STYLE STUDIO ROMAN Manual

F IT TING & CARE I NST RU CT IONS
Fitting Instructions
1. Fitting tools required include star point
screwdriver, drill and drill bit suitable for
substrate.
3. Drill hole in substrate at each marked position.
If required, fit wall plugs. Position brackets at
window or fascia, ensure they are level and screw fix.
2. Mark with a pencil where the brackets are to
be fixed. Brackets should be positioned approx.
50mm from the end of the headrail at each end.
For larger blinds, additional brackets will be
supplied and can be spaced evenly throughout
the width of the headrail.
1
2
4. Slowly remove the velco fixing attaching the
fabric on your blind to the headrail. This will help
install the rail onto the brackets. Insert the headrail
whilst pushing the plastic button as shown in
diagram.
Ensure that the headrail groove is properly places
in the bracket lock and then release the button.
Secure fabric back onto headrail ensuring the top
fabric covers the brackets.
Fitting your device
The length of the operating chain allowed on the blind is dependent on both the installation height and the drop of
the blind. The blind will be supplied in accordance with the information opposite, depending on what information was
TENSIONING DEVICE INSTALLATION HEIGHT KNOWN
GROUND
Fitting of Child Safety Devices
Fitting of Child Safety Devices
1. To fit your device, place the 2. Drill pilot hole and screw device
chain round the device at the into position. Use applicable wall
maximum distance possible from plugs if required.
the control mechanism and mark
hole position on substrate. Make
1. To fit your device, place the 2. Drill pilot hole and screw
sure the chain is fully taut.
chain round the device at the device into position. Use
Child Safety maximum distance possible applicable wall plugs if required.
from the control mechanism and
mark hole position on substrate.
Make sure the chain is fully taut.
Young children can be strangled by loops in pull cords, chains, tapes and inner cords that operate
the product.
To avoid strangulation and entanglement, keep cords out of reach of young children. Cords
may become wrapped around a child's neck.
All of our blinds are compliant with the Child Safety Legislation BS EN 13120 and are supplied with the
relevant child safety devices and labels to keep you and your family safe.
If you have any questions about the safety of your blind, please ask your retailer or installer.
Child Safety Devices
Your blind is supplied with either a face or recess fix child safety device as well as rear cord breakaway connectors
placed on the cords on the back of the blind.
The face/recess fix device is designed to hold the chain under tension, removing any potential loops.
The rear cord breakaway connectors are attached to each panel and cord on the reverse of the blind, and will break
away if any reasonable weight is placed on the cord on the back of the blind. The clip on the tape will remain in place
and the clip on the cord will breakaway, removing any potential cord loops.
INSTALLATION HEIGHT UNKNOWN
GROUND
3. Ensure the distance between
the two strands of chain is not
more than 50mm at the point of
exit from the device.
3. Ensure the distance between
the two strands of chain is not
more than 50mm at the point of
exit from the device.
CHILD SAFE
PRODUCT
.
.
