Our products are designed to be used correctly and with care for the purpose
for which they are intended. No liability is accepted by the Tool Connection for
incorrect use of any of our products, and the Tool Connection cannot be held
responsible for any damage to personnel, property or equipment when using the
tools. Incorrect use will also invalidate the warranty.
If applicable, the applications database and any instructional information provided
has been designed to offer general guidance for a particular tool's use and while
all attention is given to the accuracy of the data no project should be attempted
without referring first to the manufacturer's technical documentation (workshop or
instruction manual) or the use of a recognised authority such as Autodata.
It is our policy to continually improve our products and thus we reserve the right to
alter specifications and components without prior notice. It is the responsibility of
the user to ensure the suitability of the tools and information prior to their use.
7405_Instructions_V2
www.lasertools.co.uk
Advertisement
Summary of Contents for Laser 7405
- Page 1 Our products are designed to be used correctly and with care for the purpose for which they are intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and the Tool Connection cannot be held responsible for any damage to personnel, property or equipment when using the tools.
-
Page 2: Jump Starter
Part No. 7405 Jump Starter Multi-Function Instructions www.lasertools.co.uk... - Page 3 Introduction This multi-function Jump Starter is an efficient but extremely compact emergency engine starting power pack and mobile power bank. It also features a bright LED to illuminate the work area (flashing mode can be used as an emergency beacon), two USB outputs (for charging mobile phones, etc), a Type-C input/output port and a digital voltage display on the cable clamp adaptor.
- Page 4 Controls Fig 1 Ref. Description Main ON / OFF switch LED flashlight power button Power indicator Jump-start port Output 2 (5V 2.1A) Output 1 USB 3.0 (3.6V – 12V; 1.5A – 3A) Type C input/output port (5V / 3A) LED flashlight www.lasertools.co.uk...
- Page 5 Instructions MICRO TYPE C TYPE C Fig 2 Note: On first purchase of the Jump Starter, the unit must be charged until the power/charging LED display (3) shows four indicator lights ON. Then it must be charged every eight to twelve weeks to avoid damage to the battery.
- Page 6 Instructions LED Flashlight: • Refer to Figure 1: turn on / off switch (1) to ON. • Press LED flashlight power button (2) and hold for 3 seconds: LED torch illuminates and stays on. • Press button again: LED flashes SOS. •...
- Page 7 Instructions Vehicle Starting Procedure: Note: Always refer to the vehicle manufacturer’s documentation (handbook or workshop manual) for their recommended jump start instructions. Fig 4 1. Switch all of the vehicle’s electrical devices OFF. 2. Wear eye protection. 3. Refer to Figures 3 and 4. Peel back the cover to the jump start port (4) and connect the cable clamp adaptor (connect firmly).
- Page 8 Instructions 6. Connect the supplied red cable clamp to the (+) positive terminal of the vehicle’s battery first. Then connect the black cable clamp to the (-) negative terminal of the vehicle’s battery. Screen will now display available voltage. 7. Start the vehicle. Limit your starting attempts to a maximum of 4-5 seconds at a time.
-
Page 9: Product Specifications
Product Specifications Capacity: 7200mAh / 26.64Wh (watt hours) / 3.7V Output voltage: 12V Vehicle Start current: 350 Amps Peak current: 700 Amps USB output 1: USB 3.0 (3.6V – 12V; 1.5A – 3A). USB output 2: 5V / 2.1A Type C input/output port: 5V / 3A Battery life: 1000 cycles... - Page 10 Precautions • Danger of sparking: (explosion risk) if vehicle battery has recently been charged, ensure area is well ventilated and ensure eye protection is worn before connecting up the Jump Starter. • Danger of sparking: do not connect up the Jump Starter if there are any fuel leaks or fuel vapour present.
-
Page 11: Error Messages
Error Messages Under certain conditions, error messages may be displayed on the cable clamp adaptor LCD screen: LOW VOLTAGE: When cable clamp adaptor is plugged into device — charge device. HIGH VOLTAGE: When cable clamp adaptor is plugged into device, flashing 888. REVERSE CHARGING: When device is connected up to car battery (current drain). - Page 12 Error Messages REVERSE POLARITY: When battery clamps are connected the wrong way round, e.g., red (positive) clamp connected to (negative) battery terminal. OVERHEAT: Device may overheat after repeated start attempts. SHORT CIRCUIT: When cable clamp adaptor is plugged into device, indicates internal fault. www.lasertools.co.uk...
