Summary of Contents for Dualtech DALM1000 IP
- Page 1 Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 DALMx000 IP/2G/3G Installation and user instructions Page 1 (18) File name: Installation DALMx000 IP_2G_3G EN r3...
-
Page 2: Table Of Contents
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Contents 1 DOCUMENT INFORMATION ......................3 1.1 Summary ..........................3 1.2 History ..........................3 2 DALMx000 - System description ....................4 2.1 Alarms over IP ........................6 2.2 SMS type alarms ........................ -
Page 3: Document Information
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 DOCUMENT INFORMATION 1.1 Summary Common installation manual for products DALM1000, DALM3000 and DALM5000. 1.2 History Revision Comments Modified by / date Approved by / date First version AJ/2014-09-01 FN/2014-09-01 Adapted to new hardware release... -
Page 4: Dalmx000 - System Description
SIA DC09 receiver or Dualtech's reception software IPEagleCMS (for the complete list of ARC´s, please contact Dualtech IT). The device is supplied in a plastic enclosure or with mounting panels for mounting in an existing system enclosure and is usually powered from the existing alarm system. - Page 5 Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Integrated inputs DALMx000 has five “virtual inputs” that automatically activate in the event of different system events. Event ”Input” Event code Power supply < 10.5 VDC LowBatt Internet connection error EthErr GPRS/3G connection error...
-
Page 6: Alarms Over Ip
Alarm protocol ACCESS V4 can be received by any alarm reception centre equipped with Dualtech´s V4 receiver IPEagleCMS and protocol SIA DC09 by any alarm reception centre equipped with standard DC09 receiver. -
Page 7: Sms Type Alarms
For GPRS/3G 1. If a card other than a Dualtech M2M is to be used, PIN code must be switched off in the card. 2. Correct APN (Access Point Name) for actual SIM operator 2.2 SMS type alarms... -
Page 8: E-Mail Alarms
DALMx000 can send alarms as e-mails to any receiver address both via fixed Internet and via GPRS/3G. NOTE: Email messaging via 3G/GPRS is not available is using Dualtech SECURE SIM. In this case, messaging is enabled via the EasyWebManager web portal. -
Page 9: Connecting Analogue Alarm Diallers To Dalmx000
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Connecting analogue alarm dialers to DALMx000 DALMx000 supplies a simulated analogue telephone line on the ”LINE OUT” screw terminal. Here, two wires are connected to the analogue dialer's line connection (e.g. T & R). DALMx000 receives the number dialed by the dialer and sends a start tone for SIA or Contact ID depending on how the device is programmed during system programming. -
Page 10: Specific Points For Connection Of Dalm3000/Dalm5000 To Fire Alarm
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Specific points for connection of DALM3000/DALM5000 to fire alarm Connect output for fire alarm from fire alarm system to DALM3000/DALM5000, input 1 Connect output for error alarm from fire alarm system to DALM3000/DALM5000, input 2 Connect DALM3000/DALM5000 output REL2 to section/input on fire alarm system. -
Page 11: Dalmx000 - Programming And Commissioning
5.1 Quick guide for programming and commissioning DALMx000 Create programming configuration in the web portal https://ewm.dualtech.se Install a SIM card in sim card holder, NOTE: If a card other than a Dualtech SECURE SIM is to be used, SIM PIN code must be switched off Power up the device and wait for the LEDs to transfer to ”Ready for programming”... -
Page 12: Operation
5.2.1 SIM card If a SIM card other than a Dualtech SECURE SIM is to be used, and if the SIM card has a PIN code activated, it must be deleted before the card is placed in the alarm transmitter. This is most easily done using a standard mobile phone. -
Page 13: Status Request
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 5.2.4 Status request When the device has been programmed, a status request can be performed from the PC or from the app at any time. Log into the system and select configuration. Current status of the device is obtained after pressing the ”Status”... -
Page 14: Output Remote Control
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 2.4 NOTE: Reset DIP3 to OFF. 3. Select the relevant configuration via the app. Then select ”Tools” - ”New hardware” – ”Continue” – ”Hardware replaced” 4. Reprogram via the app, where the new phone number is entered. 5.2.6 Output remote control DALMx000 has two outputs that can be controlled via SMS sent to the alarm transmitter's SIM card phone number. -
Page 15: Technical Specifications Dalmx000
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Technical Specifications DALMx000 6.1 Hardware 6.1.1 Connections DIP Switch J2-A ETH 1 Connection Function 12/24V Connection power supply, 11-30 VDC. Secure with external fuse, 1A LINE OUT Simulated telephone line for connecting an analogue dialler GPRS/3G Potential free relay output for GPRS/3G error, max 100mA... -
Page 16: Dip Switches
Signal strength for GSM mobile network indicated by LEDs. At least one green LED must be lit. The function replies SMS at remote control of bypass/outs off. NOTE: Not applicable for Dualtech SECURE SIM where SMS delivery is not available. Reserved Reserved... -
Page 17: Led Indication
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 6.2 LED indication DALMx000 has five LEDs for indicating status and errors. LED 1 Status Description 2 3 4 5 GSM module switched off SIM-kort Flashes once per Searching for GSM second network... -
Page 18: Power Supply And Current Consumption
Title Confidentiality Document no. Revision Installation DALMx000 IP/2G/3G Project Published by Date 2015-06-03 Off: Connection to local network OK Flashes once/second: Delivery of alarm via Ethernet failed. Lit: Connection error to local network. Check the cable. Flashes:Waiting for GPRS/3G network Off: GPRS/3G connection OK Lit: GPRS/3G error Indicates signal strength on GPRS/3G link when DIP switch 4 is...
