- Page 1 ENGLISH CM4UFX 4+1 CHANNEL DJ CLUB MIXER WITH DSP EFFECTS...
- Page 2 PAGE 2...
-
Page 3: Product Description
CM4UFX - CLUB SERIES PROFESSIONAL MIXERS OPERATION MANUAL INTRODUCTION Dear customer, Congratulations on the purchase of this quality mixing desk. To meet your requirements, this unit has been designed and built to the highest standards, so that we can assure you that you have made a good and satisfying investment. To take full advantage of all possibilities and for your own safety and the safety of your environment, please read these operating instructions carefully before you start using the unit. -
Page 4: Environmental Advice
PROTECTION FROM ELECTRIC SHOCK 1. Only connect this unit to a mains socket outlet with protective earth connection, ground-fault (earth-fault) protection and overload protection. 2. Where the mains plug or an appliance coupler is used as a dis-connect device, the disconnect device shall remain readily operable. -
Page 5: Back Panel
CM4UFX - CLUB SERIES PROFESSIONAL MIXERS UNPACKING Please check that the box contains the following items: Main parts: 1 pcs. Main unit 1 pcs. Mains cable 1 pcs. Operation manual If any part is missing, please contact your dealer immediately for replacement. -
Page 6: Top Panel
TOP PANEL 12. Microphone input for DJ MIC (MIC1). This is a balanced Combo (XLR+TRS) connector without phantom power provision, hence only suitable for dynamic microphones. Please note that MIC2 can only be connected from the rear panel connector (10). 13. -
Page 7: Effects Section
CM4UFX - CLUB SERIES PROFESSIONAL MIXERS 20. Crossfader assignment switch. Allows to route the respective channel either to X (left crossfader side) or to Y (right crossfader side) or directly to the master. 21. Channel fader for input channels. A high-grade dual rail 60mm fader determines the volume of the respective channel. - Page 8 EFFECTS AND THEIR PARAMETERS Name Effect Parameter Rate/Frequency Intensity Control Flanger Comb Filter 1 LFO Rate Manual Rate Speed (33 steps: 16 steps up and Sweep width speed down, 15 to 960 BPM, starting from median (33 steps: 16 up and 16 down from step “0”...
-
Page 9: Operation
CM4UFX - CLUB SERIES PROFESSIONAL MIXERS OPERATION Apart from using good equipment, good sound comes from using it correctly. Level setting mistakes are one of the common reasons why even good equipment may not perform as desired. For setting levels, please be reminded that two guidelines need to be followed: 1. - Page 10 CLUB SERIES PROFESSIONAL DJ MIXERS ww w.vi va a fr ika .co.za...
