Summary of Contents for Conair GL-2106
- Page 1 Founded in 1995, is a professional enterprise of air purifier Air Quality Sensor 4 Speeds and Sleep Mode Timer Function Touch Display...
- Page 3 Company Profile Founded in 1995, is a professional enterprise of air purifier. Our factory approval ISO9001, ISO14001, BSCI, with modern factory buildings and advanced automation equipments from Germany and Japan to fully realize the integrated production and manufacturing mode, such as injection workshop, moulding workshop production and assembly workshop, screen printing workshop, CADR test of international standards room.
-
Page 4: Table Of Contents
Contents Read and Save These Instructions Product Structure Product Performance Operating Instruction 6 In 1 Filter Regular Cleaning Filter Replacement Dismount the Filter Install the Filter Trouble Shooting Technical Specification Warranty Card... -
Page 5: Read And Save These Instructions 1
READ AND SAVE THESE INSTRUCTIONS 1 Please read the instructions carefully before use, and keep the Warning instructions strictly. Do not use a power adapter which is not This product can only be used indoors compatible with this product. There is a This product cannot be used in risk of fire, electric shock, injury. - Page 6 2 READ AND SAVE THESE INSTRUCTIONS Do not let water or any other liquid enter the unit Do not place the product where children can Do not spray liquid on the unit! touch, there is a risk of injury. To avoid electric shock! Do not attempt to disassemble or Do not use alcohol or dilute solvent.
-
Page 7: Product Structure 3
PRODUCT STRUCTURE 3 1.touch panel 2.PCB control panel 3.control panel bracket 4. air outlet 11.fan 5. air outlet bracket 12.fan bracket 6. upper cover 13.sensor 7.power bracket 14.motor bracket 8. power panel 9. negative ion 10.motor 15.lower cover 16.6 in 1 filter 17.bottom cover... -
Page 8: Product Performance
4 PRODUCT PERFORMANCE 1. Purifying the air, absorbing dust, particle, hair and pollen, etc. 2. Removing odor, smoke and TVOC etc. 3.The air purifier automatically release negative ion after press the power button. Sleep mode Turbo mode Filter replacement Indicator Power off/on Auto mode Timer(1/2/4/8h) -
Page 9: Operating Instruction 5
OPERATING INSTRUCTION 5 1.Power Button: After connecting power, click power button, the power indicator lights up blue, and the machine startup at the default status, fan at low speed. The negative ion generator starts working. After 2 minutes the air quality indicator shows the level of current indoor air quality. - Page 10 6 OPERATING INSTRUCTION 4.Auto Mode: Press the auto button to turn on auto mode, and the auto mode indicator lights up. Press the auto button again to turn off auto mode, and the fan is set to low speed. In auto mode, the fan speed is set according to the pollution level, e.g.
- Page 11 OPERATING INSTRUCTION 7 7.Filter Replacement Indicator: The air filter is used for more than 2000 hours, the indicator will turn red to remind you that the air filter needs to be replaced. 8.Air Quality Sensor: The air quality indicator shows the air quality and pollution level according to 3 levels: Color Pollution...
-
Page 12: In 1 Filter
8 6 IN 1 FILTER Polluted air Fresh air Ultra fine pre First silver H13 true HEPA Second silver Activated Mesh filter filter coating filter coating carbon filter Ultra Fine Pre-Filter: Filter hair, pet dander. Double Silver Coating: Deeply purify the air. H13 True HEPA Filter: Removing 99.99% airborne pollen particle. -
Page 13: Regular Cleaning 9
REGULAR CLEANING 9 Clean the product more often if you use it continuously or if you are in a very polluted environment. 1. Unplug the product from power outlet before cleaning. 2. Remove dust and dirt from air inlet, air outlet, and product case using a soft cloth. -
Page 14: Filter Replacement
10 FILTER REPLACEMENT The regular change of the filter is indicated when the filter replacement indicator turns red. Change the filter more often if you use the product continuously or in a very polluted environment. 1. Unplug the product from the power outlet before changing the filter. 2. -
Page 15: Dismount The Filter 11
DISMOUNT THE FILTER 11 1. Unplug the product from power outlet before dismounting the filter. 2. Turn the bottom cover anticlockwise till it clicks.The bottom cover is unlocked. 3. Remove the bottom cover carefully from the product case. 4. Hold the filter at both ends and take it out of the product case. The filter can now be cleaned or replaced. -
Page 16: Install The Filter
12 INSTALL THE FILTER 1. Make sure the product is unplugged from power and the bottom cover is removed before installing the filter. 2. Place the filter into the open product case with the upper black part of the filter towards the inside. 3. -
Page 17: Trouble Shooting 13
TROUBLE SHOOTING 13 Possible cause Remedy Malfunction The product is The product is not Plug the power cord not working. connected to a power into a power outlet. outlet. The air quality is not The product has been Wait for 2 minutes after good, but the air quality switched on for less than switch-on until the air... -
Page 18: Technical Specification
14 TECHNICAL SPECIFICATION P ro d u c t N a m e Io ni zer Ai r P u r i f i er Mo d e l GL- 210 6 R a t ed Vo lt a g e AC 1 20 V/ 60 H z P owe r 40 W... -
Page 19: Warranty Card 15
WARRANTY CARD 15 User name: Telephone: Correspondence Address: Model No: Purchased Date: Purchased Store: E-Mail: Thank you for your purchase Gonrair air purifier. If you have any questions about our air purifier, please feel free to contact customer service. Shenzhen Guanglei Electronic Co.,Ltd sales18@glpurifier.com... - Page 20 EPA EST.NO.101118-CHN-1 Made in China...
