- Page 1 Water Conditioning Appliance SIGNATURE SERIES Owner’s Manual and Installation Guide Version 1.0...
-
Page 2: Table Of Contents
Hague Quality Water International will not be liable for, nor will it pay service call or labor charges incurred or expended with respect to this warranty. -
Page 3: General Information
General Information Getting Maximum Efficiency From the Appliance Congratulations on choosing a superior Hague water treatment appliance! Soon you and your To achieve the maximum benefit and performance from The appliance may be disinfected with 5.25% family will be enjoying clean, clear water. Use this guide to attain the maximum benefit from... -
Page 4: Installation
Install a pressure-reducing valve if the inlet pressure exceeds 70 psi (4.8 bar). The appropriate Hague Water Filter can address these water shortcomings. See Filter Specifications for details on Examine the inlet line to ensure water will flow through it freely and that the inlet pipe size is sized correctly. For well each filter. - Page 5 Installation Steps and Start-Up Procedures Installation Steps and Start-Up Procedures, Cont. Step 1 Prepare the Placement Area Turn Off Water Supply Step 2 Make sure the placement area is clean. Turn off the water supply. Turn off the electricity and water supply to the water heater. For gas water heaters, turn the gas cock to Open the hot and cold water taps to depressurize the lines.
- Page 6 Installation Steps and Start-Up Procedures, Cont. Installation Steps and Start-Up Procedures, Cont. Check for Leaks Step 12 Complete the Installation Step 8 Close all faucets. Ensure that the bypass is left in the Service position. See Bypass Valve. Check all lines and connections for leaks. If leaks are found: Ensure the water supply is on.
-
Page 7: Smart Touch Controller
Where extremely appliance’s status, perform regenerations, and change settings. An independent Hague dealer should set the Service hard water is present, the blending valve may only need to be “cracked” open. Where the incoming water has relatively low Settings during installation of the appliance. -
Page 8: Service Settings
Service Settings Service Settings, Cont. Service Settings — History To program Service Settings on the controller, tap on the screen to bring up the “Main Menu.” History is an optional set of menus that acts as a clipboard for storing the history of water chemistry, total regenerations, Tap the Service Settings button . - Page 9 Service Settings, Cont. Service Settings, Cont. Mode 1 (Timer Mode) Setting Chart Operating Modes This section provides guidance for using different service settings to achieve the desired capacity. The controller has a Timer mode (Mode 1 Frequency and Mode 1 Days of the Week), a Demand Delayed mode (Mode 2), and a Demand Immediate mode (Mode 3).
-
Page 10: Customer Settings
Service Settings, Cont. Customer Settings Mode 2 (Demand Delayed Mode) Setting Chart Service Settings must be set before Customer Settings; Service Settings should be set during installation of the appliance. This section provides guidance for using different service settings to achieve the desired capacity. To program Customer Settings on the controller, tap twice on the screen to bring up the “Main Menu.”... - Page 11 Customer Settings, cont. Salt Depths Based on the water level measured from the bottom of the brine cabinet with grid plate, the following depths correlate to the amount of salt used per regeneration: Set Number of People Step 6 Display reads “# People” followed by the current setting for the number of people in the household (Ex. 4). Modes 1 and 3 Mode 2 To Change the Number of People...
- Page 12 Add Replenishment Media Step 4 is available from Hague. To refill the neutralizing media, measure the appliance’s media bed depth upon installation (factory Weigh the replenishment media. freeboard). Use this measurement to determine the amount of media to add to maintain optimum performance of the 2AJQ.
- Page 13 1AAN WaterMax Iron Filter Sizing Formula Iron Filter and Potassium Permanganate Feeder Installation Guide ® The iron filter may be programmed to regenerate every one to twelve days. Select the frequency based on the amount of Important: The iron filter is capable of treating a combination of undesirable constituents in the water (iron, manganese, iron in the water and the number of people in the household.
- Page 14 Iron Filter and Potassium Permanganate Feeder Installation Guide Assembly and Parts Connect Lines Step 3 Cabinet and Cover Assemblies Connect the 3/8-inch tubing to the brine valve on the filter by pushing the tube to the stop. Pull back on the tubing to install the red locking clip behind the collet.
-
Page 15: Assembly And Parts
Assembly and Parts, Cont. Assembly and Parts, Cont. Cabinet and Assemblies Brine Tank Assembly Figure 11: Cabinet and Assemblies Current Part # Description Quantity 100238198 Screw 100238199 Screw 100241828 Drain End Cap and Container (No DLFC) - See Figure 17 100241865 O-Ring 100242049... - Page 16 Assembly and Parts, Cont. Assembly and Parts, Cont. ITEM NO. PartNo DESCRIPTION QTY. 93223 THROAT,INJECTOR,WHITE Injector Assembly Fill Plug Assembly 53224 WHITE NOZZLE OVERMOLD 93806 O Ring 53235 Injector Cap 53005 Valve Insert 54112 1/2-inch Compression Assembly 90829 O Ring-223 95500 Dist Tube (23") 90819...
- Page 17 Assembly and Parts, Cont. Assembly and Parts, Cont. Bypass Valve Assembly Cont. Bypass Valve Assembly The Cap should be held in place by the three 1/2-inch self-tapping screws and be in the proper 100241811 orientation. Blending Dial Cap The Dial permits the addition of “untreated water” into the soft water outlet. It is closed when pointing 100241804 toward the Main Control Valve and open when pointing toward the inlet side.
- Page 18 Assembly and Parts, Cont. Assembly and Parts, Cont. Drive End Cap Assembly Drive End Cap Assembly Cont. 100238181 The Motor is held in place by two 1/2-inch self-tapping screws. The screws should be “snug.” The brass pinion gear on the Motor should engage the plastic Drive Gear. The wires should be securely fastened to Drive Motor the Control.
- Page 19 Assembly and Parts, Cont. Assembly and Parts, Cont. Brine Valve Housing Assembly Drain End Cap Assembly Figure 17: Drain End Cap Assembly Current Part # Description Quantity 100241865 O-Ring Figure 16: Brine Valve Housing Assembly 100241822 Drain End Cap Current Part # Description Quantity 100242255...
-
Page 20: Troubleshooting
Troubleshooting Troubleshooting Problem Possible Cause Solution Problem Possible Cause Solution No salt in brine cabinet Add salt Make sure the controller is pushed all the way onto the Controller not attached properly drive end cap Remove the brine line and flush clean Sediment in brine cabinet has plugged the Remove the air check/draw tube and flush with clean Appliance stays in... -
Page 21: Specifications
Reading Model Numbers Specifications Hague appliance model numbers typically consist of two numerals followed by three letters, such as the WaterMax 3BEQ. ® 3MAQ 3BAQ 3BEQ 2MXQ 3MDQ Max Compensated Hardness–gpg (g/L) 90 (1.5) 90 (1.5) 90 (1.5) 110 (1.9) (1.5) - Page 22 Specifications Specifications 2AMQ 2APQ 2AKQ 2AJQ The following table describes the available filters. Max Compensated Hardness–gpg (g/L) 90 (1.5) 90 (1.5) 90 (1.5) 60 (1.0) Iron (ppm) ferrous-clear water Filter Purpose 2-12 Maximum ferrous iron reduction Reduces iron, iron algae, and bacteria. Reduces manganese. Also reduces up to 5 ppm Minimum pH–standard units Hydrogen Sulfide with the presence of 2 ppm iron.
- Page 23 A.O. Smith Water Treatment (North America), Inc. © 2022 A. O. Smith All Rights Reserved 100359102 - DOCUMENT NUMBER - RevA0123...
