- Page 1 TekFast 4G MODEM User Manual User Manual 4G MODEM TekFast Model: CM-1011Q Document History Revision Date Remark Rev.01-1120 CM-1011Q All specifications are correct at the time of release. Page 1...
-
Page 2: Table Of Contents
TekFast 4G MODEM User Manual TABLE OF CONTENS 1 Introduction ___________________________________________ 2 Specifications __________________________________________ 2.1 Technical Specification _______________________________ 2.2 Electrical Characteristic ______________________________ 2.3 Environmental Characteristics _________________________ 2.4 More Characteristic __________________________________ 3 Technical Hardware _____________________________________ 3.1 Overview __________________________________________ 3.2 Status Indicator _____________________________________ 3.3 Cable Interface _____________________________________... -
Page 3: Introduction
Machine-to-Machine (M2M) applications including automotive systems, fleet management, automated meter reading, smart meter, vending and retail, security and surveillance, industrial systems, information display, etc. This manual provides an overview of the operation of TekFast 4G modem. It includes technical Information. Page 3... -
Page 4: Specifications
TekFast 4G MODEM User Manual 2. SPECIFICATIONS General Feature CM-1011Q is 3G/4G cellular modem for data /networking communication over internet by remote control system. Support Thailand version Voltage Input 5V~24V 3GPP and Enhanced AT Commands Signal strength and Status indicators (LED) Control via AT commands SIM card (1.8V/3V interface) -
Page 5: Technical Specification
TekFast 4G MODEM User Manual 2.1 Technical Specification Feature Specifications Network System LTE-FDD B1/B3/B5/B7/B8/B20 LTE-TDD WCDMA B1/B2/B5/B8 GSM/EDGE B2/B3/B5/B8 Serial Interface UART 2 UART 1 Port USB 2.0 with High Speed SIM Card 1 SIM 1.8V/3.0V (U) Serial RS-232 with RJ45 Interface... -
Page 6: Electrical Characteristic
TekFast 4G MODEM User Manual 2.2 Electrical Characteristic Power Supply Specifications Operating Voltage Range DC 5 to 24 V Battery 3.6V 300mA (Option) 2.3 Environmental Characteristics Feature Specifications Temperature Operating -40°C ~ +85°C Humidity Operating 5 to 95% RH 2.4 More Characteristic... -
Page 7: Technical Hardware
TekFast 4G MODEM User Manual 3. TECHNICAL HARDWARE 3.1 Overview Page 7... -
Page 8: Status Indicator
TekFast 4G MODEM User Manual 3.2 Status Indicator Status Indicator Modem Status (Green LED) LED ON Permanently Modem is switched on but is not registered on the network LED ON and blinking slowly Modem is switched on and registered to the network . -
Page 9: Cable Interface
TekFast 4G MODEM User Manual 3.3 Cable Interface The modem to communicates with other devices via the RJ-45 cable. The 8-pin RJ- 45 plug consists of: 1. Power input and Ground (Pin 1 and pin 4) 2. RJ-45 (RS-232) serial connection... -
Page 10: Power Supply Interface
TekFast 4G MODEM User Manual 3.4 Power Supply Interface The table below shows the power supply pin assignment from the modem interface cable. PIN Number Description VDC Power Input Ground The power supply rating is : Power Supply Voltage Minimum Voltage Input Maximum Voltage Input A regulated 5V DC input voltage is recommended for operating the modem. - Page 11 TekFast 4G MODEM User Manual To interface modem to a DTE device via standard DB 9 Pin RS-232 serial port connector, map the interface cable pins as follow: PIN RJ-45 PIN DB-9 Description RS-232 (male) RS-232 Ground Page 11...
-
Page 12: Sim Interface
TekFast 4G MODEM User Manual 3.6 SIM Interface The SIM interface is intended for 1.8 / 3V SIM cards. A SIM detect pin is added to indicate whether or not a SIM card is inserted. Page 12... -
Page 13: Antenna Interface
TekFast 4G MODEM User Manual 3.7 Antenna Interface The 4G antenna interface uses a SMA connector. Attach the external antenna to the modem and tighten the connection. 4G and GPS Antenna Page 13... -
Page 14: Mounting Base
TekFast 4G MODEM User Manual 3.8 Mounting Base Modem can be mounted onto your application by attaching it to the back of the modem using four M3 screws Page 14... -
Page 15: Getting Started
TekFast 4G MODEM User Manual 4. GETTING STARTED 4.1 Setting up the modem Step 1 Prepare the SIM Card. Before using the modem, you must contact a network operator to get a personal SIM card. Do acquire the UMTS/GPRS APN, User-ID and Password from your network operator. -
Page 16: Interfacing Modem With Hyperterminal Software
TekFast 4G MODEM User Manual 4.2 Interfacing Modem with HyperTerminal Software Configuring HyperTerminal for Modem: Step 1 Connect the Modem to the PC COM port and run the HyperTerminal software. Step 2 You will be prompted to enter a description for the new connection. Enter a name for the connection (e.g. - Page 17 TekFast 4G MODEM User Manual Step 3 In the Connect to dialog box, select the PC COM port number, which is connected to the modem, and click OK to continue. Step 4 In the next prompted dialog box, enter the COM port settings which is configured in the modem and click OK to continue.
- Page 18 TekFast 4G MODEM User Manual Step 5 The Connected text in HyperTerminal status bar indicates that the PC is ready to communicate with the modem. Perform a simple check on the connection between HyperTerminal and the modem: The following are some other AT command examples you can use:...
- Page 19 TekFast 4G MODEM User Manual This section suggests examples for some basic functions using HyperTerminal sending short messages (SMS): Step 1 Set short message format as Text mode. AT+CMGF=1 <Enter> Step 2 Check whether SMS center (SMSC) number is set to SIM card.
-
Page 20: Troubleshooting
TekFast 4G MODEM User Manual 5. TROUBLESHOOTING 5.1 The modem is not power up Check whether the LED Status (Green) on the modem is lighted up. If it is not lighted up, check whether the modem is supplied with the correct voltage range between 5V to 24VDC. -
Page 21: Safety Information
TekFast 4G MODEM User Manual 6 Safety Information SAR Requirement Based on the CE radiation exposure limits, and the standards EN50385 and EN50383, a minimum safety operating distance between the device and human body must be maintained. A 203mm (8inches) separation distance between the We modem and human body must be maintained at all times during device operation. - Page 22 TekFast 4G MODEM User Manual Vehicle Safety If incorrectly installed in a vehicle, the operation of the Modem could interfere with the proper functioning of vehicle electronics. Ensure that only qualified personnel perform the installation to avoid such problems. Verification of the protection of vehicle electronics should form part of the installation.
