300522
TH2BCMP
58210
MANUAL
THIESSENS.COM
2 BURNER CAMP STOVE
WITH FOLDING SIDE TABLE
IMPORTANT, READ CAREFULLY, RETAIN FOR FUTURE
REFERENCE. MANUAL MUST BE READ BEFORE OPERATING!
FOR OUTDOOR USE ONLY. NOT FOR COMMERCIAL USE.
FUEL AND ACCESSORIES NOT INCLUDED.
WARNING: PLEASE READ THE ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS
GAS APPLIANCE. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN PROPERTY
DAMAGE, BODILY INJURY OR EVEN DEATH. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT
RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA.
Advertisement
Table of Contents
Summary of Contents for THIESSENS TH2BCMP
- Page 1 2 BURNER CAMP STOVE WITH FOLDING SIDE TABLE IMPORTANT, READ CAREFULLY, RETAIN FOR FUTURE REFERENCE. MANUAL MUST BE READ BEFORE OPERATING! 300522 TH2BCMP 58210 FOR OUTDOOR USE ONLY. NOT FOR COMMERCIAL USE. FUEL AND ACCESSORIES NOT INCLUDED. MANUAL WARNING: PLEASE READ THE ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS GAS APPLIANCE.
-
Page 2: Propane Gas Warnings
ALWAYS CHECK FOR GAS LEAKS WHEN YOU CONNECT AND DISCONNECT THE REGULATOR TO THE GAS CYLINDER, ESPECIALLY AFTER A PERIOD OF STORAGE (FOR EXAMPLE, OVER WINTER). CHECK ALL CONNECTIONS FOR LEAKS WITH A SOAPY WATER SOLUTION AND BRUSH. NEVER USE AN OPEN FLAME TO CHECK FOR LEAKS. THIESSENS : Authentic Pur suit Equipment... -
Page 3: Dangers & Warnings
ANS Z223.1/NFPA 54, STORAGE AND HANDLING OF LIQUEFIED PETROLEUM GASES, ANS/NFPA 58; OR NATURAL GAS AND PROPANE INSTALLATION CODE, CSA 8149. 1; PROPANE STORAGE AND HANDLING, CSA 8149.2; OR THE STANDARD FOR RECREATIONAL VEHICLES, ANS A119.2/NFPA 1192, AND RECREATIONAL VEHICLE CODE, CSA Z240 RV SERIES, AS APPLICABLE. www.thiessens.com... -
Page 4: Table Of Contents
AUTOMATIC LIGHTING PROCEDURE ......10 MANUAL LIGHTING PROCEDURE ......10 SHUTTING OFF YOUR UNIT ........11 COLLAPSING FOR TRANSPORT ....... 11 CARE AND MAINTENANCE ........12 TROUBLESHOOTING ..........13 REPLACEMENT PARTS ..........14 WARRANTY ............15 THIESSENS : Authentic Pur suit Equipment... -
Page 5: Parts And Specs
PARTS AND SPECS PART DESCRIPTION TH2BCMP MODEL Support Frame A (x1) Support Frame B (x1) ASSEMBLED 66.9 x 24.8 x 36.9 in. Bracket A (x1) (L x W x H) (170 x 63.2 x 93.8 cm) Bracket B (x1) Side Table (x1) WEIGHT 56.8 lb... -
Page 6: Assembly Preparation
Mount Bracket A and Bracket B to the left side of the Side Table (handle Table Bracket to the left side of the Stove Body using four screws, as faces the front) using two screws in each Bracket, as shown. shown. THIESSENS : Authentic Pur suit Equipment... - Page 7 Stove Body top. If ground is uneven, rotate the bottom half of each Support Leg to adjust the height. Adjustment variant is up to 1.5 inches / 38 mm. Assembly of unit is now complete. www.thiessens.com...
-
Page 8: Gas Cylinder Requirements
OPENING AND THE TOP OF THE GAS CYLINDER. SAVE THE CAPS. INSERT THE GAS CYLINDER VALVE INTO THE THREADED OPENING OF THE REGULATOR VALVE. TURN THE QUICK COUPLING NUT CLOCKWISE UNTIL FIRM. HAND-TIGHTEN ONLY. GAS CYLINDER IS NOW INSTALLED. PERFORM A LEAK TEST. THIESSENS : Authentic Pur suit Equipment... -
Page 9: Preparation For Use - Leak Testing
WARNING: IF STORING THE UNIT INDOORS, LEAVE THE GAS CYLINDER OUTDOORS. DO NOT FOLD UP OR TRANSPORT UNIT WITH GAS CYLINDER ATTACHED. THE CYLINDER MAY LOOSEN OFF THE VALVE AND CAUSE A GAS LEAK, POSSIBLY RESULTING IN AN EXPLOSION, FIRE, OR SEVERE BODILY HARM. DISCONNECT GAS CYLINDER FIRST BEFORE TRAVEL OR STORAGE. www.thiessens.com... -
Page 10: Automatic Lighting Procedure
WITH ALL OUTDOOR APPLIANCES, OUTSIDE WEATHER CONDITIONS PLAY A BIG PART IN THE PERFORMANCE OF YOUR UNIT AND THE COOKING TIME NEEDED TO PREPARE YOUR MEALS. ALL THIESSENS UNITS SHOULD KEEP A MINIMUM CLEARANCE OF 3 M (10 FEET) FROM COMBUSTIBLE CONSTRUCTIONS, AND THIS CLEARANCE MUST BE MAINTAINED WHILE THE UNIT IS OPERATIONAL. -
Page 11: Shutting Off Your Unit
MOVE THE CAMP STOVE TO DESIRED LOCATION, OR TO VEHICLE FOR TRANSPORT, IMMEDIATELY TO AVOID INJURY TO YOURSELF OR DAMAGE TO THE UNIT. IMPORTANT: TAKE SPECIAL CARE OF THE REGULATOR AND HOSING AS YOU COLLAPSE AND TRANSPORT THIS UNIT. www.thiessens.com... -
Page 12: Care And Maintenance
BURNER TUBE, PORTHOLES EVERY 5-6 USES DUST, SCRUB PAD & SOAPY WATER BURNERS EVERY 5-6 USES SCRUB PAD & SOAPY WATER SIDE TABLE, SUPPORT FRAME, AS NEEDED NON-ABRASIVE CLOTH & SOAPY WATER SUPPORT LEGS THIESSENS : Authentic Pur suit Equipment... -
Page 13: Troubleshooting
REGULATOR VALVE IS OFF CHECK THE REGULATOR VALVE CONNECTION TO THE GAS CYLINDER. REMOVE, THEN REINSTALL. PERFORM LEAK TEST. BURNER IS DIRTY TURN REGULATOR KNOB TO HIGH FOR FIVE MINUTES, AND BURN-OFF THE UNIT. FOLLOW CARE AND MAINTENANCE INSTRUCTIONS. www.thiessens.com... -
Page 14: Replacement Parts
Regulator With Hose (x1) Control Panel (x1) Control Knob Bezel (x2) Control Knob (x2) Front Cover (x1) Screw (x12) Step Screw (x2) NOTE: Due to ongoing product development, parts are subject to change without notice. THIESSENS : Authentic Pur suit Equipment... -
Page 15: Warranty
CONDITIONS ALL GAS CAMP STOVES BY THIESSENS, MANUFACTURED BY DANSONS, CARRY A LIMITED WARRANTY FROM THE DATE OF SALE BY THE ORIGINAL OWNER. THE WARRANTY COVERAGE BEGINS ON THE ORIGINAL DATE OF PURCHASE AND PROOF OF DATE OF PURCHASE, OR COPY OF ORIGINAL BILL OF SALE, IS REQUIRED TO VALIDATE THE WARRANTY. - Page 16 CONTACT CUSTOMER CARE IF YOU HAVE ANY QUESTIONS OR PROBLEMS, CONTACT CUSTOMER CARE. WWW.THIESSENS.COM | TOLL-FREE: 1-877-972-5742 MADE IN CHINA WARNING: COMBUSTION OF PROPANE GAS CAN EXPOSE YOU TO CHEMICALS INCLUDING FORMALDEHYDE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER, AND CARBON MONOXIDE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM.
