- Page 1 Technical Specifications ® DECTRIS EIGER 2 X 9M-V Document Version v1.8.1 DECTRIS Ltd. 5405 Baden-Daettwil Switzerland www.dectris.com...
- Page 2 Document Version v1.8.1 © Copyright 2023 DECTRIS Ltd.
-
Page 3: Table Of Contents
Checking the Connection ........25 ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1... - Page 4 Cleaning and Maintenance ......... . 30 TROUBLESHOOTING ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1...
-
Page 5: Document History
Fixed EIGER2 vacuum operation and updated trademarks. v1.8.0 2022-03-22 Documenting new features from release 2022.1 v1.8.1 2023-02-10 Updated frame rates and 8 bit mode for X and XE systems. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 iii | 33... -
Page 6: General Information
1. GENERAL INFORMATION 1.1. Contact and Support Address: DECTRIS Ltd. Taefernweg 1 5405 Baden-Daettwil Switzerland Phone: +41 56 500 21 02 Fax: +41 56 500 21 01 Homepage: http://www.dectris.com/ Email: support@dectris.com Should you have questions concerning the system or its use, please contact us via telephone, mail or fax. -
Page 7: Warranty Information
(in particular information, images or ® materials), unless otherwise indicated. Without the written permission of DECTRIS it is prohibited to integrate the protected contents in this publication into other programs or other websites or to use them by any other means. -
Page 8: Use Of The Eiger2 X 9M-V
The EIGER2 X 9M-V hybrid-photon-counting (HPC) detector system has been designed for the detection of X-rays produced ® by synchrotrons or laboratory sources. It is intended for indoor use only. For other applications, please contact DECTRIS technical support for additional information. -
Page 9: Technical Specifications
Dimensions (W x H x D) 340 mm x 370 mm x 500 mm Weight 45 kg Overvoltage category Single threshold. Using two thresholds halves the frame rate. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 4 | 33... -
Page 10: Ratings
EIGER2 9M-V power supply power output Ouput 1 and 2: 48 VDC, 8.3 A, 400 W AC connector IEC-320-C20 input inlet Warning Only use cables rated for 16 A. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 5 | 33... -
Page 11: Detector Control Unit
3.2.4. Thermal Stabilization Unit Information Please consult the user documentation of the SMC HRS-012A thermal stabilization unit for details. Caution The maximum allowable coolant pressure is 3 bar. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 6 | 33... -
Page 12: Ambient Conditions
• Make sure the temperature and the humidity inside the transport box does not exceed the specified range (use of a drying agent is required). • Ensure that no condensation moisture develops if the detector is stored at low temperature. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 7 | 33... -
Page 13: Detector Dimensions And Connectors
4.1.1. Technical Drawing Information ® 3D step files of the EIGER2 X 9M-V detector are available on request. Please contact DECTRIS technical support for more information. Figure 4.1: Drawing of the EIGER2 X 9M-V Detector (also printed separately in the user documentation folder) ®... -
Page 14: Front Side Of The Detector
Do not apply any force on the screws, the screws do not need to be tightened to hold the cover in place and excessive force can damage the housing. Figure 4.2: The EIGER2 X 9M-V Detector with the Cover Removed (front view) ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 9 | 33... -
Page 15: Back Side Of The Detector
4.1.3. Back Side of the Detector Figure 4.3: The EIGER2 X 9M-V Detector (back view) ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 10 | 33... -
Page 16: Status Leds
Do not replace the optical transceivers, as proper function of the detector system cannot be guaranteed otherwise. Please contact support@dectris.com if you need replacement transceivers. Caution There must be a 4 x LC/UPC duplex connectors point- to-point connection between detector and detector control unit. - Page 17 Plug dry-break double shut-off. Caution For in-vacuum operation do not use the standard con- nectors. A specific vacuum feedthrough set containing ® all required parts is available from DECTRIS ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 12 | 33...
-
Page 18: High Voltage Interlock
The detector status LED returns to solid green if the de- tector was initialized before the interlock was opened and blinks green otherwise. If the LED stays red, check the troubleshooting steps in chapter 8. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 13 | 33... -
Page 19: Eiger2 9M-V Power Supply
Information ® 3D step files of the EIGER2 9M-V Power Supply are available on request. Please contact DECTRIS technical support for more information. Figure 4.4: Drawing of the EIGER2 9M-V Power Supply (also printed separately in the user documentation folder) ®... -
Page 20: Front Side Of The Power Supply
Green when the DC output is enabled, red when it is disabled. Reasons for a disabled output include detector overheating, a dis- connected DC power cable or an internal error. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 15 | 33... -
Page 21: Connectors And Connecting Cables
Using the web front end, it is possible to restart the EIGER2 control service, trigger an update, and to shut down and to reboot the detector control unit. Any further control of the detector is carried out via the SIMPLON API (see separate documentation). ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 16 | 33... - Page 22 Briefly pushing the power button on the front panel will shut down the detector control unit. May take up to 1 min. Figure 4.8: Back view of detector control unit with labeled network interfaces. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 17 | 33...
-
Page 23: Connectors
Table 4.9: Operating Conditions Condition Definition Operating temperature The thermal stabilization unit has to be set to a temperature of 23 °C for normal operation. Maximum operating pressure 3 bar ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 18 | 33... -
Page 24: In-Vacuum Operation
For in-vacuum operation unscrew the self-sealing valves from the detector and use vacuum-compatible fittings and o-rings. The water connectors use an 3/8 inch ISO parallel thread. Before opening the cooling circuit always remove the coolant to avoid dripping. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 19 | 33... - Page 25 Prior to powering up and operating the detector in-vacuum the thermal stabilization unit has to be set to a temperature of 17 °C for at least 30 min. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 20 | 33...
-
Page 26: Installing The Detector System
It is strictly forbidden to add any threads to the detector base plate or to the detector housing. The detector should be mounted using the four internal M6x1 threads as shown in figure 5.1 (indicated with yellow circles). ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1... -
Page 27: Mounting From Above
The detector should be mounted using all four outer 7 mm holes (indicated with yellow circles). Caution Make sure the mounting brackets are mounted and properly tightened using the screws provided. The placement of the screws is indicated with diamonds in figure 5.2. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 22 | 33... -
Page 28: Grounding Of The Detector
Although the detector might be already grounded via the mounting bolts, the detector should be grounded additionally via the functional ground connector at the back in order to establish a defined grounding. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1... -
Page 29: Connection To Dry Air Or Nitrogen
Detectors used in vacuum need different optical cables. For information about vacuum cables, refer to the vacuum ® feedthrough set specifications or contact DECTRIS support. 5.5.1. Installing the Cables The fiber optic cables come with a pulling eye to make cable installation easier and a cable sock to protect the connectors. -
Page 30: Checking The Connection
Do not add any component other than those supplied by DECTRIS to the cooling circuit. Using the wrong material in the ® cooling circuit leads to galvanic corrosion, which can permanently damage the detector. Contact DECTRIS support at support@dectris.com in case the supplied components are not compatible with your setup. -
Page 31: Mounting The Detector Control Unit
The mains plug of the detector control unit has to be connected to a grounded power outlet. The detector control unit can be mounted in a standard 19 inch rack, which has to be properly grounded. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1... -
Page 32: Temperature And Humidity Control
5.4. Then restart the software. Information A free-flowing air stream is mandatory in order to properly cool the electronics inside the detector. Do not cover any ventilation holes. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 27 | 33... -
Page 33: Operation Procedure
• Do not remove the nitrogen/dry air connection. It is a requirement that it is left at the recommended flow rate according to section 5.4. Warning As long as the detector power cable is connected, the detector has to be considered under power. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 28 | 33... -
Page 34: Vacuum Operation
7.4. Vacuum Operation ® −3 The DECTRIS EIGER 2 X 9M-V is designed to be used in vacuum. The typical reachable vacuum is 10 mbar (read-out electronics in vacuum). The outgassing rate and content are not specified. The vacuum compatibility guarantees that the detector will operate in the mentioned vacuum range and has been tested in vacuum. -
Page 35: Storing The Detector
® ® The Mylar foil must not be touched or cleaned. If it is damaged, please contact DECTRIS technical support. The detector housing can be cleaned with a soft tissue. The EIGER2 X 9M-V detector does not require any maintenance. -
Page 36: Troubleshooting
Table 8.1 provides an overview of possible problems with the detector system and instructions in order to solve the problems. If the problem you are experiencing is not listed below or if the instructions do not help, please contact support@dectris.com. - Page 37 Ambient humidity around the detector Shut down the detector immediately exceeds the operating conditions. and check the humidity. Power up the detector only when the ambient hu- midity has been reduced. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1 32 | 33...
- Page 38 ”DECTRIS INSTANT RETRIGGER”, ”DECTRIS MYTHEN”, ”DECTRIS PILATUS”, ”DECTRIS QUADRO”, ”DECTRIS SANTIS”, ”DECTRIS SÄNTIS”, ”DECTRIS SINGLA”, ”DECTRIS TITLIS”, ”DETECTING THE FUTURE” © 2/ 2023 DECTRIS Ltd., all rights reserved • Subject to technical modifications. ® DECTRIS EIGER 2 X 9M-V Technical Specifications v1.8.1...
