Summary of Contents for Delixi BK Series
- Page 1 BK Series Control Transformer User Manual Standard: Q/DLX 361 □ Please carefully read this User Manual before installing and operating the product, and keep this manual properly for future reference...
- Page 2 1. Overview 1.1 BK series control transformer (hereinafter referred to as transformer) has advantages of excellent performance, reliable operation, and wide applicability, and it is usually used in the mechanical equipment as the power supply for electrical control, lighting and indicator light.
- Page 3 Primary Primary Iron core Iron core Secondary Secondary Fig. 1 Single winding Fig. 2 Discrete winding Primary Primary Iron core Iron core Secondary Secondary Fig. 4 Continuous winding with a center tap Fig. 3 Hybrid winding 3.2.3 3.2.3 For example 3.2.3.1 The Fig.
- Page 4 3.2.3.3 For example, Fig. 3 shows that for BK-200 type, the capacity is 200VA, the input voltage is 380V, and the output voltage is 36V, 24V. Because the primary side has only one winding, the capacity of this winding is the rated capacity 200VA;...
- Page 5 When 6V is used separately, the capacity is 6V x 1.05A = 6.3VA When two or more sets of voltages are used simultaneously, the sum of their currents must not be greater than 1.05A. 4 Outline Dimensions and Installation Dimensions BK series Capacity (VA) Overall dimensions: LxW×H(mm) Installation dimensions: L× W (mm)
- Page 6 5 Operation Instructions 5.1 Open the packing box, take out the manual and transformer, and carefully read the User Manual for proper operation. 5.2 The transformer is reliably fixed in the appropriate position to prevent vibration and erosion. 5.3 Before use, test whether the circuit and grid voltages are rated input voltages, and the allowable deviation is ±5%;...
- Page 7 6.3 Before use, please carefully check whether various data marked on the nameplate and accessory instructions meet your requirements, and power on the product after confirming that those parameters are correct. 6.4 After power-on, the transformer core and coil will heat up (but the temperature rise does not exceed 80K), and this is a normal phenomenon.
- Page 8 Standard: Q/DLX 361 Inspector: Check 05 Zhejiang Delixi Electrical Co., Ltd. Production date: See product or package Manufacturer: Zhejiang Delixi Electrical Co., Ltd. Address: No. 155, Zhandong Road, Liushi Town, Yueqing City, Zhejiang 325604 Tel: (86-577) 61778888 Fax: (86-577) 61778000 Customer Service Hotline: 400-826-8008 www.delixi-electric.com...
