TRUBLUE iQ+ LT /

TRUBLUE iQ+ XL

AUTO BELAY

Installation Guide

Models: TBiQ+LT / TBiQ+XL

NOTE TO INSTALLERS

Always Read Instructions Before Use

Leave this Installation Guide attached to the Auto Belay. The

Installation Guide contains information relating to the safe

use of the TRUBLUE iQ+ Auto Belay and includes all product

registration and Warranty information. This document may

only be removed by the Owner/Operator. Ensure that this

Installation Guide is readily available to Operators at all times

Head Rush Technologies TRUBLUE iQ+ Installation Guide

P/N 12904-02

Head Rush Technologies products are covered by a number of patents, including

U.S. Patents 8,490,751; 8,851,235; 9,016,435 and D654,412

& corresponding patents/applications in the USA and in other countries worldwide.

Table of Contents

Need help?

Do you have a question about the TBiQ+LT and is the answer not in the manual?

Questions and answers

Summary of Contents for Trublue TBiQ+LT

Page 1 Leave this Installation Guide attached to the Auto Belay. The Installation Guide contains information relating to the safe use of the TRUBLUE iQ+ Auto Belay and includes all product registration and Warranty information. This document may only be removed by the Owner/Operator. Ensure that this...
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION 1.1 Symbols Used in this Manual IMPORTANT INFORMATION 2.1 Included Parts List 2.2 TRUBLUE iQ+ Modes 2.3 TRUBLUE iQ+ Battery Pack 2.4 Wiring Diagram AUTO BELAY INSTALLATION 3.1 Precautions 3.2 Standards 3.2.1 Anchor Points 3.2.2 Secondary Connectors 3.2.3 Selecting a Location...
Page 4 Auto Belay system, its component parts, and all associated hardware. Users of the TRUBLUE iQ+ Auto Belay must be trained on proper usage of the Auto Belay. It is the responsibility of the Owner/Operator to provide this training. Failure to do so can result in death, serious injury, and equipment damage.
Page 5: Safety Information
SAFETY INFORMATION Symbols Used in this Manual The following safety symbols are used throughout this Manual to highlight potential dangers. One or more precautions may be associated with practices and procedures described within this Manual. Failure to adhere to any precautions highlighted can result in death, serious injury, or equipment damage.
Page 6: Important Information
2.0 IMPORTANT INFORMATION Included Parts List 1x TRUBLUE iQ+ Auto Belay 1x Summit Button 1x Base Button 2x 20 m Communication Cable www.headrushtech.com | +1-720-565-6885...
Page 7 1x Y-Cable Splitter 1x Li-Ion Battery Pack (shipped inside the Base Button) 1x Battery Charger 6x Wood Screws www.headrushtech.com | +1-720-565-6885...
Page 8 1x Summit Button Backer 1x Base Button Backer 1x Battery Removal Tool 1 Releasable Cable Tie www.headrushtech.com | +1-720-565-6885...
Page 9: Trublue Iq+ Modes
Error - Refer to Section 10.9 Troubleshooting in Operator’s Manual Normal Mode Device functions as a standard LEDs off TRUBLUE iQ Auto Belay. A fall during climbing will safely lower the climber to the ground. Catch-and-Hold Device will monitor climbing Blue LEDs pulsing slowly...
Page 10: Trublue Iq+ Battery Pack
Battery Pack with unapproved chargers may result in damage to the Battery Pack, fire, or serious injury. Do not attempt to power any device other than the TRUBLUE iQ+ with the supplied Battery Pack. Do not submerge the Battery Pack in water.
Page 11 If the Battery Pack is removed or runs out of charge, the TRUBLUE iQ+ Auto Belay will function just like a regular TRUBLUE iQ Auto Belay and is safe for use. The Battery Pack must be recharged periodically for continued operation of the Catch-and-Hold Technology.
Page 12: Wiring Diagram
Wiring Diagram TBiQ+ AUTO BELAY SUMMIT BUTTON 20 M 20 M COMMUNICATION COMMUNICATION CABLE CABLE Y-CABLE CONNECTOR BASE BUTTON www.headrushtech.com | +1-720-565-6885...
Page 13: Auto Belay Installation
Standards for anchor points, hardware, and equipment used with the Auto Belay. 3.2.1 ANCHOR POINTS All anchor points and connectors used with a TRUBLUE iQ+ Auto Belay must conform to any federal or state requirements for such devices. www.headrushtech.com | +1-720-565-6885...
Page 14: Secondary Connectors
3.2.3 SELECTING A LOCATION The TRUBLUE iQ+ Auto Belay is to be mounted at the top of the climbing route/ descent path with the Nozzle and webbing line pointed down. When selecting a location to mount the Auto Belay, ensure that: ƒ...
Page 15: Outdoor Installations
Operator. Details of replacement parts may be found in the Replacement Parts section of the Operator Manual. The TRUBLUE iQ+ Auto Belay MUST be installed with the flat plastic cover facing the climbing/descent wall. The TRUBLUE iQ+ Brake Module MUST face away from the climbing/descent wall.
Page 16 The TRUBLUE iQ+ Auto Belay has a plastic mounting insert which is inserted through the primary mount attachment point. The mounting connector or carabiner should always be used with the plastic mounting insert during installation. This plastic mounting insert is designed to protect the aluminum mounting point from deformation due to swinging and movement of the Auto Belay during use.
Page 17 DEVICE ORIENTATION Always mount the TRUBLUE iQ+ Auto Belay with the covers parallel to the face of the climbing wall. Mounting in this direction will allow the TRUBLUE iQ+ Auto Belay to swing laterally and minimize the wear on the webbing line, Nozzle assembly and mounting points.
Page 18: Wire Routing
Wire Routing With the TRUBLUE iQ+ Auto Belay properly mounted, the 20 m Communication Cable can be routed to the device. STEP 1: INSTALL RELEASABLE CABLE TIE Insert the Releasable Cable Tie into the Cable Tie Holder. STEP 2: CONNECT 20 M COMMUNICATION CABLE Align the pins in the Device Connector to the sockets in the Cable End.
Page 19 STEP 3: SECURE THE 20 M COMMUNICATION CABLE Route the 20 m Communication Cable through the Releasable Cable Tie. Leave a small amount of slack in the 20 m Communication Cable to prevent excess strain on the cable connection. Tighten the Releasable Cable Tie to secure the 20 m Connection Cable.
Page 20 STEP 5: ROUTE THE 20 M COMMUNICATION CABLE CONT. The 20 m Communication Cable must be routed to the ground behind the climbing wall to prevent damage to the cable. Determine the best location to route the 20 m Communication Cable to the base of the climbing wall where the Base Button will be mounted.
Page 21: Summit Button Installation
4.0 SUMMIT BUTTON INSTALLATION The Summit Button is mounted at the top of the climbing route and, when touched, disables the Catch-and-Hold feature of the TRUBLUE iQ+ Auto Belay. The Summit Button is powered by a 20 m Communication Cable that connects to the Base Button via the Y-Cable Splitter.
Page 22 STEP 3: PRE-DRILL MOUNTING HOLES (OPTIONAL) Use the Summit Button Backer to mark and pre-drill the three (3) mounting holes for the Summit Button. The center hole in the Summit Button Backer should align with the 7/16” hole created in the previous step. STEP 4: CONNECT THE 20 M COMMUNICATION CABLE Slide the Summit Button Backer onto the cable.
Page 23 Align the pins in the Summit Button Connector to the sockets in the Cable End. Press the Cable End onto the Summit Button Connector. Screw the Cable End onto the Summit Button Connector until finger tight. Take care to only turn the silver piece of the Cable End to avoid damaging the 20 m Communication Cable.
Page 24: Base Button Installation
5.0 BASE BUTTON INSTALLATION The Base Button contains the Battery Pack and is used by the climber to turn Catch-and-Hold Mode On or Off. The Base Button should be installed at the base of the climbing wall in a convenient location. The Base Button requires a 7/16” hole and three (3) of the included wood screws to attach to the climbing wall.
Page 25 Summit Button. The center hole aligns with the 7/16” hole created in the previous step. NOTE The Base Button Backer is facing forward when the word “TRUBLUE” is readable as shown in the image below. The top of the Base Button Backer can be used to ensure level mounting.
Page 26 STEP 4: MOUNT THE BASE BUTTON Run the Base Button Cable through the Base Button Backer and place the Base Button Backer flush with the back of the Base Button. Run the Base Button Cable through the climbing wall and align the Base Button as desired.
Page 27 NOTE Any #10 flat head screws can be used in place of the wood screws if the wall material requires a different type of screw. STEP 5: CONNECT THE Y-CABLE SPLITTER TO THE BASE BUTTON CABLE Align the pins in the Base Button Cable to the sockets in the Y-Cable Splitter Cable End.
Page 28 STEP 6: CONNECT THE 20 M COMMUNICATION CABLES TO THE Y-CABLE SPLITTER Align the pins in the Y-Cable Splitter to the sockets in one of the 20 m Communication Cables. NOTE Either one of the 20 m Communication Cables can be connected to either one of the Y-Cable Splitter Ends.
Page 29 FIRST 20 M COMMUNICATION CABLE SECOND 20 M COMMUNICATION CABLE www.headrushtech.com | +1-720-565-6885...
Page 30: Battery Pack Installation
6.0 BATTERY PACK INSTALLATION The Battery Pack is located in the Battery Tray of the Base Button and is accessible using the Battery Removal Tool. An attempt to remove the Battery Pack using any other object may result in damage to the Battery Pack or the Base Button.
Page 31 STEP 2: CONNECT THE BATTERY PACK CABLE TO THE BASE BUTTON POWER CABLE Install the Battery Pack in the Battery Tray and connect the Battery Pack wire to the Base Button Power Cable. NOTE Ensure that all of the Communication Cable connections have been made and are secure before connecting the Battery Pack Cable.
Page 32: Battery Pack Removal
BATTERY PACK REMOVAL The Battery Pack is located in the Battery Tray of the Base Button and is accessible using the Battery Removal Tool. An attempt to remove the Battery Pack using any other object may result in damage to the Battery Pack or the Base Button.
Page 33 STEP 2: DISCONNECT THE BATTERY PACK CABLE TO THE BASE BUTTON POWER CABLE Disconnect the Battery Pack wire from the Base Button Power Cable and remove the Battery Pack from the Battery Tray. STEP 3: SECURE THE BATTERY TRAY Slide the Battery Tray back into the Base Button until the Battery Tray clicks into place.
Page 34: System Check
8.0 SYSTEM CHECK Perform a system check to ensure all cables are properly connected and that the Catch-and-Hold feature is functioning correctly. If any of the below steps do not function as described, consult the Troubleshooting Section of the Operator Manual.
Page 35 NOTE The LEDs may show a short flash the moment that the Battery Pack is plugged in. This immediate flash is not the electronic check. The electronic check will take approximately 1-2 seconds to complete. Electronic Check Reports LED Indicator Decription of Report LEDs flash Green Electronic Check - OK...
Page 36 Base Button to select the Preset Hold Time. The table below shows the relationship between the number of flashes and the Preset Hold Time in the order that the flashes will appear. The TRUBLUE iQ+ will come from the factory with a Preset Hold Time set at 15 seconds.
Page 37 Hold Mode will automatically disengage and the TBiQ+ Auto Belay will enter Normal Mode. CONGRATS! Your TRUBLUE iQ+ Auto Belay is now ready for use. The only things left to do are clip in, activate Catch-and-Hold Mode, and start climbing. Welcome to the future of auto belaying!
Page 38 NOTES www.headrushtech.com | +1-720-565-6885...
Page 40 REGISTER YOUR DEVICE Get automatic updates on recertification and product information – visit www.headrushtech.com/register ANNUAL RECERTIFICATION IS REQUIRED Please keep the shipping box for your device. For instructions on annual recertification, visit www.headrushtech.com/annual-service +1-720-565-6885 www.headrushtech.com info@headrushtech.com Jan 2023...
