- Page 1 RP100-15RX RP100-20RX Power Monitoring Surge Protection Line Filtration Wiring Fault Protection OWNERS MANUAL Houston, Texas p: 713.772.1404 info@juicegoose.com www.juicegoose.com Mar 2023...
- Page 3 DISCLAIMER Juice Goose shall under no circumstances be held responsible for any loss, damage or injury resulting from the use of the RACKPOWER in a manner inconsistent with any of the procedures outlined in this docu- ment.
- Page 4 DIMENSIONS (H x W x D Inches)..........1.72 x 19.00 x 7.00 CHASSIS DESIGN............Tour Class Unibody (TM) WEIGHT (LBS)....................11 CURRENT CAPACITY RP100-15RX...…………............15 Amps RP100-20RX...…………............20 Amps VOLTAGE INPUT................120 VAC, 60Hz USB PORTS (x2).................5 VDC @ 500mA POWER OUTLETS Fifteen Amp Units............10 NEMA 5-15R Twenty Amp Units.........8 NEMA 5-15R, 2 NEMA 5-20R...
- Page 5 FRONT PANEL Combination On/Off Switch and Circuit Breaker – The rocker switch located on the right side of the chassis is a dual function component. It is normally used to manually turn the RACKPOWER on and off. In the event of a prolonged current overload the circuit breaker will trip to shut off power.
- Page 6 The Surge Protection OK LED is not lit. (See the “Front Panel” section of this manual.) This could indicate a fault with the RX Series power protection circuitry. Contact Juice Goose info@juicegoose.com or 713-772-1404) for more information.
- Page 7 JUICE GOOSE. This warranty is transferable to a repur- chaser for the period stated above. The warranty holder shall pay the cost of returning the unit to JUICE GOOSE or its designated repair lo- cation. JUICE GOOSE shall pay the cost of returning the unit to the warranty holder by normal ground parcel delivery.
- Page 8 AV control platforms such as Crestron and Q-SYS. – UPS MODELS When protection against power outage is needed, Juice Goose is a source for ten models of UPS products with options related to size, cost, power and function.
