Summary of Contents for Juggernaut RAPTOR
- Page 1 RAPTOR MANUAL...
- Page 2 GENERAL OPERATION SECTION 1: IMPORTANT SAFE OPERATION PRACTICES SECTION 2: FIND OUT MODEL AND SERIAL NUMBER SECTION 3: AFTER SALE SERVICE SECTION 4: OPERATING RANGE SECTION 5: ASSEMBLY SECTION 6 : CONTROLS AND OPERATING SECTION 7 : MAINTENANCE SECTION 8 : OFF-SEASON STORAGE SECTION 9 : TROUBLE SHOOTING GUIDE...
-
Page 3: General Operation
GENERAL OPERATION GENERAL OPERATION PRACTICE PREPARE · Read this owner’s guide carefully in its entirety before attempting to assemble this machine. Read, · Thoroughly inspect the area where the equipment is to be used. Remove all stones, sticks, wire, understand, and follow all instructions on the machine and in the manuals before operation. Be bones, toys and other foreign objects which could be picked up and thrown by the scarifer in any completely familiar with the controls and the proper use of this machine before operating it. - Page 4 GENERAL OPERATION GENERAL OPERATION SAFETY PETROL ENGINE · Do not operate the scarifier while under the influence of alcohol or drugs. · Shut the engine off and wait until the blade comes to a complete stop before removing the grass catcher or unclogging the chute.
- Page 5 SLOPE OPERATION · Never run an engine inside a closed area. · If the slope is greater than 15 degrees as shown on the slope gauge, do not operate this scarifier on that area or serious injury could result. · To reduce fire hazard, keep scarifier free of grass, leaves, or other debris build-up. Clean up oil or fuel spillage.
-
Page 6: Important Safe Operation Practices
SECTION 1: IMPORTANT SAFE SECTION 2: FIND OUT MODEL AND SERIAL NUMBER OPERATION PRACTICES Data brand shows this scarifier’s model and serial No. on the chassis of the scarifier. WARNING: THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH, IF NOT FOLLOWED, COULD ENDANGER THE PERSONAL SAFETY AND/OR SECTION 3: AFTER SALE SERVICE PROPERTY OF YOURSELF AND OTHERS. - Page 7 FOLLOW STEPS 1 THROUGH 3 TO ASSEMBLE YOUR RAPTOR STEP 1 STEP 3 LIFT UPPER HANDLE PUT NUT INTO THE SLOTS OF KNOB NUT, USING BOLT FIX UPPER AND LOWER HANDLE. STEP 2 ALIGN UPPER HANDLE WITH LOWER HANDLE...
-
Page 8: Controls And Operating
SECTION 6: CONTROLS AND OPERATING TO START ENGINE AND ENGAGE BLADE WARNING: Keep hands and feet away from the chute area on the cutting deck. · Attach spark plug wire to spark plug. Make certain the metal cap on the end of the spark plug wire The operation of any scarifier can result in foreign objects being thrown into the eyes, is fastened securely over the metal tip on the spark plug. -
Page 9: Maintenance
SECTION 6 TO STOP ENGINE AND BLADE SECTION 7: MAINTENANCE Release the flywheel brake lever to stop the blade and switch off the engine’s WARNING: Always stop engine and disconnect spark plug wire before cleaning, lubricating flameout button to stop the Scarifier. or doing any kind of service work on the scarifier. -
Page 10: Off-Season Storage
BLADE SHAFT LUBRICATION WARNING: Always stop engine and disconnect spark plug wire before cleaning, lubricating The inside blade shaft should be cleaned after each use .If not, it will cause rust and corrosion , and increase the engine ‘s burden. After pulling out spark plug, can use wood chip, or other tool to or doing any kind of service work on the scarifier. -
Page 11: Troubleshooting Guide
TRANSMISSION TYPE BELT CUTTING WIDTH (MM) CUTTING DEPTH (MM) 0-25 MEASURED SOUND PRESSURE 82.9DB(A) LEVEL AT OPERATOR’S EAR LPA MEASURED SOUND POWER 93.85DB(A) LEVEL LWA K=3DB(A) GUARANTEED SOUND POWER 97DB(A) LEVEL LWA VIBRATION 5.389M/S2 K=1.5M/S2 BJC TOOLS OFFICIAL IMPORTER OF JUGGERNAUT...
