  • Page 1 WLRD12-2DI User Manual Pulse counter...

  • Page 2: General Warnings

    WLRD12-2DI User Manual General warnings. • The following information must be read and understood before proceeding with the installation, commissioning and maintenance of the devices described in this document. • ATTENTION! Any omission or failure to follow these instructions scrupulously can cause danger.
  • Page 3 WLRD12-2DI User Manual 1. Description WLRD12-2DI is a datalogger with two input channels to acquire pulses from clean contacts or open-collector, from energy meters, fluid meters, etc. inputs, with storage functionality of samples acquired. Counting is continuously performed on input channels and is partially considered on the configurable sampling period.
  • Page 4 WLRD12-2DI User Manual Picture 2 - Datalogger configuration InfoReq Advanced sensor properties click on “ ” button to enter in the “ ” tab Picture 3- Datalogger configuration In this section following options can be selected: • - channel TYPE from those available.
  • Page 5 WLRD12-2DI User Manual ➢ Check for proper configuration of WLRD12-2DI datalogger. The maximum possible value in a measure interval is 65,535 multiplied by the pulse weight [ ]. Reached this value the count stops, Wh or KWh and, during the transmission, the invalid status of the measure is notified.

  • Page 6: Sensor Positioning

    WLRD12-2DI User Manual 5. Device pre-set and use mode. a. Wireless Mode: In this use mode, the datalogger records and transmits each measure sampled to the linked gateway. Typically, the monitoring system is refer to Picture 7 - Status table –...
  • Page 7 WLRD12-2DI User Manual 7. Wireless device user interface. WineCapKey The user interface consists of a “virtual” button that can be activated using the and of a two-colours led. WineCapKey To give a command, user must approach the to the device’s sensible area and keep it in that position.; the following picture Picture 5 - WineCapKey positioning ) shows device’s sensible points.

  • Page 8: Device Enrolment

    WLRD12-2DI User Manual The following COMMAND table describes the available commands: WIRELESS DEVICES USER INTERFACE Flash count Command Description Shows the device STATUS. As answer the led perform a flash sequence as 1 flash refer to STATUS reported in the STATUS table. If the device is performing the TEST ( TEST command ) this command stops it.
  • Page 9 WLRD12-2DI User Manual WineCapKey For each flash, a different command is associated; to confirm the command the must be removed from the sensible area immediately after the number of flashes corresponding at the desired command. The TEST corresponds to the second pulse and activate the "Field Measurer"...
  • Page 10 WLRD12-2DI User Manual 11. Shutting off/Reactivating the device. (refer to Picture 6 – Wireless devices user If the device is shut off and left unused for a long time, you can issue the STANDBY command interface) . It corresponds to the command number 4 and must be issued twice to confirm the operation.

  • Page 11: Technical Information

    WLRD12-2DI User Manual 13. Technical Information. Power supply 8.5Ah - 3.6V type “C” lithium internal battery ( BAT2 Up to 7 years Battery life (*) samples every 60 minutes and radio signal quality at least sufficient Pulses from clean contact or open collector configurable as: •...

  • Page 12: Mechanical Dimensions

    Picture 10 - Mechanical dimensions 15. Disclaimer. • Specifications are subject to change without notice and should not be interpreted as a commitment on the part of Capetti Elettronica S.r.l. • Capetti Elettronica S.r.l. assumes no responsibility for possibly errors that may appear in this document. In no case Capetti Elettronica S.r.l.

  • Page 13: Reference Standards

    WLRD12-2DI User Manual 16. Reference standards. EN 61010 -1 For electromagnetic compatibility EN 61000 - 3 - 2 EN 61000 - 3 - 3 EN 300 220 -2 EN 301 489 - 03 EN 61000 - 6 -1 This symbol indicates that this product is compliant with the European Directive 2011/65/CE that restricts the use of substances in the manufacturing of electronic devices.
