EXTREME CCTV WZ Series Installation Manual

Important

Please read this document carefully before installation and initial use. Keep for future reference.

• An unregulated power supply can cause damage to the camera. The use of an unregulated power supply with this camera will void

the product warranty.

• Do not attempt to disassemble the camera to gain access to the internal components. Refer servicing to Extreme CCTV.

• It is recommended that the camera be used with a monitor that has a CCTV quality 75Ω video impedance level. If your monitor is

switched to a high impedance level, then please adjust accordingly.

• Never direct the camera towards the sun or any bright or reflective light. Doing so may cause smearing on the picture and possible

damage to the CCD

• Do not open or modify

• Do not put objects inside the unit. Make sure that no metal objects or flammable substances enter the camera. This may cause fire,

short-circuits and other damages.

• Be careful when handling the unit. To prevent damage, do not drop the camera or subject it to strong shock or vibration.

• Install the camera away from electric or magnetic fields.

• Protect the camera from humidity and dust.

• Do not subject the unit to high temperature. Be careful when installing close to ceilings, in a kitchen or a boiler room as heat rises

and will affect the camera.

• Dirt can be removed from the camera by wiping it with a clean soft moistened cloth and soft detergent solution.

• The mounting surface material must be strong enough to secure the camera.

Before sending the camera for repair, check the questions below. If the problem still persists, contact Extreme CCTV.

If no image appears

• Is the coaxial cable firmly attached?

• Is power and voltage at a normal level?

• Is there adequate illumination?

Installation Guide

WZ18-NV312-0

If the image is unclear

• Is the lens in focus?

• Is the lens dirty?

• Is the monitor correctly adjusted?

Table of Contents

Do you have a question about the WZ Series and is the answer not in the manual?

Page 1 • Do not attempt to disassemble the camera to gain access to the internal components. Refer servicing to Extreme CCTV. • It is recommended that the camera be used with a monitor that has a CCTV quality 75Ω video impedance level. If your monitor is switched to a high impedance level, then please adjust accordingly.
Page 2 Increase the separation between the equipment and receiver • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected • Consult Extreme CCTV for technical support. Camera Specifications Contact Information Part Number WZ18-NV312-0 Extreme CCTV Inc.
