Alfaled AFT-20 Quick Start Manual

W all Mounted Touch Panel
Model No.: AFT-20, AFT-20-1, AFT-20-2, AFT-20-3
1-4 Zone dimming sw itch/ Glass touch panel/ W ireless remote 30m distance/ AAA x 2 battery
AFT-20-1
1 Zone sw itch

Features

● Touch panel 1/ 2/ 3/ 4 zone dimming sw itch RF remote.
● Each zone can remote control multiple receivers, including Alfaled's 2.4G LED controller, dimming driver or smart lamp.
● Ultra sensitive high strength glass touch panel.
●Touch keys w ith chord tones and LED indicator.
●Free installation, no w iring, removable.
● AAA x 2 attery pow ered.
b

Technical Parameters

Input and Output
Output signal
W orking voltage
W orking current
S tandby current
S tandby time
Remote distance
W arranty
W arranty
User Manual Ver 1.0.2 2018.11.01
AFT-20-2
2 Zone sw itch
RF 2 .4 GHz
( )
3 VDC A A A x 2
( )
＜2 0 mA
＜2 0 μA
1 y ear
3 0 m
5 y ears
www.alfaled.sk
AFT-20-3
3 Zone sw itch
S afety and EM C
EMC standard (EMC)
Safety standard(LVD)
Radio Equipment(RED)
Certification
Environment
Operation temperature
Case temperature Max.
(
IP rating
AFT-20
4 Zone sw itch
LVD RED
EN301 489,EN 62479
EN60950
EN300 328
CE,EMC,LVD,RED
Ta: -30 O C ~ +55 O C
)
Tc: +85 O C
IP20
Page 1
