- Page 1 Installation & Operation Manual Full Inverter Pool Heat Pump Maxinverter-30S Thank you very much for purchasing our product,please keep and read this manual carefully before you install heat pump.
- Page 3 Dear Customer We really appreciate that you have chosen our swimming pool heat pump. Meticulously designed, using only the highest quality materials and components, your pool heat pump is designed to last longer. To enable your swimming heat pump to give you many years of perfect trouble-free service, we would recommend you to follow the instructions of the service manual carefully.
- Page 4 -IMPORT SAFETY PRECAUTIONS IMPORTANT NOTICE: This guide provides installation and operation instructions for the pool heat pump. Please consult the technical for any questions regarding this equipment. ATTENTION INSTALLER: This guide contains important information about the installation, operation and safe use of this product. This Information should be given to the owner and operator of this equipment after installation.
- Page 5 Fluorinated greenhouse gas – (R32) The device contains the fluorinated greenhouse gas (R32) which is required for the device to work. Industrial designation HFC-32 Common designation Global warming potential (GWP) Further information can be found on the device itself or the Specifications. WARNING! Risk of fire and explosion through leaking finned heat exchanger! The refrigerant circuit of the finned heat exchanger contains highly pressurised, easily flammable,...
- Page 6 - Do not open the housing. Leave repairs to qualified specialists. Liability and warranty claims are excluded in the event of repairs carried out on your own, improper operation. - Ensure that children do not insert any objects into the fan blade and heat pump. - Ensure that the electrical system to which the heat pump is connected has an earth conductor.
-
Page 7: Accessories Description
1. Accessories description Each unit produced by our factory is with the following accessories: Name Qty. Instruction Manual 1 PC Guide users to install the system Drain-pipe 1 PC Used for draining the condensate water Drain-pipe connector 1 PC Connect the drain pipe to the heat pump unit Rubber shock absorber 4 PCS Reduce vibration and reduce noise... -
Page 8: Attention For Safety
2. Attention for safety Range of application: 1.Power supply: 220~240V/1N~50/60Hz; 380~415V/3N~50/60Hz. 2.Environment temperature: -15°C〜43°C 3.Water temperature range: 8°C~40°C in Heating function 8°C~28°C in Cooling function ● Confirm the ground connection, if the ground connection is not correctly done, it may cause electric shock. -
Page 9: Installation Of The Unit
● When cleaning the unit, the operation should be stopped, and power switch should be turned off. 3. Installation of the unit 3.1 Installation Illustration Above illustration is just for the reference, please take the advice of authorized installers. 3.2 Advised installation space Keep the following indicated space for operation and maintenance when make the installation. - Page 10 3.3 Additional By-pass kits The additional By-pass kits is suggested to be put into the piping system to get the better adjustment of water flow. 3.4 Heat pump unit size (mm) Maxinverter-13S/17S/21S Maxinverter-30S 1056...
- Page 11 3.5 Heat Pump Exploded View Parts Parts Fan protective gill Water flow switch Front panel Titanium heat exchanger Fan blade Right structure Fan motor Manometer Left panel Right panel Left structure Control panel Evaporator Electrical terminal cover Fan motor mount Electrical terminal block Upper structure Electrical cable support...
-
Page 12: Specifications
Bottom panel Plastic net Four-way valve Middle panel Compressor 4. Specifications 4.1 Specifications Model No. Maxinverter-30S Advised pool volume (m³) 80-145 Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out Heating Capacity（kW) 30.11～6.83 Power Input（kW) 5.51～0.54 15.8~6.8 Heating Capacity at Air 15℃, Humidity 70%, Water 26℃... -
Page 13: Electrical Wiring
Noise at 10 m dB(A) 24~32 Net Dimensions (mm) (L x W x H) 1084*399*737 Package Dimensions (mm) (L x W x H) 1146*460*862 * Above data are subjects to modification without notice. 5. Electrical wiring 5.1 Electric wiring diagram Maxinverter-30S... - Page 14 6.1 Wire controller (Buttons and Icons)
- Page 15 6.2 Start up & Locking Attention: Before you start the machine, please make sure the filtration pump is running and there is water flow goes through the heat pump. Hold the button for 3 seconds to switch the heat pump ON or OFF. On the main interface, hold for 3 seconds to lock or unlock the controller.
- Page 16 6.3 Mode Selected Hold the button for 3 seconds to change the below three operating functions each time: Heating function Cooling function Auto function Under Auto function, if the real situation is in Heating, it will show , if the real situation is in Cooling, it will show Press button to change the below two running modes each time:...
- Page 17 6.4 Set the required temp. On the main interface, press to adjust the required water temp. Of your pool, then press to save the setting. Or you can adjust the Parameters P01/P02 to set the required water temp. 6.5 Clock setting for 3 seconds to enter Clock setting interface.
- Page 18 Hold the button for 3 seconds to enter the setting of Timer ON & Timer Off groups. Then use the same method to make the setting of Hour and Minute like Clock setting. Pay attention: There are 3 groups Timer for your every day setting. See above photo, the icon ‘ON’...
- Page 19 : WiFi connected. It will flash under WiFi connecting. : It will flash when there is Error code or system protection. 6.8 Manual defrosting Hold for 5 seconds, and when the Piping temp. is below than Exit defrosting temp., the system can enter into Manual defrosting. 6.9 Parameters Setting On the main interface, hold for 3 seconds to enter Parameter setting.
- Page 20 to adjust the data, then press again to save the data. Press to go back the main interface. Code Description Range Default Desired water temp. in Heating mode 8℃~40℃ 27℃ Desired water temp. in Cooling mode 8℃~28℃ 27℃ Desired water temp. in Auto mode 8℃~40℃...
- Page 21 Code Description Scope Inlet water temp. ℃ Outlet water temp. ℃ Ambient temp. ℃ Exhaust temp. ℃ ℃ Gas return temp. Outer piping temp. ℃ ℃ Inner piping temp. EEV aperture Compressor current Radiator temp. Voltage value Frequency Fan motor speed r/min Fan motor speed r/min...
-
Page 22: Operation And Maintenance
7.2 Preparation Before Adjustment ● The system is installed correctly. ● Tubes and lines are putted in the right place. ● Accessories are installed. ● Ensure the smooth drainage. ● Ensure the perfect insulation. ● Correct connection of ground lead. ●... - Page 23 ● Examine regularly whether the electrical connection is loose, if yes, fasten it on time. ● Examine regularly the reliability of the electrical components, change all the failed or unreliable components on time. ● The dirt retention on the surface of evaporator fin should be cleaned every 6 months. ●...
- Page 24 alcohol and other flammable materials, to avoid explosion accident. 9. Error codes & Solutions Code Description Potential reasons Solutions Check the water circuit system, the Water flow protection Insufficient water flow opening of by-pass kits, the running of water pump...
- Page 25 Water flow switch Check the wiring and reconnect water disconnected flow switch Water flow switch defective Change a new one Ambient/Inlet water temp. is The unit will be re-started when the Antifreeze protection too low and the unit is on ambient/inlet water temp.
-
Page 26: Wifi-Function
Outer piping temp. sensor Sensor disconnected or Reconnect or replace sensor failure defective Exhause piping temp. Sensor disconnected or Reconnect or replace sensor sensor failure defective Inverter module abnormal Check the voltage, compressor, fan protection motor etc... Ambient temp. sensor Sensor disconnected or Reconnect or replace sensor failure... - Page 27 Scan the QR code below to download the mobile APP. Or search ‘Tuya Smart’ in App Store (IOS) or Google play (Android) 2. Sign up for the first time 3. Press ‘+’ to add a device 4. Choose ‘Others’ and ‘Other Wifi’ on the interface...
- Page 28 5. Put your mobile phone close to the pool heat pump, which must be under the same WiFi area 6. Make sure the device (controller/display) is reset (Hold for 3 seconds to make the reset), then using your App to enter the WIFI account and password to connect WIFI.
- Page 29 Reset the Wifi function: Hold the for 3 seconds. 7. Press ‘Confirm’ to start the connection after completing. The device is successfully added if it’s connect, then press ‘Finish’.
- Page 30 8. Functions Remark: The heat pump APP function includes: ⚫ Turn On/Off the machine ⚫ Temperature setting and display ⚫ Mode Selection ⚫ Failure status display...
-
Page 31: Customer Care
Customer Care If your heat pump does not operate normally, please turn off the unit and cut off the power supply at once, then contact our service center or technical department.
