Summary of Contents for EG4 EG4-LL
- Page 1 User Manual -LL 12v 400AH Copyright © 2023 EG4 Electronics, LLC. All rights reserved. Version 1.0.0 | Information subject to change without notice.
-
Page 2: Table Of Contents
BMS Tools Installation and Interfacing ..................14 4.4.1 Downloading and Installing BMS Tools ................14 4.4.2 Interfacing with BMS Tools ....................17 4.4.3 Interface menu definition ....................18 Installing and using EG4 Bluetooth App ..................19 Battery Charging ......................... 21... - Page 3 BMS Protection ........................21 Troubleshooting .......................... 22 5.2.1 Alarm Description and Troubleshooting ................22 Battery End of Life ........................24 EG4 Warranty ............................24 Warranty Exclusions ........................24 Technical Specifications ........................25 Technical Specifications Table ....................25 Battery Performance Curves ....................... 26...
-
Page 4: Safety
1 Safety 1.1 Safety Instruction Before any work begins, carefully read all safety instructions, and always observe them when working on or with the battery. The installation must follow all applicable national or local standards and regulations. Incorrect installation may cause: •... - Page 5 7. Never charge a battery below the specified minimum charging temperature or damage may occur. Please refer to this manual or spec sheet for charging parameters. DISCLAIMER EG4 reserves the right to make changes to the material herein at any time without notice. You may refer to the EG4 website at www.eg4electronics.com...
-
Page 6: Brief Introduction
The state of the battery when placed into storage will affect how long it can be stored as well as the battery’s condition when it is brought out of storage. EG4 recommends that each battery is brought to a 100% SOC (state of charge) before placing it in storage. Lithium iron phosphate batteries will lose a certain percentage of their total charge while in storage, depending on how long they are stored and the conditions they are stored in. -
Page 7: Requirements For Installation
3.2.2 Requirements for Installation Warning • Before using batteries, inspect them for signs of damage. Never use damaged or puffy batteries. Please contact the distributor if a battery is received in this state or experiences this issue. • Avoid exposing batteries to conductive materials, such as water, strong oxidizers, and strong acids. -
Page 8: General Installation
Tools needed for installation The tools required may vary depending on how you choose to mount your battery. Typically, the following items are needed to install the battery into an EG4 battery rack solution or general racking. 1. 13mm socket and ratchet 2. -
Page 9: Installation In Eg4 Battery Rack
Warning Do not ground rack/cabinet or door to negative or positive bus bars! In this image, there are 6 EG4-LL 12V 400Ah batteries wired in parallel. This battery bank still maintains the appropriate 12V needed for a system. However, the Amp hour rating of this bank has increased to 2400Ah. -
Page 10: Battery Overview
3.3 Battery Overview 3.3.1 System Connections An example system connection diagram with 12V Victron Phoenix Inverter Smart is as below: Note: During single-battery operation, the battery terminals can directly connect to the equipment. Overview of System Components This unit contains two aerosol fire-fighting modules inside the battery for safety... - Page 11 19-inch cabinet and communicates with external devices via CAN/RS485 as well as with other EG4 batteries via RS485. The modules can be connected in parallel to meet expansion requirements. Inter-battery communications support a maximum of 16 modules.
-
Page 12: Operation Guide
4 Operation Guide 4.1 Battery Communications Each EG4 battery is designed with you in mind, displaying as much To system information as possible in the simplest manner. EG4 Electronics includes the option of connecting the battery to PC software to monitor the module status. -
Page 13: Lcd Screen
DIP switch ID table 4.2 LCD Screen Each module has a built-in HD LCD touch screen used to display important information about the cells including voltage, current, temperature, SOC, and others. 4.2.1 Button description There are 4 function buttons below the display with detailed descriptions as shown in the table below. Description Down Return... -
Page 14: Cell Information
4.2.3 Cell information Check individual cell voltage by pressing the “Enter” button on the main page (shown in mV). There are 2 pages. Pressing “Up” and “Down” changes the page. Note: 12V module only displays 4 cells due to 4 packs being in parallel (4s4p config.). -
Page 15: Bms Tools Installation And Interfacing
3. On the host battery, press and hold Enter for 5 seconds to enter the “Protocol Setting.” 4. Select the corresponding RS485 program or CAN program, and press Enter. Note: The only supported inverter protocol at this time is for 12V Victron systems. 5. - Page 16 2. Once downloaded, locate the file. (This is typically in the Downloads folder.) 3. Right click on the folder and click “Extract All.” Verify the location the file will be extracted to for future reference. Check the box “Show extracted files when complete” and click on “Extract.”...
- Page 17 4. Open the folder to access BMS_TOOLS. Right click and click “Run as administrator.” You may see a popup for Microsoft Defender appear. Click “More info,” and then click “Run anyway.” 5. You will be brought to the main page of BMS Tools.
-
Page 18: Interfacing With Bms Tools
4.4.2 Interfacing with BMS Tools 1. While all power is off, set the DIP switch ID address of the battery to Address 16. 2. Connect your USB cable to your PC and to the RS485 port on the battery. 3. Power on the battery. 4. -
Page 19: Interface Menu Definition
5. Open BMS Tools. Under “Monitor Status,” verify “COM” matches the battery COM from the previous “Ports” list. Verify “Baud Rate” is set to 9600, and “PACK ID” is set to 16, then click “SearchDevice.” After about 30 seconds, BMS Tools will begin the monitoring process and pull real-time data from the BMS. -
Page 20: Installing And Using Eg4 Bluetooth App
Record of sending and receiving of battery pack data (exportable) Software configuration, settings, and language selection Software Parameter (restricted, unauthorized changes will void warranty) 4.5 Installing and using EG4 Bluetooth App 1. Download the app using the QR codes here. (You may need to enable “Allow install from unknown sources”... - Page 21 2. Power on the battery. When opening the app, it will immediately begin scanning for the Bluetooth ID located on the front right side of the battery. (See images below.) Note: Users may need to scroll down through the list of devices to find the battery ID, as the app can pick up any Bluetooth signal...
-
Page 22: Battery Charging
This protection also aids in keeping the battery and battery cells operational for a greater number of life cycles. Each EG4-LL battery is specifically configured to ensure peak performance and operation with any system. -
Page 23: Troubleshooting
Environmental temperature protection It may be dangerous to attempt using the battery in extreme heat or cold. Continued operation in these conditions may result in permanent damage to the battery module and its components. To prevent this, the BMS is designed to measure the temperature while charging/discharging and will shut down the battery to prevent damage. - Page 24 Protect Float Stoped Float Stopped Contact the distributor Discharge current is too high, turn BMS and Protect Discharge SC Discharge short-circuit breaker off and back on to reset. Lower loads Helpful tip The “Historical Record” tab can indicate what occurred with the module before entering a warning or protection state.
-
Page 25: Battery End Of Life
5.3 Battery End of Life The EG4-LL 12V battery is designed to last for more than 15 years when used correctly. We have worked tirelessly to ensure that our batteries will maintain a charge after thousands of cycles. However, when it does come time to retire the battery, there are a few things to consider. -
Page 26: Technical Specifications
All installation advice provided by EG4 before, during, or after purchase of solar equipment is purely for the purpose of general concept education and must not replace the expertise of a licensed and trained solar specialist. -
Page 27: Battery Performance Curves
Sleep & Off Mode <300uA Storage/Transport/Standby Power Consumption Operating Mode <14mA Charging/Discharging Communication Ports RS485/CAN Bus Bluetooth Monitoring Customized EG4 App Physical Specifications Dimensions (H×W×D) 6.1 in.×19 in.×20.2 in. (15.5 cm×48.2 cm×51.3 cm) Weight 98.1 lbs. (44.5 kgs) 7.2 Battery Performance Curves... - Page 29 Notes...
