- Page 1 Racks P7C Controller – HI tecnologia The content of this document is part of P7C User Manual (PMU1070011). The Notes and Acronyms full list is at the complete version of the manual. To get it, please, access: www.hitecnologia.com.br...
-
Page 2: Technical Specifications
User Manual - P7C Controller Technical Specifications Presentation programmable controllers line was developed for attending machine and process control ap- plications. This PLC has up to 368 I/O points at its full configuration and offers all the others HI con- trollers versatility, including also new and exclusive features. -
Page 3: Applicable Standards
User Manual - P7C Controller Applicable Standards controller was developed for attending CE certification requirements, being adherent to the standards defined by IEC61131-2. According to the criterion defined by IEC61131-2, the equipment is able to operate on the named “Zone B”, attending to the specification of the following standards:... - Page 4 User Manual - P7C Controller Humidity ≤90% without condensation Rack weight 0,5 Kg Aluminium and Carbon Steel Protection Degree IP30 Dimensions 110 (W) x 110 (H) x 115 (P) mm Maximum number 5 expansion racks Racks connection The expansion racks must be connected to the right side of the main rack. In the case of adding...
- Page 5 User Manual - P7C Controller Supply The power supply connector is a spring connector that does not need a screw to be tightened. To insert the wire in the terminal block , use a screw-driver at the smaller hole (as indicated by A, at the following picture).
- Page 6 User Manual - P7C Controller IMPORTANT: The main Rack MRK AC power supply can be from 85 to 265 VAC or 100 to 400 VDC. The main Rack MRK DC power supply can be from 10 to 36VDC. We recommend the use of a rigid or flexible 2,5mm2 wire (7mm stripped) or flexible 1,5mm2 wire with eyelets terminal.
- Page 7 User Manual - P7C Controller Note: The modules can have lever connectors (for the new modules) or screw connectors. Termination Module – BBT260 The termination module must be, obligatorily, connected to the last expansion rack or, if it does not exist, then it must be connected to the main rack.
-
Page 8: Dimensions (Mm)
User Manual - P7C Controller Removing the rack from trails To remove the rack from the trail, just push it to the top (as indicated by number 1, at the picture) and also move it to the front (as indicated by number 2, at the picture):...
