- Page 1 EtherNet MPI Adapter GT100-IE-MPI User Manual V 2.0 SST Automation Email: support@sstautomation.com www.SSTAutomation.com...
- Page 2 Important Information Warning The data and examples in this manual cannot be copied without authorization. SST Automation reserves the right to upgrade the product without notifying users. The product has many applications. The users must make sure that all operations and results are in accordance with the safety of relevant fields, and the safety includes laws, rules, codes and standards.
-
Page 3: Table Of Contents
Catalog 1 Product Overview ..............................1 1.1 Product Function ............................1 1.2 Product Features ............................. 1 1.3 Technical Specifications ..........................1 1.4 Related Products .............................2 1.5 Revision History .............................2 2 Hardware Descriptions .............................. 3 2.1 Product Appearance ............................3 2.2 Indicators ................................ 4 2.3 Interface ................................4 2.3.1 Power Interface ........................... -
Page 4: Product Overview
1 Product Overview 1.1 Product Function The GT100-IE-MPI is an adapter which is used for Ethernet communication of Siemens SIMATIC S7 series PLC (including S7-200, S7-300, S7-400), Siemens CNC (840D, 840DSL, etc). It supports data monitoring. 1.2 Product Features Supports multi-master communication, the expansion port can be connected to touch screen or other masters. -
Page 5: Related Products
[4] Operating temperature: 32℉~140℉(0℃ ~ 60℃). Humidity: 5%~90% (non-condensing). [5] Dimensions (W*H*D): 0.67 in *2.56 in *1.29 in (17mm*65mm*33mm). [6] Installation: Siemens S7 PLC DB9 communication port plug. [7] Protection Level: IP20. 1.4 Related Products The related products include: GT200-DP-RS, GT200-PN-RS and GT200-PN-3RS, etc. To get more information about related products, please visit SSTCOMM website: www.sstautomation.com. -
Page 6: Hardware Descriptions
2 Hardware Descriptions Product Appearance Extended S7 Bus Interface Indicators S7 Bus Interface Ethernet Interface Optional Power Interface Notes: This picture is for reference only. The product appearance is subject to the actual product. www.SSTAutomation.com... -
Page 7: Indicators
2.2 Indicators Indicator State State description Troubleshooting Supply of power is normal OFF, Flashing Supply of power is abnormal Check the power supply The baud rate is correct and the gateway is functioning normally Flashing (for 1 The same station address exists on the Modify the station address of the seconds) S7 bus... -
Page 8: Ethernet Interface
2.3.2 Ethernet Interface The Ethernet interface uses an RJ-45 connector. Its pin (standard Ethernet signal) is defined as below: Description TXD+, Transmit Data+ TXD-, Transmit Data- RXD+, Receive Data+ Bi-directional Data+ Bi-directional Data- RXD-, Receive Data- Bi-directional Data+ Bi-directional Data- 2.3.3 S7 Bus Interface 1) S7 bus interface X1 X1 interface is DB9 male port, which can be directly inserted into the communication port (PPI port, MPI port or... -
Page 9: Reset Button
2) Extended S7 bus interface X2 The X2 interface is a DB9 female port, which is used to connect Siemens communication equipment (such as Siemens touch screen, CP5611 communication card, etc.). The supported baud rates include 9.6K, 19.2K, and 187.5K. 2.3.4 Reset Button The reset button is used to restore the gateway to factory settings. -
Page 10: Hardware Installation
3 Hardware Installation 3.1 Mechanical Dimension Size (width * height * depth): 0.67 in *2.56 in *1.29 in (17mm*65mm*33mm) 3.2 Installation Method Using Siemens S7 PLC DB9 communication port plug. www.SSTAutomation.com... -
Page 11: Quick Start Guide
2. Build your configuration using web browser after connecting the gateway with network cable. If the gateway cannot be searched，please note: The network factory setting of GT100-IE-MPI is 192.168.1.188. Please check whether the computer and gateway are in the same network segment. -
Page 12: Configuration Instructions
5 Configuration Instructions 5.1 Configuration Interface Description After connecting the gateway using network cable, you can fill in http://192.168.1.188/ to start configuration of GT100-IE-MPI. When you first visit the web configuration page, the interface is as below. The default password is admin. -
Page 13: Parameter Settings
5.3 Parameter Settings 5.3.1 Basic Settings Click the "Parameter Settings" on the left and you will the configuration interface, as shown below: Device name: Enter the name of the device to which the bridge is connected. Password: Change the login password of the web configuration page. Confirm password: Input the password again. -
Page 14: Serial Interface Settings
X2 baudrate: Select the baudrate you want to use with PLC. X2 port connects to PLC,the baudrate can be set to be automatic or fixed baudrate. 5.3.3 Ethernet Interface Settings IP Address: Set the IP address of the GT100-IE-MPI. Subnet Mask: Subnet mask is 255.255.255.0 by default. Gateway: The default address is 192.168.1.1. -
Page 15: Download
5.4 Download When parameter settings are done, please click Download button to download the configuration to the GT100-IE-MPI. The web page will show the following hint when you click the Download button. Then the configuration will take effect. www.SSTAutomation.com... -
Page 16: Portal Programming
6. Portal Programming 6.1 System Requirement If you want to use GT100-IE-MPI to do programming on Portal or STEP7, you should install Portal software firstly. 6.2 Programming You should refer to the following instructions to finish the programming. 1. New a project. - Page 17 4. Double click "MPI address", configure it and click "Add new subnet". www.SSTAutomation.com...
- Page 18 5. It will generate "MPI_1" network, the "Address” should be the same with MPI address of PLC. The default is 2. 6. Then "Add new device", select "PC station" under "PC general" of "PC systems", click OK. www.SSTAutomation.com...
- Page 19 7. Select "Communications modules"->"PROFIBUS"->"CP5611(A2), drag it to the No.1 slot of PC station. 8. Double click "CP5611A2_A" and start configuring. Choose "MPI" for Interface type. Choose "MPI_1" for Subnet, "Address" keeps 3 (Prevents address duplication with other MPI stations). www.SSTAutomation.com...
- Page 20 9. Select "Communications modules"->"PROFINET/Ethernet"->"IE general", drag it to the No.2 slot. 10. Double click "IE general_1" and start configuring. Click "Add new subnet" and it will automatically generate "PN/IE", fill in the IP address and Subnet mask of the GT100-IE-MPI (for example, it is 192.168.1.188). www.SSTAutomation.com...
- Page 21 11. Right click "PLC", turn to "Go online". In the pop-up window, select "PN/IE" for "PG/PC" interface type, select local network card for "PG/PC Interface". Click searching, then the PLC will be found. Click "Go online". www.SSTAutomation.com...
- Page 22 12. Right click "Program blocks", select "Upload from device (software)", then start uploading and downloading the program of PLC. www.SSTAutomation.com...
-
Page 23: Use Case
7. Use Case www.SSTAutomation.com...
