WOLF
Multi-Band Signal Meter
BANDS SUPPORTED
SENSITIVITY
Adj. Chan. Rejection:

RECEIVER MODES

GENERAL SPECIFICATIONS

Dual Conversion:
IF Bandwidth:
Stability:
Phase Noise:
Antenna:
Controls:
Warm Up Time:
Power:
Weight:
Dimensions:
Wolf™ output data supports
Microsoft Excel spreadsheets as
well as the included Wolf-Pack™
Real-time Indoor/Outdoor
Mapping solution
PocketPC®. No GPS required.
Berkeley Varitronics Systems, Liberty Corporate Park, 255 Liberty Street, Metuchen, NJ 08840
Phone 732-548-3737 • Fax 732-548-3404 • www.bvsystems.com • E-mail: info@bvsystems.com
TM
Cellular:
PCS:
-118 to -30 dB + 1 dB
>45 dB @ 30 kHz
Single Channel
Multiple Channel (user selectable or sweep)
83 MHz first IF, 455 kHz second IF
30 kHz (Cellular) 50 kHz (PCS)
+ 2.5 PPM Temp range 32° to 120 F°
> 80 DBC @ 1 kHz
SMA Female 50 ohm
iPAQ PocketPC
< 3 minutes
Internal battery power (4 AA Ni-MH batteries in receiver)
3 lbs.
2" H x 4" W x 6" L (water resistant, high impact ABS plastic case)
on iPAQ
868-896 MHz
Downlink (Blocks A through F) 1930-1990 MHz
Wolf™ Receiver
includes all of the following:
Wolf calibrated receiver
Wolf Software
Wolf-Pack Mapping Software
HP iPAQ PDA PocketPC
iPAQ charger/cradle
Wolf/iPAQ expansion pack
3 dBi small SMA antenna
8 Ni-MH batteries
Ni-MH fast charger
Backup CF Installer
Optional:
Direction Finding Antenna
System
