Summary of Contents for FunTech Innovation Innex Cube
- Page 1 AI 360° 4K Conference Cam Quick Start Guide...
-
Page 2: Package Contents
AI algorithms capable of tracking multiple people simultaneously. Creating the most immersive conference experience from the table center, Innex Cube captures video and audio from a close distance, at the eye-level from a natural frontward angle. A patented real-time stitching algorithm technology stitches four high resolution sensors together to produce an ultra-clear and undistorted video. - Page 3 Overview Cameras Front Arrow IR Receivers Mode Switch USB Type-C Port Camera Off 1/4 Tripod Screw Hole Microphone Off Microphones LED Indicator...
- Page 4 Additional Pole (male-female) 30 cm 42 cm Pole (male-female) Pole (male-male) Wooden Base Pole Storage Kensington Nano Security Slot Back Velcro Cable Tie...
- Page 5 Remote Control Button Description Function Press to turn off and Camera on/off turn on the video Microphone Press to mute and on/off unmute the microphone Adjust the position of Arrow Keys the field of view Okay Confirm Get into AI mode or AI mode AI setting Get into manual mode or...
-
Page 6: Getting Started
1. Assemble Innex Cube with 2 or 3 poles. With an effective coverage within a 2.5 meter detection radius and a 2. Connect the USB cable. Plug the USB-C end to Innex Cube and USB-A number of 12 people, AI modes are recommended to be used in small- end to a USB3.0 port of your computer. - Page 7 AI Dedicated Focus AI Stage Stage Area 90° FOV Front Dedicated focus mode creates a close-up shot (a box) for each person. If Stage mode auto-frames the presenter(s) in the stage area (area that is 180° centered on front arrow direction) and displays it at the upper portion two or more people are sitting close to each other, they will be merged into while showing the back 180°...
- Page 8 Manual 360° Panorama In the Manual modes, users can conveniently control the FoV and the direction of the video. Below is a summary of the available control in the different modes. Manual Mode E-Pan Left / Right E-Tilt Up/Down Conversation 360°...
- Page 9 2.5 m 2.5 m Room Size: Medium to Large Room Size: Medium to Large Table Type: Rectangular long table. Table Type: Rectangular long table. Participants: 8 to 12. Sitting horizontally to the display. Eyes on the Participants: 8 to 12. Sitting vertically to the display. Eyes on the presenter more.
-
Page 10: General Settings
General Settings Apply Ignore Zone Under the AI Modes Ignore Zone Setting Dedicated Focus When the Ignore Zone is set, under Dedicated Focus mode, Innex Cube will not detect the Language participants who sit in that area of the room. Anti-Flicker... - Page 11 Auto-Framing Language When the ignore zone is set, under Auto-Framing mode, Innex Cube will keep that area out of Switch and select the desired language. the frame. Stage Anti-Flicker When the Ignore Zone is set within Stage Area, under Stage mode, Innex Cube will not display Switch the frequency between 50/60 Hz to avoid flicker.
- Page 12 AI Mode Settings While in AI modes or setting, press to enter About AI Mode Settings Check the serial number and firmware version of the Innex Cube. Or restore factory setting. Dedicated Focus Auto-Framing Stage...
- Page 13 Dedicated Focus Stage Dedicated Focus outputs a close-up shot for each person, up to 8 boxes total. On-tracking is Stage auto-frames the presenter(s) in the stage area (180° centered on Front Arrow direction) selected by default and the AI constantly auto-tracks people in the scene. The preview of the and displays at the upper screen while showing the back 180°...
-
Page 14: Manual Mode Settings
Manual Mode Settings While in Manual modes or setting, press to enter Manual Mode Settings Conversation Conversation splits participants from two sides into two equal 180° views. Use the up/down/ left/right arrow keys to adjust the center of the view. The preview of the output is shown at the Conversation button right corner. -
Page 15: Specifications
Flicker 50Hz/ 60Hz Auto Exposure Auto White Balance 1. Dedicated Focus Mode 2. Stage Mode Camera Embedded 3. Conversation Mode Mode 4. Auto-Framing 5. Manual Mode 360°/ 270°/ 180°/ 120°/ 90° Microphone Microphone 2 Omnidirectional Microphones Automatic Gain Control (AGC) Active Noise Supression 270°/ 180°/ 120°/ 90°... - Page 16 FunTech Innovation Compliance. Important Safety, Compliance For Product Safety, EMC, RF and Energy information, go to www.funtechinnovation. and Warranty Information com/compliance Maintenance is not required for product compliance. This product complies with relevant legal requirements for Restriction of Hazardous *Read Manual Before Product Use* Substances (RoHS) and management of waste electronic and electrical equipment (WEEE).
- Page 17 ● To prevent the product from being damaged, do not use any types of USB cables to the point of purchase or such other place as FunTech Innovation may direct other than the one provided with the product or a USB certificated cable.
- Page 18 WARNING Do not touch the power cable with wet hands. Do not install the product in high temperature environments. ● Do not install the product near a heat source, such as a radiator, a heat reservoir, a stove or other heating products. ●...
- Page 19 Visit FTI website https://funtechinnovation.com...
