Summary of Contents for SMS Modem M35
- Page 1 SMS Modem install manual www.SMS-MODEM.ru 1st November, 2016...
-
Page 2: Table Of Contents
Directory 1, SMS Modem contact PC ..............3 2, Install driver ..................1,Open the “Device Manager” ............5 2,Install driver ................... 6 3, Install SMS Caster E-Marketer software.......... 4, The use of SMSCaster E-Marketer ..........1,Use the information ..............13 2,Send SMS ................... 15 3,Other features(Automatically add prefix, intermittent sent, Multitasking is sent, Timing task) .......... -
Page 3: 1, Sms Modem Contact Pc
2,Install SIM card（SIM card does not support hot swap, if you need to change SIM cards, please close the corresponding module power at first）, 3,Open SMS Modem power, Note: Must use the matching power adapter DC), otherwise it may cause damage to the equipment. - Page 4 M26 Modem SMS-MODEM.ru 1st November, 2016...
-
Page 5: 2, Install Driver
2, Install driver 1,Open the “Device Manager” you can see: this is 8 port SMS Modem, there is no driver SMS-MODEM.ru 1st November, 2016... -
Page 6: 2,Install Driver
2,Install driver (Download the driver) 1,Open the driver the compressed file and Into the current folder, If there is no decompression procedure, please Download WinRAR,and install it , 2, Unpack the driver folder： please open the Win7 folder and find it 3 Open it ,it will Auto install driver, If it have following tips, click Next. - Page 7 It means that the installation has been completed ： 3,look “ Device Manage”,this is 8 port SMS Modem, So it have 8 COM port, and driver installation is done. SMS-MODEM.ru 1st November, 2016...
-
Page 8: 3, Install Sms Caster E-Marketer Software
3, Install SMS Caster E-Marketer software 1,Download SMSCaster open it, click Next 3 As shown in figure SMS-MODEM.ru 1st November, 2016... - Page 9 4 Next, and continue Next 5 click Install SMS-MODEM.ru 1st November, 2016...
- Page 10 6,Install done, click Finish 7,software registered, As shown in figure, just installed software shows Unregistered. So it need to be registered. SMS-MODEM.ru 1st November, 2016...
- Page 11 1,open , Copy the content about “Serial#” to “# Computer Serial”, select the”# Software” to “SMSCaster E-Marketer GSM Enterprise v3.6”. Click “Generate”, than Copy the generated content. 2,open it , Copy the generated content to “Unlock key”, click “ok” SMS-MODEM.ru 1st November, 2016...
- Page 12 3,if the “Unregistered” is disappeared, it mean registered is success. If not, please do it again about registered steps. SMS-MODEM.ru 1st November, 2016...
-
Page 13: 4, The Use Of Smscaster E-Marketer
4, The use of SMSCaster E-Marketer 1,Use the information 1,open ,If you didn't choose any port in advance, It will promptly check COM list. Select “Yes”. 2,it mean ,this COM port have SIM card, and it have read this SIM card ,if you select it ,The “Status”... - Page 14 Select done ,it means , it will use them to send SMS. If you need to close the software, it is better do not select any com port , otherwise, you can’t see the COM list when you open again, than you need to re-install the software again.
-
Page 15: 2,Send Sms
2,Send SMS Select Groups or all (default all) => Input Message content => click “Send to Outbox” =>check Outbox (click “Send”) SMS-MODEM.ru 1st November, 2016... -
Page 16: 3,Other Features
Send SMS, if successful, the message will be saved in “Sent”, the failed message will keep in “Outbox” 3,Other features(Automatically add prefix, intermittent sent, Multitasking is sent, Timing task) Automatically add prefix, intermittent sent, As shown in figure： Multitasking is sent： need open this SMS-MODEM.ru 1st November, 2016... - Page 17 function After open the multitasking function, you need to set COM in which Queue, and also need to select Queue when Add to the Outbox. SMS-MODEM.ru 1st November, 2016...
- Page 18 Timing task:( Please see prompt box) SMS-MODEM.ru 1st November, 2016...
- Page 19 SMS-MODEM.ru 1st November, 2016...
-
Page 20: 4,Import Contacts List
4,Import contacts list 1, Please pay attention to choose the option below(Details please see the options, For example: The first is default, it means it will delete duplicate number When adding) SMS-MODEM.ru 1st November, 2016... - Page 21 2,Select the file(csv or txt ) SMS-MODEM.ru 1st November, 2016...
- Page 22 Click “Next” SMS-MODEM.ru 1st November, 2016...
- Page 23 Please pay attention to the relevant options, the default click “Next”: SMS-MODEM.ru 1st November, 2016...
- Page 24 4,Import is done , See the prompt. SMS-MODEM.ru 1st November, 2016...
-
Page 25: 5,Add Groups
5,Add Groups 1,click New SMS-MODEM.ru 1st November, 2016... - Page 26 2,Input Group Name and select the need to add the number SMS-MODEM.ru 1st November, 2016...
-
Page 27: 6,Faq
3,Group add done,please note it that to select the group when adding to outbox. 6,FAQ 1, COM and port number is not corresponding, how do I know this port can not use? Each module has lights: 1,Light flash every 3 s, means normal registration card, can be used;... - Page 28 direction of the note card is correct 3,COM port have error 2 Please reboot this port or re-install this port(Each module is removable) 4, Just began to normal to send, but send failure after a period of time, It may be blocked by operator or limit, Check the SIM card again or contact Operator.
-
Page 29: 7,Change Imei/Send Ussd/Call/Put In Pin/Puk Code
7,Change IMEI/Send USSD/Call/Put in PIN/PUK code(AT command) Download putty，and open it ,put in COM number ,open it , According to the following text instructions. Change IMEI 1,open Putty 2,click " Serial" 3. Input the com port in "Serial line" such as COM 1 4,PUT IN "at&f"... - Page 30 6,at+egmr=1,7,"IMEI number" change imei, for example : AT+EGMR=1,7,"453243242432134" if you put in imei is wrong ,it will reset or keep old IMEI 7,put in "at+cgsn"//check new IMEI CALL 1,open Putty 2,click " Serial" 3. Input the com port in "Serial line" such as COM 1 4,PUT IN "at&f"...
- Page 31 for example: at+cusd=1,"*097#" Put in PIN/PUK code 1,open Putty 2,click " Serial" 3. Input the com port in "Serial line" such as COM 1 4,PUT IN "at&f" 5,PUT in “at+cpin?” //check PIN status If display “ready”=> it is ok, don’t need put in PIN code If display ”SIM PIN”...
