Hildebrand GlowStick Manual

Use the GlowStick & Shine App to see your
consumption, generation, import and export

Setting up Shine

Download the App

1. Go to the App or Google Play Store and search for Shine
It might be quicker to include 'Hildebrand' in your search
•
2. Install and open the app
3. Set up an account
Name: enter your name
•
Email: make sure you use a valid email address
•
Username: this is also an email address
•
Password: ensure this meets the criteria prompted by the app
•
Confirm password
•
Register
•
4. For security, you will need to verify your email address. We will send a 4-
digit code to your email address. (If you haven't received it, please check
your spam/junk folder as it may be there).
5. Enter the 4-digit verification code where prompted by the app
6. Login using your verified credentials

Associate your Glow Hub to your account

1. Once you have logged in you will need to 'Claim' your Hub.
2. The process is automatically prompted by Bright when you login
3. Select "Setup a new device"
4. Scan the MAC address and Serial Number on the back of the Hub
5. Press Next, then Claim my device
Setting up your GlowStick

Powering your GlowStick

1. Plug the stick into the power adapter included in the package
2. Then plug this into a power supply
WiFi
Transmitter
Solar PV Array
Make sure the the
arrows on the inside of
the clamps are facing
the same direction as
shown in these
instructions
Domestic Loads
Grid
1
3. When you first plug in the device, the lights
should be as follows:
Power: solid green
•
Transmitter: off
•
WiFi: flashing red
•
4. To complete setup, see page 3

Hardware installation

For Type II solar installations
Grid tie inverter
CT Clamp
CT Clamp
Fuse box
CT Clamp
IMPORTANT: Remove the protective
cap from the ports on the bottom of the
Utility meter
Transmitter and firmly insert the Clamp
cable jack. THEN insert the batteries.
Glowstick
Transmitter
3 2 1
Y-cable
2
