Summary of Contents for Voltronic Power EVA 5420W
- Page 1 User Manual 20 - 30KW DC EV Charger Version: 1.0...
-
Page 2: Table Of Contents
Table of Contents 1. Safety Instructions ....................1 2. Technical Specifications..................... 3 3. Introduction ......................5 3.1. Product Overview .................... 5 4. Packaging ........................ 7 5. Installation ....................... 8 5.1. Pedestal Charger Installation ................9 5.2. Wall-Mount Charger Installation ..............14 6. -
Page 3: Safety Instructions
1. Safety Instructions Read and follow the instructions and warnings in this Manual before attempting to install this product. Keep this Manual for future reference. Please follow the below safety precautions to prevent bodily injuries and property damages. Warning: When the product is running, it should pay attention to ventilation, heat dissipation and keep the environment clean. - Page 4 CAUTIONS CAUTION: Wrong installation and testing of the charger will cause potential damage to the vehicle battery, assembly, and the charger itself. CAUTION: Do not operate the charger in temperatures outside its operating range of -35°C to +55°C. NOTE: Electrical equipment should only be installed, operated, serviced, and maintained by qualified personnel.
-
Page 5: Technical Specifications
2. Technical Specifications Model 20KW 30KW Charging Type DC fast charging C: CCS2 cable , A: CCS1 cable , J: CHAdeMO cable , G: GBT Outlet Options cable AC Input Power @ 400V 31A A, 20KW 48 A, 30KW 50Hz Input Voltage Range 400 VAC or 380 VAC +/- 10% Input Frequency... - Page 6 Connectivity Internet access via 4G/3G/Ethernet (RJ45) User Authentication RFID, QR code User Interface 7" LCD high-contrast touchscreen Communiation Protocols Proprietary and OCPP 1.6J RFID Reader ISO/IEC 14443 A/B Mifare RFID reader Emergency Button Cofiguration Software Upgrade Over-The-Air Language system English, Chinese, French, Spanish General characteristics Protection rating IP54 and IK10 (cabinet) / IK8 (touchscreen)
-
Page 7: Introduction
3. Introduction The DC EV charger comes with a charging plug. Maximum output power of 30kw, with 99% efficiency. For ease of operation, the electric car charger is equipped with a 7-inch industrial touch screen, a standard Ethernet connection and an embedded RFID reader with WI-FI features to communicate with LAN routers, vehicles, action devices, and other wall-mounted chargers WIFI communication is optional). - Page 8 1. LED indicators 5. EPO button 9. Back plate of the charger pedestal 2. Touch screen 6. CCS2 10. Main case of the charger pedestal 11. Front plate of the charger 3. Nozzle holster 7. Charging station backplate pedestal 4. CHAdeMO 8.
-
Page 9: Packaging
4. Packaging The charger is delivered in a carton packaging. The following figure shows the packaging for the charger. NOTE: The charger must be stored in its original packaging in a dry environment between -40 °C to +80 °C. It is recommended to ship the charger to its final destination in its original packaging and unpack it there. -
Page 10: Installation
5. Installation Danger to life due to improper installation! Ignoring environmental conditions when handling electricity can lead to hazardous situations. Before performing any installation activities, carefully read each item listed in this chapter that is critical to the installation process. [Location Selection] Consider before choosing where to install: ... -
Page 11: Pedestal Charger Installation
5.1. Pedestal Charger Installation [Note before installation] The unit must be mounted on solid and flat stone slabs. Different stone slabs require expansion bolts, or choose suitable screw installation; in some conditions, drilling is required. 5.1.1. Charger Pedestal Installation ... - Page 12 Step 2：Secure the back plate of the charger pedestal Secure the back plate of the charger pedestal with two M4 screws to the main case...
- Page 13 Step 3：Secure the front plate of the charger pedestal Secure the front plate of the charger pedestal with six M4 screws to the main case 5.1.2. DC Charger Installation Step 1：Remove two pieces of back plate Remove the back plate for the charging station and the charger pedestal...
- Page 14 Step 2：Main case installation Put the main case on the charger pedestal and fix it with seven M8 screws. Step 3: Connect the wire Pull out the ground wire and install the L1, L2, L3, N, GROUND wires and ETHERNET cable. Locate the connections according to the diagram below.
- Page 15 Step 4: Back plate installation Install the back plates for the charging station and the charger pedestal. NOTE： Before charging the charger, recheck all electrical connections after all wiring is complete. Once all chargers are powered on, the LCD screen will display the status of the chargers.
-
Page 16: Wall-Mount Charger Installation
5.2. Wall-Mount Charger Installation [Note before installation] The unit must be installed on a solid and flat wall (preferably concrete or metal). Different types of walls need to use expansion bolts, or select appropriate screws to install, and in some conditions, drilling is required. ... - Page 17 Step 3：Connect the Charger NOTE： Before charging the wall charger, recheck all electrical connections after all wiring is complete. Once all chargers are powered on, the LCD screen will display the status of the chargers.
-
Page 18: Charging Process
6. Charging Process 6.1 Charging Process Operating steps Operating interface Step 1: Touch the screen and swipe the card, and then connect the nozzle (step2- Touch the screen and connect the nozzle first, then swipe the card (step2-2) Step2-1：... - Page 19 Step 2-2: If the nozzle has been connected, please tap the card. Note: It takes a while to connect the nozzle. Step 3: Select charging method: auto full, charge by time, or charge by cost.
- Page 20 Step 4: Once the authorization is complete, this charger will start charging. Step 5: While the vehicle is charging, charging data can be viewed on the LCD screen via the touchscreen. Step 6: After the charging is completed, it will pop up message to ask for tap the card again and finish the charging.
-
Page 21: Charging
Step 7: It will display the charging capacity, charging amount, and charging time as the final screen. When charging is complete, put the charging plug back in place. NOTE: During charging period, if it’s necessary to stop charging, simply touch “ ”... -
Page 22: Led Operation
Charging cost Charging capacity Charging current Change charge type Stop button Network status 6.3. LED Operation Idle Charging Fault Stare Description EV Pole LED State A (Idle) EV Green LED State B1 Vehicle Connected EV Blue LED Vehicle Connected, State B2 EVSE Ready EV Blue LED State C... -
Page 23: Precautions
6.4. Precautions During the card swiping operation, you need to hear the buzzer beeping “di” before removing the card, otherwise the operation may fail. If the screen shows a machine failure, do not operate, please contact the staff. ... -
Page 24: Routine Maintenance
7. Routine Maintenance Due to the influence of ambient temperature, humidity, dust and vibration, the internal devices of the charger will wear out, which leads to the potential failure of the charger. Therefore, it is necessary to carry out daily and regular maintenance of charger to ensure their normal operation and its service life. -
Page 25: Trouble Shooting
8. Trouble Shooting Fault Fault Description Possible cause & What to do Code Charging gun is not in E015 After charging, put the gun wire back in place place The charging station is connected to the background, and E017 Failed to send bill the bill is uploaded after charging, but no reply is received from the background, please contact the background.
