releasing the game ac�on and the turbo
func�on will be executed automa�cally.
Turbo se�ng and cancel methods are as follows:
Press and hold Select+A(B) at the same �me for 1 second, A(B) will have con�nue
fire func�on. Cancel the Turbo func�on, you just need to press and hold Select+A (B)
for 1 second again, the con�nue fire func�on of bu�on A(B) will be cancelled.

Return to the NES Games Menu By Controller

Press the START+SELECT at the same �me on wireless controller, equivalent to Press
RESET bu�on of the NES Classic Mini game.
USB Receiver

Paring Controller With USB Adapter

SELECT START
Red LED flash
Press and hold the START+SELECT+UP for 1s
3. If without any opera�ons in 30s, Controller will enter into the standby mode.
Red LED will turn off, You can ac�vate the Controller via pressing any bu�on.
4. Controller will enter into sleep mode if there is no opera�ons a�er 10 mins. You
can only press the Start bu�on to wake up the controller.

Package Contents

Model :
Compa�bility:
Charge method:
Charge �me:
Ba�ery:
Working �me
Wireless transmission
Wireless effec�ve:
Attention
1. Charging input power ra�ng: DC5V.500mA.
2. The built-in ba�ery is a rechargeable polymer lithium-ion ba�ery.
3. Do not use the product in direct sunlight or in damp condi�ons.
4. Do not disassemble the controller for any reason, so as not to make the ba�ery
short-circuit or even burned.
5. The capacity of ba�ery is 250mA, which takes 2 hours for full charge.
6. It can be used con�nuously for about 100 hours.
7. Place the Controller in a recyclable container when it's no use.
Red LED blink when low ba�ery
SELECT START
Blue LED light for Charging.
B A
RESET
Step1: Press and hold the START+SELECT+UP for 1s
un�l Red LED flashes quickly. Controller will enter into
pairing mode. A�er Red LED does not flash quickly
but stays on, which means the pairing between the receiver
B A
and controller is successful.
Step2: Insert the receiver into the NES game console
or PC USB port.
MRN027WL
NES Classic mini, Windows
XP/7/8/10, Mac OS, Linux,
Raspberry Pi
Charge by 5V 500mA Charger, Charge by
computer USB 2.0port .
About 2 hours.
250mAH
100H
2.4GHz wireless connec�on
distance > 30 �
SELECT START
B A
Turbo LED
SELECT START
B A
