Summary of Contents for Nederman TL2M
- Page 1 Steel Belt Conveyor TL2M Manufacturing No. _____________________ Order No. _____________________________ No. 1426007 INSTRUCTION MANUAL E 2009-0610...
-
Page 2: Table Of Contents
Contents Foreword ....................2 Guarantee ..................... 3 Safety regulations ..................4 Operation ....................5 Installation ....................5 Maintenance instruction ................6 Belt tightening .................... 6 Belt disassembly ..................7 Lubrication ....................8 Trouble-shooting ..................8 Spare parts list .................... 9 Drawing ...................... -
Page 3: Foreword
Foreword ARBOGA-DARENTH Conveyors guarantee good design, quality components and skilled labour plus years of experience in swarf handling and swarf crushing. All these abilities have been used to design a product with high reliability and long service life. We are convinced that your expe- riences will confirm your choice of ARBOGA-DARENTH Swarf Conveyors. -
Page 4: Guarantee
Guarantee All products from ARBOGA-DARENTH are guaranteed free from any fault in material and labour during a period of one year. One year consists of 365 calendar days or 1800 hours which ever occurs first. The guarantee period for our products starts the day the equipment is sent to the client and continues during one year as earlier described. -
Page 5: Safety Regulations
Safety regulations • Electrical installations have to be done by qualified personnel only. • At connection of voltage feed as well as at service and maintenance work on the conveyor the circuit breaker must be off. • Test the emergency stop at installation and always when maintenance and service have been done. -
Page 6: Operation
Operation ARBOGA Hinged Steel Belt Conveyors are designed to handle a variation of material in different shapes and forms. They can convey short, long or curley swarf, dry as well as wet. They can also convey parts. Ask ARBOGA-DARENTH! The conveyor consists of the following main components: ... -
Page 7: Maintenance Instruction
Maintenance instruction After approx. 3 months operation in one shift, the conveyor shall be checked. The following items shall be special attended. 1) Belt tension. 2) The chain and its position in the frame. 3) The rollers. It can be necessary to retighten the belt. The frame and the chain should be checked for eventual excessive wear. -
Page 8: Belt Disassembly
Belt disassembly Disassembly of the hinged belt can be done for two reasons: • To replace damaged parts. • Cleaning and maintenance of the conveyor trough. Hinged belt The belt is to be disassembled in the following order: 1. Loosen the screws (16) on the bearing plate (8) and the motor plate (5). 2. -
Page 9: Lubrication
Lubrication Gear The gear manufacturer's specifications are to be followed (see enclosure). NB! Some gears are delivered without oil. It is in these cases fully marked on the gear. The manufacturer's specification is valid. Drive The drive shaft bearings are to be greased every 6th month. Pulley wheel shaft bearing When pulley wheel shaft bearings are used the shaft bearings are to be greased every 6th month. -
Page 10: Spare Parts List
Spare parts list NB! When ordering spare parts, please specify the following data: - Type - Designation - Serial number - Article number Article No. Denomination 980201 End cover 980275 Bend 30° 980274 Bend 45° 980241 Bend 60° 9002506 Tightening holder 900204 Motor plate 900203... -
Page 11: Drawing
Drawing...
