OWNER'S MANUAL
JAXON GREY MIRROR
LIVING SPACES SKU : 241128
VENDOR ITEM NO. : 7YU683
ASSEMBLY PARTS LIST
SKU #
241128
7YU683MS
FULLY ASSEMBLED
PRE-ASSEMBLED PARTS LIST
SKU #
7YZZBPBT
DESCRIPTION
QUANTITY
MIRROR
MIRROR
SUPPORT SET
(packed with dresser)
DESCRIPTION
LARGE DECORATIVE BOLT
HARDWARE KIT PACKED IN BOX
SKU : 7YZZ83HW
SKU #
1
7YZZ83HW-1
1
7YZZ83HW-2
7YZZ83HW-3
SKU #
Scan QR code to view assembly video
DESCRIPTION
ALLEN BOLT
(M6 X 40MM)
FLAT WASHER
(M6)
ALLEN KEY
* DRESSER SOLD SEPARATELY
DESCRIPTION
QUANTITY
8
8
2
