Controller Board Tech Guide

Kershaw Systems

www.kershawsystems.com

Table of Contents

Need help?

Do you have a question about the A-WEB Host and is the answer not in the manual?

Questions and answers

Summary of Contents for Kershaw Systems A-WEB Host

Page 1 Controller Board Tech Guide Kershaw Systems www.kershawsystems.com...
Page 2: Table Of Contents
Wire 2 Readers to One Reader Port Page 21 Input / Output – Power Routing Page 22 SD Card Information & A-Web Default Readers Page 23 A-Web Host & AW-EXP-R Circuit Support Page 24 Kershaw Systems Mfg. of RISG Products Questions 949-335-5149 San Clemente, Ca 92672 Kershaw Systems www.kershawsystems.com...
Page 3: A-Web Controller (Diagram)
Reader # 1 2 General Purpose Output Dry Contact Form C Relays 12- 24 VDC 5 Amp for Other Devices **Lithium Battery A-Web Host Clock- see page 4 for more information. 8 Open Collector Outputs use for other devices 12 V & Ground to Power Supply 12V or 13.8V 2.8 to...
Page 4 Reader Controller will be shipped without the CR2032 3 Volt Lithium Battery. These batteries are very common throughout the world. Please check with our RISG Partners if they can ship the batteries with the A-Web Host Controller. The Current USA...
Page 5 AW-EXP-R 2 Reader Expansion Information AW-EXP-R 2 Reader Expansion Boards connect via the 485 Board (see below). Reset Button General Purpose (4) Inputs for other Devices Dipswitch Connect Door Connect Door Contact & REX # 2 2 Door Lock # 1 Lock Relays &...
Page 6 AW-EXP-R 2 Reader Expansion Information 11 10 Door Lock & Output Relays Open Collector Outputs Dipswitch Pin8- 12 V Pin12- Door Lock 1 COM Pin7- 002 Open Collector Pin11- Door Lock 1 N/C RS485 Port Pin6- 12 V Pin10- Door Lock 1 N/O Pin5- 006 Open Collector Pin9- Door Lock 2 COM Pin1- 12 V...
Page 7: Expand System To 32 Readers Using Aw-Exp-R's
Web Host to communicate with the AW-EXP-R (see page 6). When Adding (1) ea. AW-EXP-R 2 Reader Expansion Boards No power supply required if within 50 ft. from AWEB Host. Do not use Power Supply for door strikes or Mag Locks to power AW-EXP-R or A-Web Host.
Page 8 Set Up to Connect to the A-WEB Computer / Lap Top IP Settings Step 1 – Go to Control Panel & Click on STEP 1 Network & Sharing. Network & Sharing STEP 2 Adapter Settings Step 2 – Click on Change Adapter Setting.
Page 9: Connecting Lan To A-Web Controller
Step 1 Plug LAN Cable Directly into LAN Connector on A-Web A-Web Host Controller Enlarged LAN Connection Area on A-Web Host Controller Step 2 Plug LAN Cable Directly into Router and then connect to PC or connect directly into PC...
Page 10 Prox Reader for A-Web / AW-EXP-R Connecting Standard Reader to A-Web / AW-EXP-R (make sure power is off on A-Web & AW-EXP-R before connecting reader) Color Description Reader Power 12V Reader Power 5 V Ground Black Green White No Go Brown Orange Keypad...
Page 11 Prox Key Pad Readers for A-Web / AW-EXP-R Connecting Keypad Reader to A-Web / AW-EXP-R (make sure power is off on A-Web & AW-EXP-R before connecting keypad reader) Color Description Reader Power 12V Reader Power 5 V Ground Black Green White No Go Brown...
Page 12 Connecting Power Connecting Power to A-Web / AW-EXP-R View with Connector Off Description Power 12V/13.8V Power 12V/13.8V Battery Alarm Ground Ground Normal Connection directly to power supply may be a 12 V or 13.8 V to Pin # 1 and Ground to Pin # 5 going left to right. A 12 Volt or the 13.8 Power Unit can be connected to the A-Web or AW-EXP-R.
Page 13 Battery Back Up (for A-Web & AW-EXP-R 13.8V Power Unit to A-Web / AW-EXP-R (Pins 5 & 6) using PS05 shown above) We recommend Battery Back A-Web Host up for the A-Web and AW- Power or AW-EXP-R EXP-R’s. Using the PS05...
Page 14 The 485 connection is used to connect AW-EXP-R-2RD expansion board. This allows for additional readers, inputs & outputs to be connected to the A-Web Host Controller. Connecting the 485 network (if used) to the A-Web Host 485 is at Port1. Use 22 AWG twisted pair wire. This network has a maximum length of 4,000 Ft. Attach the network to connections labeled A and B on PORT1.
Page 15 LED Information for A-Web when Red LED is on Power is On – when green LED is on LED on means Transmit & Receive to Host – when Red LED is on means connected to LAN SD Card Red LED on means SD Card Green LED’s are on means Connected...
Page 16 A-Web to AW-EXP-R Wiring The 485 connection is used to connect AW-EXP-R-2RD expansion boards. This allows for additional readers to be connected to the A-Web Controller. Connecting the 485 network (if used) to the A-Web is at Port1. Use 22 AWG twisted pair wire. A-Web / AW-EXP-R Environmental, Relay &...
Page 17: Enclosures For A-Web & Aw-Exp-R
PS-01/PS-05-C Power Unit (single or dual output Power Unit x 9.3”(235 CM) power supply). (pre-drilled for PS-05-C & A-Web Host-C) A-Web Host-C A-Web Host-C with Cover and standoffs mounted underneath of A- Web Host that match the drill holes on the removable panel inside the EN-17.
Page 18: Wire Lock Relays
Wire Door Lock Relays Wire Mag Lock Relay Normally Close Lock 1 Lock 2 12 VDC External NO NC COM NO NC COM Power Supply Wiring a 12VDC door strike lock using an external power supply. A door magnet lock requires constant Power to the lock &...
Page 19 Wiring Door Contact, Rex & Input Circuits Adding EOL (end of line) Resistors to Inputs Normally Open Normally Close (class B Inputs) (class B Inputs) Inputs Inputs Points Points Wire Door Contact (1) and REX (2) (request to exit) EOL Resistors for Door Contact Only. Door Contact is Normally Close Switch Door Position Switch (N/C Sensor)
Page 20 Wiring Door Contact, Rex & Input Circuits Wire External Relay 24VDC To open collector output Wire a Device directly to an Open Collector Output 1.1 Connect the positive device lead (if polarized) to the + 12 pin 1.2 Connect the remaining device lead to the OC (open collector ground ) pin. Ensure that the current load requirement for each circuit does not exceed 100ma.
Page 21 Special Reader Applications Anti-passback Configuration (using two Readers For 1 door) When configuring an ANTI-PASS BACK circuit which uses two reader circuits to control one door, wire the door strike and door position switch circuits in parallel as shown below. In this setup, the system does acknowledge and control each reader circuit.
Page 22: Input / Output - Power Routing
Input / Output & AC Power Routing The following LED’s should show the following conditions. If they do not, then the A-Web Controller has malfunctioned. D100- Green Run LED should either be ON and PULSING SLIGHTLY. Readers If one or more of the readers does not operate check for power at the reader. Inputs Testing input points should be done with a D.C.Voltmeter.
Page 23: Kershaw Systems
A variety of card readers can be attached to one A-Web or AW-EXP-R. The most common reader is Wiegand and their data wires are listed on page 10. The A-Web Host defaults are in the Hardware Section of the A-Web Host Software which are 26,32,34 & 42 Wiegand and HID 34, HID 35 and Corp 37 and listed below: 26 Bit Wiegand –...
Page 24 A-Web Host / AW-EXP-R Circuit Support Web-Browser Browse into Into A-Web Host System From any PC / Lap Top connected to A-Web Host Connect via LAN Internet / WAN S485 10 Alarm Outputs 2 Readers 4 Alarm Inputs (2 Output Relays & 8...
