Default CAP
The 'Default CAP' group allows for default priority mapping of packets that do not have a VLAN TAG. The settings are available for
Unicast (directed to a host).
• IGMP - (default CAP 3) - sets the channel access priority for IGMP frames - these are the group management frames, not the
stream data.
• Unicast - (default CAP 1) - sets the default channel access priority for unicast frames not matching any other classification or
mapping.
• IGMP managed Multicast Stream (Fixed to CAP 2) - sets the default channel access priority for stream data belonging to a
snooped IGMP multicast group.
• Multicast/Broadcast - sets the default CAP for multicast frames not in a snooped group and for broadcast frames.
VLAN Tag User Priority
0
1
2
3
4
5
6
7
Default CAP Priority
CAP1
CAP0
CAP0
CAP1
CAP2
CAP2
CAP3
CAP3
TOS Bit User Priority
0
1
2
3
4
5
6
7
25
Default CAP Priority
CAP1
CAP0
CAP0
CAP1
CAP2
CAP2
CAP3
CAP3
