Nest Cam Outdoor Installation Guide

In the box

The mounting magnet is very strong. Mind your fingers and keep it in the box until you're ready to use it.

What you'll need

Other items you may need

• Drill bit (3/32" for pilot holes. Or 7/32" if you're using wall anchors.)
• Ladder

No outdoor outlet?
You can plug Nest Cam Outdoor into an indoor outlet. This requires some extra steps, which may include drilling through your home's exterior wall. Keep in mind that you'll need to know where any in-wall pipes and wiring are.

Don't want to do it yourself?

Nest Cam Outdoor is designed for easy DIY installation, or you can hire a Nest Pro. They'll take care of the installation and make sure everything's up and running. Find a local Nest Pro at nest.com/install

Do this first

1. Turn on Nest Cam indoors
   Start by turning on your camera inside the house to get everything set up before you take it outside.
   Connect your Nest Cam's cable to the power adapter. Push and twist the USB connector into place. Then plug the adapter into a power outlet. Your Nest Cam will turn on and you'll see a blue light.


2. Add it to your Nest Account
   Download the Nest app from the App Store ® or Google Play ™. Open the app and tap "Sign up" to create an account. Then tap Add, choose Nest Cam and follow the instructions. If you already have a Nest Account: Tap the settings icon in the top-right corner of the app home screen. Then tap "Add product," choose Nest Cam and follow the steps. If you need help, go to nest.com/pair


3. Bring your camera outside
   Once you've added Nest Cam to your account, unplug it and take it to the spot you've chosen outdoors. Plug it into the outlet you want to use and wait for the green light to turn on. Nest Cam will reconnect to your Wi-Fi network automatically. This may take a minute or two. Keep Nest Cam plugged in for the rest of the installation.
   → See location tips on the next page.


4. Make sure it's streaming
   Before you mount the camera, make sure it can get Wi-Fi in the spot you've picked. Hold your Nest Cam where you'd like to mount it and check to make sure it's streaming video to the Nest app. If you don't see video, the Wi-Fi may not be strong enough there – you'll need to find a different spot or move your Wi-Fi router.


Choose a good spot

Avoid direct sunlight.
Nest Cam Outdoor is designed to operate between –4° and 104°F (–20° to 40°C). If it gets hotter or colder, image quality may be affected.

Keep it in range of your router.
Make sure to pick a place within range of your network. Thick or insulated walls can greatly reduce the strength of your Wi-Fi signal even if your router is close by, so you should try streaming video before you mount your camera. Learn more at nest.com/wifihelp

Consider the surroundings.
Is a post, plant or porch light blocking the view? It might throw off exposure, focus or Night Vision. If you start noticing glare, adjust the camera so the horizon is out of frame.

Place it up high.
But not too high. We find 7 to 10 feet above the ground, tilted downward, is best – close enough to see someone's face and talk with them through the camera. Check the video in the Nest app to make sure Nest Cam is seeing what you want to see.

Mount your camera

5. Place the mounting magnet
   Screw the wall plate onto your wall. It's a good idea to drill pilot holes first. If the wall is made of a material like brick or stone, you may need to use the included wall anchors to hold the screws. Next, put the magnet onto the wall plate. Got a magnetic surface nearby? The mounting magnet may be all you need. Just put it where you'd like the camera to be and move on to the next step.

   Tip: If the camera wall plate sticks to the mounting magnet, you can use a screwdriver to help pry them apart.
6. Attach the camera Put Nest Cam onto the mounting magnet and aim it where you like. Use the video stream in the Nest app to fine-tune your camera's position.


7. Mount the power adapter
   Before you mount the power adapter to the wall, take a minute to plan the route of the cable from your outlet to the camera. Be sure to leave some slack at both ends. We recommend installing the weatherproof adapter at least 18 inches above the ground in case of flooding or deep snow. Mount the adapter wall plate with the flat side flush to the wall. When that's done, snap the power adapter into place.


8. Secure the cable
   Fasten the cable to the wall using as many of the included cable clips as you need. It's a good idea to route the cable along a ledge or another hidden place, and you can paint it to match your house. Don't pull the cable too tight in case you want to adjust the camera angle later on.

   Tip: Some outdoor outlets have covers you can lock in place. Use a zip tie or padlock to keep the cover shut.

Safety

PLACEMENT GUIDELINES
To avoid risk of overheating and burns:
Use only in temperatures between –4° and 104°F (–20° to 40°C). Keep out of direct sunlight. Do not block airflow to Nest Cam.
To avoid risk of fire and shock:
Use only the provided USB cable and power adapter. Install in accordance with building and installation codes where you live. For example, if your desired electrical outlet is exposed to direct rain, the electrical code may require that the outlet have a while-in-use cover. We recommend using only an electrical outlet equipped with a ground fault circuit interrupter (look for "Test" and "Reset" buttons on your outlet).
To avoid risk of other serious injury: Keep camera and all components out of the reach of children and pets. If your Nest Cam is installed more than 6.5 feet (2 m) above the ground, make sure you've got a cable clip close to the camera head (19.5 inches or 50 cm from the base).
