Summary of Contents for Barox PD-BTPMC102M-GE
- Page 1 User Manual: PD-BTPMC102M-GE Industrial Media converter lite managed with PoE af/at/bt Version 3.2021...
- Page 2 2-port 10/100/1000 Base-TX IEEE 802.3bt PoE standard to transmit data and power between 1000 Base-FX Fiber and 10/100/1000BASE-T(X) Ethernet interface. The PD-BTPMC102M-GE delivers up to 120 watts of power output to PDs. With ultra-compact hardened design and dual DC power inputs, the PD-BTPMC102M-GE offer power protection for redundancy and operate in extremely harsh conditions.
- Page 3 Power connection The PoE injector provides dual DC power input for redundancy. Each power input voltage depends on the situation of power budget to select the voltage range. Hardware Description Model Name PD-BTPMC102M-GE 2 ports LAN Interface 10/100/1000 Base-TX Power Budget...
- Page 4 Wiring the Alarm Contact The alarm contact wires are at the two middle contacts of the 6-contact terminal block connector. The two wires attached to the fault contacts form an open circuit when detecting the fault status of the power failure or the Ethernet port link fails. *Note: Only use cooper conductors.
- Page 5 Installation Procedures DIN RAIL Mounting Step STEP 1: Hook the unit over the DIN Rail. STEP 2: Push the bottom of the unit towards the DIN Rail until it snaps into place. Removal Step STEP 1: Push the unit down to free the bottom of the DIN Rail. STEP 2: Rotate the bottom of the unit away from the DIN Rail.
- Page 6 LED Definition The function of each LED indicator on the front panel is described in the table below. Color State Description PWR1 Green Power is provided from power input 1. PWR2 Green Power is provided from power input 2. Green System is working.
- Page 7 DIP Switch Configuration There are four settings for DIP switch, including Relay, LFPT, PoE, and SFP. The configuration of DIP switch is described in the table below. *Note: There are four white buttons for DIP switch. Moving the white button up position, its setting is “ON”.
- Page 8 Access the Web Configurator After properly connecting the hardware as previously explained. Launch your web browser and enter http://192.168.1.1 as URL. The default IP address, username, and password are as follows. ⚫ Default IP Address: 192.168.1.1 ⚫ Default Username: admin ⚫...
- Page 9 The system status is shown as below. This section includes Switch Port Status, PSE Port Status, Alarm Status, and DIP Switch. Page 9/13...
- Page 10 The device setting is shown as below. This section includes LAN Setting, SNTP Setting, and MISC Setting. ⚫ The SNTP server is necessary when PoE scheduling mode is on. ⚫ The situation of Relay Alarm Event is described in the table below. Item Description When the temperature is over 110 degrees C, the relay alarm event is enabled.
- Page 11 The PSE configuration is shown as below. This section includes Port Link Speed, and PSE Setting. For the PSE Setting, there are some principles to describe in the table below. Item Description ▪ The total maximum power budget is 120W. The valid power budget is as follows.
- Page 12 The Ping Setting is shown in the interface as below. Reload the device default configuration. After clicking Load Default item, it will be shown the interface as below to make sure if you are ready to load or not. Reboot the device. After clicking Reboot item, it will be shown the interface as below to make sure if you are ready to reboot or not.
-
Page 13: Hot Parts
Precautions and Safety Warnings Disconnect all power from devices before attempting installation. ● This device is intended for installation only in restricted access locations as defined where ● both these conditions apply: ▪ Access is through the use of a lock or tool and key, or other means of security, and is controlled by the authority responsible for the location.
