Page 1: Table Of Contents
Table of Contents Important Safety Instructions General Warnings and Cautions ......1 Protection Against Electric Shock ......2 Information About Repair Service ......3 Getting Started Installing the Batteries ..........6 Set Up Connections ..........8 Connecting a TV Cable or Antenna ....8 Connecting an S-Video Source ......
Page 2 Caring for Your iCEBOX Updating Your iCEBOX System ......43 Cleaning the iCEBOX ......... 45 Getting Help ..........45 Troubleshooting ..........47 FAQs .............. 48 Privacy Policy ............ 52 Specifications............ 54 FCC Statement ..........55 iCEBOX CounterTop Warranty ......56 Index ............... 59...
Page 3: Important Safety Instructions
Important Safety Instructions Important Safety Instructions When using the iCEBOX™ CounterTop, observe these basic precautions to reduce the risk of personal injury or equipment damage. Before using the iCEBOX • Read and understand all iCEBOX instructions. • Follow all warnings and cautions on the product and in these operating instructions.
Page 4: Protection Against Electric Shock
CounterTop Owner’s Manual Do not use the unit near water. For example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swim- ming pool; and the like. Carts and Stands. The iCEBOX should be placed on a cart or stand designed to securely support the weight of the unit.
Page 5: Information About Repair Service
Important Safety Instructions of the mast and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of grounding conductors, location of antennadischarge unit, connection to grounding electrodes, and requirements for the grounding electrode. Antenna lead wire Ground clamp Antenna discharge un (NEC section 810-20)
Page 6 CounterTop Owner’s Manual Damage requiring service. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the powersupply cord or plug is damaged. If liquid has been spilled, or objects have fallen into the product. If the product has been exposed to rain or water.
Page 7: Getting Started
DVDs or CDs, check your Email, and monitor other areas of your home, all from the convenience of your kitchen. The iCEBOX CounterTop can also act as the command center and informa- tion gateway for your Beyond Connected Appliances, which includes the Beyond Microwave, Bread Maker and Coffee Maker.
Page 8: Installing The Batteries
CounterTop Owner’s Manual Installing the Batteries Before you turn on your iCEBOX, you will need to install the batteries in the remote and keyboard. The remote requires two AAA batteries (sup- plied), and the keyboard requires two AA batteries (supplied). Alkaline batteries are recommended.
Page 9 Getting Started To install the batteries for your keyboard On the back of the keyboard, remove the battery cover by loosening both large screws on either end of the battery panel (Keyboard Battery Installation). Keep the attached washers with each screw. Remove the rubber gasket.
Page 10: Set Up Connections
SANI Broadband Power Cable Rear Panel of the iCEBOX CounterTop FIGURE 5. Connecting a TV The iCEBOX is a 125-channel, cable-ready, stereo television. To use your iCEBOX as a television, you must first connect it to a TV signal source.
Page 11: Connecting An S-Video Source
Getting Started Satellite or Digital Cable Television Service The iCEBOX supports satellite and digital cable television service; how- ever, when using satellite service, the iCEBOX remote or keyboard cannot be used to change channels. Continue to use your existing remote control with the set-top box.
Page 12: Connecting The Fm Radio Antenna
Insert audio cables from the device into the Audio In connections on the back of the iCEBOX. Connecting the You can use the iCEBOX to listen to your favorite local FM radio stations in FM Radio Mode. Enclosed with your iCEBOX CounterTop is an FM radio FM Radio antenna. Antenna...
Page 13 To connect using a wireless bridge Insert the included networking card into the PCMCIA slot on the back of the iCEBOX (Rear Panel of the iCEBOX CounterTop). Connect the wireless bridge to your home PC and configure it follow- ing the directions provided by the manufacturer of the bridge.
Page 14: Connecting Other Devices
CounterTop Owner’s Manual To connect using a Dial-Up connection Insert the modem card into the PCMCIA slot on the back of the iCEBOX. Plug the analog telephone line into RJ-11 jack on the modem card. • Further configuration is required. Configuring a Dial-Up Connection Do not connect the iCEBOX to a digital phone line.
Page 15: Connecting The Sani Antenna
You can route sound through a home stereo or other amplified audio sys- tem. Connect your system to the Audio Out connections on the rear panel of the unit (Rear Panel of the iCEBOX CounterTop). For more information, refer to the instructions that were provided with your audio system.
Page 16: Using The Icebox Controls
CounterTop Owner’s Manual Using the iCEBOX Controls When you turn on your iCEBOX CounterTop for the first time, take a moment to familiarize yourself with the controls. Front Panel The front panel of the CounterTop has controls and indicators that are attractively integrated into the design.
Page 17: Remote And Keyboard
Getting Started Power Indicator The light on the Power Button of the iCEBOX tells you what the current power status is for your iCEBOX. When the button is... The iCEBOX is... Unlighted Turned off because the power cord is not plugged into the rear of the unit.
Page 18 CounterTop Owner’s Manual The iCEBOX Remote FIGURE 7.
Page 19 S-Video signal. Press the Video button repeatedly to switch between the S-Video and composite signals. Mode X My Kitchen Mode Puts the iCEBOX into My Kitchen mode where you can manage your Beyond Connected Appliances. Mode Y This mode will be available as part of future updates.
Page 20 CounterTop Owner’s Manual Options Button Options, Channel, and Volume Buttons shows the location of the Options button. You can use the Options button in all modes to change modes on screen, or to access the Options menu for the current mode. Television Mode Buttons Options, Channel, and Volume Buttons FIGURE 8.
