INSTRUCTIONS
Read this manual carefully before using your
camera.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Epic Zoom 80 CF and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus Epic Zoom 80 CF

Summary of Contents for Olympus Epic Zoom 80 CF

  • Page 1 INSTRUCTIONS Read this manual carefully before using your camera.
  • Page 2 WARNING Indicates circumstances under which mishandling resulting from ignoring this symbol could result in personal injury or property damage. KEEP THE BATTERIES AWAY FROM FIRE. NEVER TRY TO DISASSEMBLE, RECHARGE, OR SHORT-CIRCUIT BATTERIES.
  • Page 3 DISASSEMBLE THE CAMERA; IT CONTAINS A HIGH-VOLTAGE CIRCUIT. IF THE INTERNAL PARTS OF THE CAMERA ARE EXPOSED DUE TO DROPPING OR DAMAGE, REMOVE THE BATTERIES IMMEDIATELY TO PREVENT FURTHER USAGE. IN CASE OF MALFUNCTION, CONSULT YOUR NEAREST OLYMPUS DEALER OR OLYMPUS SERVICE CENTER...

  • Page 4: Table Of Contents

    Names of parts ... 6 Viewfinder display/LCD panel .. 8 Loading the battery... 11 Checking the battery ... 13 Proper shutter release...14 Loading the film ... 15 Taking pictures ... 18 After shooting... 24 Unloading the film ... 25 Taking panorama pictures*... 26 Using the shooting modes ...

  • Page 5: Table Of Contents

    Using the RC-200 remote control (optional)... 44 Correcting the data**... 48 Printing the date and time**... 50 Care and storage... 52 Caring for your weatherproof camera... 56 Specifications ... 59 * Models with the panorama switch only. ** QUARTZDATE/DLX models only.

  • Page 6: Names Of Parts

    NAMES OF PARTS Shutter release button Zoom lever Strap eyelet Remote control sensor Lens barrier Light sensor* Selftimer indicator Lens* Autofocus windows* Flash* LCD panel (date/time indicator**) Viewfinder Shooting mode button Selftimer/remote control button...
  • Page 7 MODE and SET buttons" Green lamp Orange lamp Viewfinder Panorama switch*** Back cover release Back cover Mid-roll rewind button Film window Tripod socket Battery compartment cover Do not soil as this can cause blurred pictures. Wipe clean with a soft cloth. QUARTZDATE/DLX models only.

  • Page 8: Viewfinder Display/Lcd Panel

    VIEWFINDER DISPLAY/ LCD PANEL Viewfinder Display Close-up correction marks Autofocus mark Green lamp Orange lamp A: Standard mode B: Panorama mode* * Models with the panorama switch only.
  • Page 9 LCD Panel Date/time indicator* Infinity mode Exposure counter Selftimer/remote control** Red-Eye Reducing Flash mode Off (Flash Override) mode Fill-In Flash mode Night Scene Flash mode Battery check * QUARTZDATE/DLX models only. **Optionally available...
  • Page 10 Notes: If you don't use the camera, the LCD goes off after four and half minutes. The LCD panel does not actually display all indications simultaneously as shown. Attach the strap as shown.

  • Page 11: Loading The Battery

    LOADING THE BATTERY 1. Close the lens barrier. Push OPEN to open the battery compartment cover 2. Insert the new battery correctly. WARNING; KEEP THE BATTERY OUT OF THE REACH OF CHILDREN. IF A CHILD SWALLOWS A BATTERY, CONTACT A DOCTOR IMMEDIATELY.
  • Page 12 Notes: About 15 rolls of 24-exposure film can be used with one new battery. Keep a spare battery on hand when going on a long trip or to a cold area. Sweat, oil, and so on can prevent a battery's terminals from making electrical contact.

  • Page 13: Checking The Battery

    CHECKING THE BATTERY Open the lens barrier until you feel a click. Display: lights (and turns off automatically). Meaning: Battery is OK. You can shoot. Display: blinks and other indicators are displayed normally. Meaning: Battery power is low and battery should be replaced. Display: blinks and other indicators go out.

  • Page 14: Proper Shutter Release

    PROPER SHUTTER RELEASE Practice before loading the film. Locks the focus. The green lamp lights. Releases the shutter to take the picture. Cautions: • Press the shutter release button gently. • Avoid shaking the camera when pressing the shutter release button to prevent blurry pictures.

  • Page 15: Loading The Film

    LOADING THE FILM 1. Open the back cover. Do not touch the inside of the camera, especially the lens. 2. Insert the film cartridge until it clicks. Note: Use of ISO 400 film is recommended.
  • Page 16 A. Correct Make sure the film is lying flat. B. Incorrect Push the film cartridge gently to position the film correctly. Then press the left side of the back cover and close it securely. If the film is not lying flat, the film may not advance to the first frame.
  • Page 17 3. Align the film leader with the mark , and close the back cover. The film automatically advances to the first frame. The film does not overlap any of the positioning guides Then close the back cover. 4. Open the lens barrier until you feel a click.

  • Page 18: Taking Pictures

    TAKING PICTURES 1. Open the lens barrier until you feel a click. The lens extends slightly, the flash pops up, and the LCD panel turns on. Note: When the flash is held down, the camera will not activate. Release your finger from the flash.
  • Page 19 2. Aim the camera at your subject. Use the zoom lever for telephoto or wide- angle photography.
  • Page 20 How to Use the Zoom Lever Telephoto: Pull the lever to the "T" side to zoom in. Wide angle: Push the lever to the "W" side to zoom out.
  • Page 21 3. Position the autofocus mark on your subject. WARNING: DO NOT LOOK DIRECTLY AT THE SUN THROUGH THE VIEWFINDER. 4. Depress the shutter release button halfway to adjust the focus. Focus has been correctly adjusted and the green lamp lights. Exposure also will be adjusted automatically.
  • Page 22 5. Depress the shutter release button fully to take the picture. Note: Keep your fingers and the strap away from the lens, autofocus windows and flash. Working distance: 0.6 m (2 ft) ~ (infinity) Notes: When the subject is closer than the minimum working distance, the shutter will not release.
  • Page 23 Close-up Correction Picture area at (infinity) Close-up correction marks Image area of picture at 0.6 m (2ft) The picture area will move lower in the viewfinder as you get closer to the subject.

  • Page 24: After Shooting

    AFTER SHOOTING 1. Close the lens barrier slowly and carefully. The lens and flash will retract automatically. 2. Close the lens barrier completely. Caution: Do not forcibly close the lens barrier as it will interfere with lens retraction. Note: The power is turned off automatically after 4.5 hours.

  • Page 25: Unloading The Film

    UNLOADING THE FILM The camera automatically rewinds the film when you reach the end of a roll. After the motor stops and £ starts blinking on the LCD panel, open the back cover and remove the film. Rewinding the film before the end of the roll Press the mid-roll rewind button gently with your fingernail, etc.

  • Page 26: Taking Panorama Pictures

    TAKING PANORAMA PICTURES Set the switch to PANORAMA. Caution: To avoid malfunction, do not touch the sliding panorama borders inside the camera when the back cover is open in the Panorama mode. Notes: Always set the panorama switch to either end, not midway between the two ends.
  • Page 27 Availability of panorama format film processing facilities varies according to area. We recommend that you consult your local film processor or camera dealer before taking pictures in the Panorama mode. When pictures taken in the Panorama mode are printed in the standard size, black strips appear at top and bottom of prints.
  • Page 28 Close-up Correction in the Panorama Mode At about 0.6 m (2 ft) the shaded area in the illustration becomes the image area.

  • Page 29: Using The Shooting Modes

    USING THE SHOOTING MODES This camera has seven shooting modes. Use these modes in accordance with the photographic conditions and your purpose. Setting the Modes Each time the shooting mode button is pressed, the mode will change sequentially as shown on page 58.
  • Page 30 Auto Flash mode (p. 31) Red-Eye Reducing Flash mode (p. 32) Off (Flash Override) mode (p. 34) Fill-In Flash (Forced Activation) mode (p. 35) Infinity mode (p. 36) Night Scene Flash mode (p. 37) Red-Eye Reducing Night Scene Flash mode (p. 38) Note: The flash strength is automatically controlled to prevent pictures from being...
  • Page 31 W (38 mm) T (80 mm) 0.6 ~ 4.4 m 0.6 ~ 2.2 m (2 ~ 14.4ft) (2 ~ 7.2 ft) 0.6 ~ 6.2 m 0.6 ~ 3.1 m (2 ~ 10.2 ft) (2 ~ 20.3 ft) 0.6 ~ 8.8 m 0.6 ~ 4.4 m (2 ~ 14.4ft) (2 ~ 28.9 ft)
  • Page 32 RED-EYE REDUCING FLASH Significantly reduces the phenomenon of "red-eye" (when a subject's eyes appear red in flash photography). In the flash mode, the camera will fire a series of low-power pre- flashes before the regular flash. Red-eye reduction may not be effective when the subject: 1.
  • Page 33 The effectiveness of red-eye reduction varies depending on the individual characteristics of subjects. IMPORTANT: Be sure to hold the camera still until the shutter releases. It takes approximately one second.
  • Page 34 OFF (FLASH OVERRIDE) When you don't want the flash to fire even in the dark or when you want to shoot such subjects as fireworks. Use this mode in situations where flash photography is not desired or is prohibited or in twilight or night scenes.
  • Page 35 FILL-IN FLASH (Forced Activation) When you want the flash to fire for each shot. The flash fires regardless of available light. Use this mode to compensate for a shadow oast on the subject's face (such as the shadow of a tree). It is also used when shooting in backlit conditions or under artificial lighting (such as fluorescent...
  • Page 36 INFINITY The camera automatically sets the working distance at (infinity) and the flash to OFF (flash override). Notes: Cancel the Infinity mode to shoot a subject up close. Since the autofocus system is de-activated, this mode is useful for shooting a landscape through a window.
  • Page 37 NIGHT SCENE FLASH When taking pictures of a night scene, this mode produces clear images. Notes: The use of a tripod is recommended since slow shutter speeds (down to 4 seconds) are automatically selected in low-light situations. Closing the lens barrier restores the Auto Flash mode.
  • Page 38 RED-EYE REDUCING NIGHT SCENE FLASH MODE You can take pictures of people with a night scene background while reducing the "red-eye" phenomenon. Notes: Except for the pre-flashes, this mode is the same as the Night Scene Flash mode. Read precautionary remarks in "Red-Eye Reducing Flash"...

  • Page 39: Backlight Control

    BACKLIGHT CONTROL Use this mode to achieve correct exposure when the subject is backlit. 1. Press the selftimer/remote control button and flash mode button simultaneously. will be displayed on the LCD panel. To cancel the Backlight Control mode, press both buttons simultaneously again or close the lens barrier.
  • Page 40 Difficult-to-Autofocus Subjects Although this camera's autofocus system can lock on virtually any subject, under certain conditions, such as below, it may not lock on the correct subject even if the shutter releases. This can happen either when the green lamp lights or blinks intermittently.
  • Page 41 In these situations, first focus on a different subject at a similar distance, and then reposition the correct subject in the picture frame. Glossy or reflective surfaces Black objects Subjects behind glass or wire mesh Flames and smoke Excessively bright light within the picture area...

  • Page 42: Selftimer

    SELFTIMER 1. Press the button to display Fix the camera on a tripod or other support. 2. Aim at your subject, and press the shutter release button. The shutter will be released about 12 seconds after you press the button. The selftimer automatically disengages after release.
  • Page 43 Notes: The focus and exposure will be locked when the shutter release button is depressed halfway. To cancel the selftimer after it has been activated, press the button again.
  • Page 44 USING THE RC-200 REMOTE CONTROL (optional) 1. Press the button to display To cancel this mode, press the button again. This mode is canceled automatically when not used for more than 20 minutes. 2. Aim the remote control at the camera, and press the button.
  • Page 45 WARNINGS: KEEP THE REMOTE CONTROL OUT THE REACH OF CHILDREN. IF A CHILD SWALLOWS THE REMOTE CONTROL, CONTACT A DOCTOR IMMEDIATELY. NEVER EXPOSE THE REMOTE CONTROL TO EXCESSIVE HEAT OR OPEN FLAME. Notes: Use the remote control within a range that can be seen in the viewfinder.
  • Page 46 Attaching to the Strap Open the buckle ~ , insert the strap , and close the buckle The remote control can be attached to round straps with a diameter of 3 ~ 5 mm (0.12 ~ 0.2 in) and flat straps with a thickness of 1.2 ~ 2 mm (0.05 ~ 0.08 in) and a width of 6 ~ 12.5 mm (0.23 ~ 0.42 in).
  • Page 47 Replacing the Battery 1. Open the buckle remove the battery cover inside by sliding in the direction of the arrow. 2. Insert a new battery (CR1220) with the plus mark showing on top 3. Attach the battery cover by sliding in the direction of the arrow 4.

  • Page 48: Correcting The Data

    CORRECTING THE DATA (for QUARTZDATE/DLX models only) 1. Press the MODE button for two seconds or longer. The year indication will start blinking. 2. Press the SET button to correct the year. If you press the button once, the number on the display will advance by 1.
  • Page 49 3. Press the MODE button again. The month indication will start blinking. 4. Repeat steps 2 and 3 to set the day, hour and minutes. Note: As you press the mode button, the blinking indication changes in the order of year, month, day, hour, and minute.

  • Page 50: Printing The Date And Time

    PRINTING THE DATE AND TIME (for DUARTZDATE/DLX models only) Choose the desired mode. The mode will switch in the described order. The date unit uses the same power switch as the main unit. Make sure to correct the data after the battery is replaced. The data is imprinted in the lower right of the picture.
  • Page 51 No data Year-month-day Month-day-year Day-month-year Day-hour-minute...

  • Page 52: Care And Storage

    CARE AND STORAGE Do not leave the camera in any place exposed to excessive heat, humidity, or direct sunlight — for example, in a car or on the beach. Do not expose the camera to formalin or naphthalene. If the camera gets wet, wipe it with a dry towel.
  • Page 53 Do not expose the camera to dust or sand as this could cause serious damage. Do not shake or shock the camera. Do not apply excessive force to the zoom lens. Keep the camera in a well- ventilated place. Do not expose the camera to extreme heat (over 40°C/104°F) or to extreme cold (below -10°C/14°F).
  • Page 54 When transporting the camera from a cold place to a warm place or in the event of a sudden temperature change, put the camera into a plastic bag. This allows the camera's temperature to change slowly. Once the camera has to the new temperature, you can remove it from the bag and use it.
  • Page 55 Avoid leaving the camera unused for long periods of time. This can cause mold to grow on the camera as well as other problems. Try to press the shutter release button and check the operation of the camera before use. Some airport X-ray machines can damage the film in your camera.

  • Page 56: Caring For Your Weatherproof Camera

    CARING FOR YOUR WEATHERPROOF CAMERA This camera is designed to be water- resistant; however, it is not designed for underwater use or to be subjected to being saturated. Seawater can be especially damaging to your camera due to salt content. Note the following warnings and take the necessary precautions if your camera becomes wet.
  • Page 57 These gaskets protect the interior of the camera from becoming wet in the event the camera is splashed with water. Check these gaskets often and carefully remove any sand or dust to maintain this protective seal. Whenever your camera gets wet, take the following precautions to maintain your camera in good working order.
  • Page 58 They may need more frequent replacement depending on use and wear. If the gaskets are damaged or need replacement, contact your nearest Olympus service center. If you are taking pictures at the beach, you need to avoid getting sand on or inside of your camera.

  • Page 59: Specifications

    38 ~ 80 mm zoom lens. Film format: 35 mm standard DX- coded film (24 x 36 mm). Lens: Olympus lens 38 ~ 80 mm F4.5 ~ 8.9, 5 elements in 4 groups. Shutter: Programmed electronic shutter.
  • Page 60 Focusing: Active-type multi- beam autofocus system. Focus lock possible. Focusing range — 0.6 m (2 ft ) ~ (infinity). Fixed at (infinity) in mode. Exposure control: Programmed automatic exposure control, 2-zone light metering. Auto exposure range: Wide angle —EV 2.4~EV 16; Telephoto —...
  • Page 61 Remote control (optional): Infrared remote control unit with approx. 3-sec. delay. Film speed range: Automatic setting with DX-coded film with ISO 50, 100,200,400, 800, 1600 and 3200. Film speeds other than above will be automatically set to next lower speed. For non- DX-coded film and film with less than ISO 50, film speed is set to ISO 100.
  • Page 62 Film loading: Automatic loading. (Automatically advances to first frame when camera back cover is closed.) Film advance: Automatic film winding. Film rewind: Automatic film rewind (automatic rewind activation at end of film, automatic rewind stop). Rewind possible at any point with rewind button.
  • Page 63 Flash: Built-in flash. Recycling time: Approx. 0.5 - 7 sec. (at normal temperature with new battery). Flash working range: Wide angle — 0.6 - 4.4 m (2 ~ 14.4ft)/ Telephoto — 0.6 ~ 2.2 m (2 - 7.2 ft) with ISO 100 color negative film;...
  • Page 64 Battery check: Displayed on LCD panel. Power source: One 3 V lithium battery (DL123A/CR123A). Dimensions: 115 (W) x 59.5 (H) x 39.5 (D) mm (4.5x2.3x1.6 in) (without grip and other protrusions). Weight (without battery): Non- QUARTZDATE/DLX models — 180g(6.3oz). QUARTZDATE/DLX models —...
  • Page 65 SPECIFICATIONS FOR DATE UNIT Imprinting direction: Data imprinted onto film from lens side. Data coding: No data, year- month-day, month-day- year, day-month-year and day-hour-minute. External indication of data: Data display on LCD panel Film speed setting: Automatic film speed setting. Automatic calendar system: Up to year 2030.
  • Page 66 SPECIFICATIONS FOR RC-200 REMOTE CONTROL (optional) Type: Infrared type remote control. Operating range: Approx. 5 m (16.4ft). Battery: One CR1220, replaceable; service life — approx. 5 years or approx. 20,000 operations. Dimensions: 32 x 44 x 13 mm (1.2 x 1.7 x 0.5 in). Weight: 11 g (0.4 oz) (without battery).
  • Page 67 OLYMPUS OPTICAL CO.,LTD. San-Ei Building, 22-2, Nishi Shinjuku 1-chome, Shinjuku-ku, Tokyo, Japan.Tel. 03-3340-2211 OLYMPUS AMERICA INC. Two Corporate Center Drive, Melville, NY 11747-3157, U.S.A. Tel. 516-844-5000/1-800-622-6372 OLYMPUS OPTICAL CO.(EUROPA) GMBH. (Premises/Goods delivery) Wendenstrasse 14-16, 20097 Hamburg, Germany.Tel. 040-237730 OLYMPUS OPTICAL CO.(U.K.) LTD. 2-8 Honduras Street, London EC1YOTX, United Kingdom.Tel. 0171 -253-2772 This device complies with part 15 of the FCC Rules.
