LitAIR - SmartPro
Model BTS2003
USER GUIDE
www.litiscool.com
----------------------------------------------------------------------------------------------------------
AirPod Pro Case with Anti-lost and Touch Gesture Remote Control Functions.
Description
LitAIR is Bluetooth enabled AirPod Pro protective leather case with touch sensor. It operates with
simple touch gesture inputs on the front surface of the device and mobile App. It remotely
controls media playback of mobile devices, allows you to remotely accept incoming call on your
smartphone, and remotely control turn on/off and shutter release of your smartphone camera.
When it's connected to e-book or notebook through Bluetooth, you can navigate pages or
presentation slides from up to 10~15 meters(32~49 fts). When a connected smartphone and
LitAIR are out of Bluetooth range, internal haptic motor vibrates and/or buzzer alarms. LitAPP,
available on the Google Play Store or the Apple App Store, works with LitAIR and makes it easy to
use as well as offering extended features.
Touch
Sensing
Area
Front View
Right View
Button for Power ON/OFF,
Bluetooth Pairing and Mode
Switching
Left View
Lightning Port
Advertisement
Summary of Contents for LitAIR SmartPro
- Page 1 LitAIR are out of Bluetooth range, internal haptic motor vibrates and/or buzzer alarms. LitAPP, available on the Google Play Store or the Apple App Store, works with LitAIR and makes it easy to use as well as offering extended features.
- Page 2 Lighting charger, then press Power ON/OFF switch again. Press the button for 3 seconds: Power ON Bluetooth Connection After unboxing LitAIR and turn on power, it automatically enters Bluetooth pairing mode.. For manual pairing, press Power button 3 times consecutively.
- Page 3 Bluetooth Anti-Lost Anti-Lost is activated when LitAIR is connected to a smartphone through Bluetooth. If those connected devices are out of Bluetooth connection range, both LitAIR and the smartphone respond and generate alarm signals. If LitAPP was running at that time, it locates the disconnection spot on a map.
- Page 4 Touch function 1. Keep touching ‘Lit’ logo on the front of LitAIR for 3 seconds, then Touch function is disabled and LED color changes to white. 2. Press ON/OFF button on the side, then Touch function is enabled. .
- Page 5 Swipe Left/Right, Scroll Up/Down, Double Tapping Swipe/Scroll and then Hold Palm Touch LED Color/Blinking Assignment to the Operation Blue Green Sky Blue Yellow White Bluetooth Blinking Disconnected slowly Bluetooth Pairing Blinking Mode Low Battery Blinking Battery Charging Fully Charged Touch Input Blinking Detected Multimedia Mode...
- Page 6 Function and Operation by OS Android Multimedia/ Mode Camera Presentation Call Receive Play/Pause, Double Tapping Shooting Once Begin Slide Show Accept Call Receive Scroll Up One Step Volume Up Shooting Once First Slide Continuous Volume Scroll Up and then Hold Continuous Shooting One Step Volume Scroll Down...
- Page 7 Swipe Right and then Hold Fast Forward Fast Forward Swipe Left Previous Music Previous Slide Swipe Left and then Hold Rewind Rewind Charging LitAIR Connect a Lightning charger to the Lightning port on the side. It charges both LitAIR and AirPod Pro simultaneously.
- Page 8 Wireless Charger Connect a Lightning charger to the Lightning port on the side and charge LitAIR and AirPod Pro simultaneously. Bluetooth Wireless charger charges AirPod Pro only. Bluetooth 4.2 LE Bluetooth wireless range: Max 10~15m(32~49 fts). Frequency: ISM Band 2.4GHz OS compatibility: Android, Windows, iOS &...
- Page 9 Certifications KC: R-R-btu-BTS2003 TELEC: R210-126452 FCC: 2ASN3BTS1801 CE: CTS-R19-0025 FCC Warning Statement FCC Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 10 Additional Features included in LitAPP Compatible with Android and iOS Battery status, Bluetooth signal strength Operation mode switching One-touch App activation Finding my smartphone, Finding my Lit ZERO Music info reader Smartphone feedback setting Lit ZERO disconnection alarm Alarm setting Package Contents LitAIR_Smart_Pro Non-woven fabric envelop...
