iSmartEV DP750 User Manual
Copyright Information
Copyright © 2021 by SHENZHEN SMARTSAFE TECH CO.,LTD. All rights
reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording or otherwise, without the prior written permission of
SMARTSAFE.
Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this
unit or third parties for damages, losses, costs, or expenses incurred by
purchaser or third parties as a result of: Accident, misuse, or abuse of this
unit, or unauthorized modifications, repairs, or alterations to this unit, or
failure to strictly comply with SMARTSAFE operating and maintenance
instructions. SMARTSAFE shall not be liable for any damages or problems
arising from the use of any options or any consumable products other than
those designated as Original SMARTSAFE Products or SMARTSAFE
Approved Products by SMARTSAFE.
All information, specifications and illustrations in this manual are based on
the latest information available at the time of printing. SMARTSAFE reserves
the right to make changes at any time without prior written or oral notice.
Trademark Information
SMARTSAFE is a registered trademark of SHENZHEN SMARTSAFE TECH
CO.,LTD. in China and other countries. All other SMARTSAFE trademarks,
service marks, domain names, logos, and company names referred to in this
manual are either trademarks, registered trademarks, service marks, domain
names, logos, company names of SMARTSAFE or are otherwise the
property of SMARTSAFE or its affiliates. In countries where any of the
SMARTSAFE trademarks, service marks, domain names, logos and
company names are not registered, SMARTSAFE claims other rights
associated with unregistered trademarks, service marks, domain names,
logos, and company names. Other products or company names referred to
in this manual may be trademarks of their respective owners. You may not
use any trademark, service mark, domain name, logo, or company name of
SMARTSAFE or any third party without permission from the owner of the
applicable trademark, service mark, domain name, logo, or company name.
You
may
contact
SMARTSAFE
by
visiting
the
website
at
www.newsmartsafe.com, or writing to SHENZHEN SMARTSAFE TECH
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iSmartEV DP750 and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartSafe iSmartEV DP750

  • Page 1 SMARTSAFE. Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this unit or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: Accident, misuse, or abuse of this...
  • Page 2 DP750 User Manual www.newsmartsafe.com CO.,LTD., 3310, Building 11, Tianan Cloud Park, Bantian Street, Longgang District, Shenzhen, Guangdong, China, to request written permission to use Materials on this manual for purposes or for all other questions relating to this manual.
  • Page 3: Table Of Contents

    DP750 User Manual Contents 1. Packing List ................1 2. Product Introduction ..............3 2.1 Overview .................3 2.2 iSmartEV DP750 ..............3 3. Technical Parameters .............. 7 4. Equipment Operation ...............9 4.1 Equipment Startup ..............9 4.2 LV Output ................9 4.3 HV Output ................10 5.
  • Page 5: Packing List

    DP750 User Manual 1. Packing List The following accessories are for reference only. Please consult from the local agency or check the package list supplied with this equipment together. Main Unit and Accessories Name Q'TY Reference Picture: iSmartEV DP750...
  • Page 6 DP750 User Manual www.newsmartsafe.com HV Jumper Cable (4mm Banana Plug) LV Wire (Alligator Clip-Fits) LV Wire (Alligator Clip-Fits) Certification User Manual Packing list...
  • Page 7: Product Introduction

    DP750 User Manual 2. Product Introduction 2.1 Overview iSmartEV DP750 Adjustable Digital Power Supply for automobile maintenance is a dual-output switching DC stabilized voltage supply developed by SmartSafe Company for both new energy vehicles and fuel vehicles. This product has stable current output, excellent performance indicators, and a variety of protection mechanisms.
  • Page 8 DP750 User Manual www.newsmartsafe.com Name and Description Handle Buzzer Hole The buzzer will keep sounding when the HV output. Display Area for LV Value Display the current LV output value. LV ON/OFF Button Turn on/off LV output. Under LV output, the LED light (green) of the button is always on;...
  • Page 9 DP750 User Manual HV Output Port It includes HV positive and negative electrode interface, a dustproof cover, and fool-proof and anti-reverse connection design. HV ON/OFF Button Start/Stop HV output. Under HV output, the LED light (orange) of the button is always on; When the HV is not output, the LED light (orange) of the button is off.
  • Page 10 DP750 User Manual www.newsmartsafe.com displayed. Display area for HV Current Value The current set voltage is displayed when the high-voltage output is not started, and the actual output voltage is displayed after the high-voltage output is started. Power Supply Input Air Vent for Heat Dissipation Air vent of cooling fan, with a dust screen.
  • Page 11: Technical Parameters

    DP750 User Manual 3. Technical Parameters Technical Indexes Power Supply Input AC 100~240V@16A Power 3200W Max Voltage Range 250~750V Current Range 0~5A Voltage Sampling 0.1V Accuracy Current Sampling 0.1A Accuracy Current-limiting protection, short-circuit Output protection, undervoltage protection, Protection...
  • Page 12 DP750 User Manual www.newsmartsafe.com Input-output:2000Vac 50Hz (2828Vdc) 1 minute Insulation and Input-earth: 2000Vac 50Hz (2828Vdc) 1 Resisting minute Voltage Output-earth: 2000Vac 50Hz (2828Vdc) 1 minute Output DC 12V/24V (switch with buttons) Voltage Output Parameters Current Output Short-circuit protection Protection Working -10~65°C...
  • Page 13: Equipment Operation

    DP750 User Manual 4. Equipment Operation 4.1 Equipment Startup (1) Pull down the circuit breaker handle. (2) After confirming that voltage of input power supply is correct, connect two ends of the power cord to the power socket and the power input respectively.
  • Page 14: Hv Output

    DP750 User Manual www.newsmartsafe.com 4.3 HV Output (1) Rotate the HV current adjusting knob and the HV voltage adjusting knob to set the required current and voltage values. (2) Remove the dust-proof cover of the HV output port, and insert...
  • Page 15 DP750 User Manual of the button is always on, the buzzer keeps sounding, and the digital power supply supplies power to the device under test according to the set voltage value. Note: The voltage and current cannot be adjusted during the HV output of the equipment;...
  • Page 16: App Operation

    DP750 User Manual www.newsmartsafe.com 5. APP Operation In addition to operating directly on the main unit, iSmartEV DP750 can also be used with other detection devices (such as iSmartEV P01) to operate via Bluetooth wireless connection. 5.1 APP Launching (1) Tap Digital Power on the detection device to launch the APP.
  • Page 17 DP750 User Manual Name and Description Exit Tap this button to exit the APP. Display Area for LV Value Display the current LV output value. LV Setting Button Tap this button to switch the LV gear, including gears of 12V and 24V.
  • Page 18: Bluetooth Button

    DP750 User Manual www.newsmartsafe.com 5.2 Bluetooth Button (1) Tap the Bluetooth button in the upper right corner (the icon is shown as when Bluetooth is not connected) to pop up the device selection window, and select the serial number of the current digital power supply for connection.
  • Page 19: Hv Output

    DP750 User Manual (2) Tap the "LV ON/OFF Button", and the digital power supply will supply power to the device under test according to the set voltage value. If it is required to stop the LV output, Tap the "LV ON/OFF Button"...
  • Page 20 DP750 User Manual www.newsmartsafe.com Note: Digital power supply output is not affected after exiting the APP. The digital power output can be turned off only after the "LV ON/OFF button" and "HV ON/OFF button" are turned off.
  • Page 21: Equipment Protection

    DP750 User Manual 6. Equipment Protection 6.1 Power Iutput Protection Mechanism The iSmartEV DP750 protects the input circuit through a circuit breaker. When the fault protection is triggered, the circuit breaker will automatically cut off the power supply of the equipment.
  • Page 22 DP750 User Manual www.newsmartsafe.com Stop output immediately, and "Check the equipment" is Output Overcurrent displayed Stop output immediately, and "Check the equipment" is Output Short-circuit displayed Overtemperature Stop output immediately, and "Check the equipment" is Protection displayed Stop output immediately, and "Check the equipment" is...
  • Page 23: Fcc Warnning

    DP750 User Manual FCC Warnning Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to...
  • Page 24: Warranty

    The exclusive remedy for any automotive meter found to be defective is repair or replacement, and SMARTSAFE shall not be liable for any consequential or incidental damages.
