The Haloview BT12 vehicle observation carplay monitor carry two 1080P cameras installed inside/outside of the vehicle to capture images around the vehicle while navigating and music listening. It’s a combination of carplay, dashcam and rear view real-time observation. With this system, drivers can intuitively see the obstacles and pedestrians around the vehicle, which effectively reducing the occurrence of accidents such as scratches and collisions.
Mount Base TF Card 64G C10/U1 Suction Mount 1. Static Sticker for Dashcam 2. Anti-glare film for display 3. Specifications Monitor (BT-M12) Introduction Function English/Simplified Chinese/Traditional Chinese/ Language Japanese/Korean/French/Italian/Spanish, etc Interface Graphic MENU Touch screen/Push button Short press to standby the screen. Operation Long press to turn ON/OFF Video Input...
Page 5
Real-time display 10.2" 1600*600MIPI Display Mode Single channel display and split display Local playback can be viewed at any time, Display or select the playback button to urgent-record, Playback lock or delete files, support real-time viewing and playback via mobile phones. Screen Saver 1 minute/3 minutes/5 minutes/off...
Page 6
Smart Box (BTR100) 1920 ×1080 Output Pixels Operation Frequency 2400-2483MHz Transmission Distance (barrier free) 300m (984ft) Transmission Power 18dBm H.265 Video Codec DSSS Spread Spectrum 120ms Latency RF Bit Rate 12Mbps DC11~18V Power Supply Dashcam (CA617) Image Device 1/2.9” CMOS TV System 25fps/30fps Effective Pixels...
Page 7
Viewing Angle 140° Audio Power Supply DC10~32V Waterproof rating IP69K Minimum Illumination 0.5Lux -20℃ ~ 70℃, RH95%MAX. Operating Temperature Storage Temperature -30℃ ~ 80℃, RH95%MAX. Wireless Rear View Camera (BTC128) Image Device 1/2.9" CMOS TV System 25fps/30fps Effective Pixels 1920×1080 Pixel Size 2.8um×2.8um Video Output...
5. Installation Installation Method 1: Mount Carplay Monitor on Rearview Mirror Wired Dashcam RX BOX Wireless Camera 1.5m or 3.5m cable Installation Method 2: Mount Carplay Monitor on Front Windshield by Provided Sunction Bracket Wired Dashcam Suction Mount Wireless Camera RX BOX 1.5m or 3.5m cable...
Page 10
Dashcam installation 1. Please wipe the front windshield with cleaning paper before installation. 2. Paste the provided static sticker on windshield. 3. Tear off the film of 3M glue, and then stick it on the static sticker 4. Turn the camera up and down to adjust to the appropriate angle. Reaview Camera installation...
Page 11
(the antenna is not placed on the roof of the vehicle or there is obstruction around the antenna). In this case, it is recommended to purchase the Haloview 0.6m antenna extension cable and place it on the roof without any obstacles.
6. Smart box 1. Functions of each part Camera night light switch/ Pairing button Mirror/Flip Switch Power Button NTSC/PAL Switch Smart Box Indicator 2. Indicator Status Short press to turn ON/OFF camera night light. The icon shown on the left of the screen.
7. Menu 10 : 10 Driving recorder Carplay Android auto 2020/06/19 FRI FM launch Replay Replay Setting Insert the SD card, after formatting, the system will automatically enter recording mode ① Driving recorder ② Carplay ③ Android auto (#) ④ Volume settings: volume +, volume -, previous song, next song, play, pause ⑤...
① Turn on/off recording ② Snapshot ③ Lock the video file to avoid being overwritten during loop recording ④ Turn on/off the recording sound ⑤ Switch channel of cameras ⑥ Return to the homepage ⑦ Voice command list ⑧ SD card status ⑨...
Page 15
Q: How to connect Carplay/Android auto after the device is powered off and restarted? A: After the first connection, the phone will automatically connect to the carplay monitor if the wifi and bluetooth is turned on. Q: How to use the APP RoadCam when connected to Carplay? A: When connected to Carplay, you can use the RoadCam to control the carplay monitor at the same.
Page 16
1. Tap to set the Bluetooth name 2. Turn ON/OFF the BT Switch 3. Tap Disconnect to disconnect current connection to enter FM setting Instruction 87.5 Adjust the FM frequency of the car and the device to be consistent and you can use the car audio to play.
Page 17
If Front camera selected, only dashcam will be displayed in screen in Driving recorder. If Rear camera selected, only rear camera will be displayed in screen in Driving recorder. Date watermark and Car OSD Turn on Date watermark and Car OSD, enter your license plate number. After setting, the license plate number and time will be displayed in the upper left corner of every recorded file.
Page 18
Wifi switch and Wifi info Turn ON Wifi switch and tap Wifi info. Scan code to download roadcam app. Login app with provided Wifi SSID and password. After that, it will realize real-time remote control of the device. Wifi into WIFI SSID: TF765-5c55154c WiFi PASSWORD: 12345678 WIFI description: download and...
