About the Projector Safety Instructions Please read all instructions before using the laser projector (hereinafter referred to as “the Product”) and keep them properly for further reference. Instructions Make sure to read all safety and operation instructions before using the Product. Notes and warnings Make sure to follow all notes and warnings in the instructions.
Page 3
About the Projector Notes of AC Power Line The AC power line must conform to the requirements of state (region) where the Product is used. Please confirm the type of your AC power line plug according to the following diagram and make sure to use the AC power line correctly.
Page 4
About the Projector Disclaimer All rights reserved · Do not reprint All software and hardware of the Product are owned by the Company. No imitation, copying, extraction or translation is allowed unless otherwise permitted by the Company. The Manual has no guarantee, standpoint expression or other implications in any form. For any direct or indirect data loss, benefit loss or business termination due to the Manual or any product information in it, the Company and its staffs should not bear any liability.
Features Introduction Features Based on high-performance optical engine projection technology, user-friendly design, high reliability and simple operation, the Product has the following features: •Color mode offers different options for different projectors •D-Sub 15-pin terminal can be connected to analog video •Fitted with HDMI connection, support HDCP •Correct the distorted and deformed images based on digital trapezoidal distortion correction •RS-232 interface supports serial control...
About the Projector List of Articles Confirm the following objects while unpacking the projector: Projector Remote controller Power line VGA signal line User’s manual Quick tour Certificate Note • For any shortage and damage of articles or machine failure, please contact the dealer immediately.
Product Overview Product Overview Appearance of projector Front and top side 1. Lens 2. Infrared remote sensor 3. Loudspeaker (Configured in Type FHD only) 4. Focusing lever 5. Status indicator 6. Power key 7. Signal source key Bottom and lateral side 8.
Page 9
Product Overview Backside 1. HDMI OUT 5. COMPUTER IN 2. HDMI 6. AUDIO IN 3. MINI USB 7. AUDIO OUT 4. RS-232 8. USB A 5V/1.5A Note •HDMI OUT applies to Type FHD only. •The Product can be supported by a lifting frame. The lifting frame is excluded in the product package.
Connection of Projector Installation Connection of projector Connection of external computer/laptop AV device charger Louds Display peake Computer HDMI OUT interface applies to Type FHD only Steps Steps Signal source...
Power on/off Projector Power on/off Projector Power on projector Turn on the projector 1. Finish the wiring of AC power line and signal line of peripheral equipment. 2. Press button on control panel or “POWER” button on remote controller to power on the Product.
Adjustment of Projector Height and Focusing Adjustment of Projector Height The Product is fitted with three adjusting pins to adjust the image height. Rotate to ascend/descend the pins to ascend or descend the images slightly. Note •Make sure the adjusting pins are fully retracted before the Product is put in the packaging box to avoid damage.
Control Panel and Remote Controller Adjustment of Projector Image Size Diagonal of screen Screen Lens center Vertical offset Projection distance Screen Size (XGA) Projection Distance Vertical Offset Distance Diagonal Width Height Wide tele inch~ inch inch inch inch inch 40.0 30.0 1.96 2.20...
Control Panel and Remote Controller Control Panel Control Panel and Remote Controller Power Signal source Power on or turn off the Product Search signal source Item Power switch Switch projection proportion of image Switch to HDMI signal Switch to wireless projection Switch to VGA signal Switch signal source Fast forward...
Battery Installation Battery Installation 1. Open the battery cover according to the direction in diagram. 2. Install the battery in the chamber according to the diagram. 3. Close the battery cover. Caution •Explosion may occur if the replaced batteries have wrong type. •Please handle the waste batteries according to the instructions.
Operation of Remote Controller Operation of Remote Controller Point the remote controller at the sensor of infrared remote control and press the button. An IR remote controller sensor is arranged in front of the Product. Hold the remote controller and keep a right angle within 30°...
Steps of Operation Menu Operation The Product offers multi-language display menu to adjust the image and change the settings. Steps of operation 1. Press the menu to open OSD menu. 2. When it displays OSD, press ▲/▼ to select any function on the main menu. 3.
Pictures Pictures Color mode The different pictures have corresponding preset values. • Standard: Maximize the brightness of projection image. This mode applies to the environment that requires super brightness. • Computer: Maximize the purity of RGB color, in order to provide the real pictures. •...
Page 19
Pictures Sharpness Press ◄/► to select the required items. The image will be clearer if the value is higher, or the image will be softer if the value is lower. Gamma The relationship between the input signal source and image brightness. Enter the picture >...
Display Display Width-height ratio Selections to make image match screen: • Auto: Adjust the image size proportionally, in order to make the horizontal width or vertical width match the Product’s natural resolution. It is wished to fully utilize the screen without adjusting the width-height ratio of source image.
Page 21
Display Rim angle adjustment 1. The screen displays the OSD of 4 rim angle adjustment. 2. Select the to-be-adjusted rim angle and the selected area will become red. 3. Two angles can be adjusted. 4. Save the settings and then close OSD menu. How to reset rim edge adjustment: •Press “Enter”...
3D Settings 3D Settings 3D Image Format: Auto, off, frame sequential, frame encapsulation, top and bottom, abreast 3D inversion Enabled/disabled DLP Link: Enabled/disabled...
Basic Basic Demo timer The demo timer can demonstrate time on the screen, to better control the time during demonstration. Please use this function as follows: • Select the timer interval and press ◄/► to confirm the last period. The last period can be set as 1 –...
Page 25
Basic Image Enable/disable •The Product can display the test pattern to help you confirm the color correctness of projected image Blank timer Disabled/5min/10min/15min/20min/25min/30min •Draw the attention of audience to the demonstrator during demonstration. You can press “Blank screen” to hide the screen image. Press any key on the Product or remote controller to recover the image display.
Advanced Advanced HDMI setting HDMI format: RGB/TUV/auto •RGB: Change color space as RGB. •YUV: Change color space as YUV. •Auto: Set the Product to have auto detection of color space settings. HDMI range: Auto/normal/enhanced •Enhanced: Change HDMI color range as 0-255. •Normal: Change HDMI color range as 16-235.
Page 27
Advanced Projector Position Front projection on desk/back projection on desk/hoisting back projection/hoisting front projection •Front projection on desk: For this position, the Product is placed right in front of screen. This is the most common installation method of the Product. The installation position can be arranged quickly and it has high mobility.
Information Information Signal source Display the current signal source Color mode Display the modes selected in color mode menu Resolution Display the original source resolution of input signals Color system Display the input system: RGB or YUV Hardware version Display the hardware version...
Wireless Projection Wireless Projection Search the current wireless network and enter password; finish wireless projection by referring to the equipment Main chip RK3036 Dual-core A7 up to 1.0ghz Flash 128M 128M Androi Android 4.4 and above IOS8 and above Windo Supported Windows 8.1 and above system...
Page 30
Wireless Projection Operation Guide Method 1: Projection via hot spot of projector 1. Power on the Product, enter the wireless 2. When devices, such as mobile phone, tablet projection interface and the default interface is PC and computer, are connected to SSID, it as shown below.
Page 31
Wireless Projection Operation Guide iPhone: Step 1 Step 2 Step 3 Enter the setting menu of Find mirror image option in The device names shown in mobile phone and find the the drop-down menu, click the diagram below will be network name as shown in screen mirror image and find searched automatically in the...
Page 32
Wireless Projection Operation Guide Windows computer: Step 2 Step 1 Step 3 Press shortcut key Win + P to Find the device name shown Find the network name as enter the projection interface, in Fig. 2 in the pop-up shown in Fig.1,enter password a shown in diagram below, connection dialogue box, and click “Connect’...
Page 33
Wireless Projection Operation Guide Step 6: The Product displays the Step 5: Based on the step Step 4: Find the name of interface as shown in diagram above, enter the interface as target wireless network, below. Implement projection of shown in diagram below, enter double click to enter the device, please refer to Method 1 the password in the Password...
Page 34
Wireless Projection Operation Guide iPhone Android mobile phone Windows computer Apple computer iPad Topological diagram of device connection Android tablet iPhone Android mobile phone Windows computer Hot spot of projector Apple computer iPad Android tablet PC 1. Support the interaction of multiple systems, platforms (Android, Ios and Windows) and multiple screens;...
Maintenance Maintenance The Product should be maintained properly. Keep the lens clean; otherwise, the dust or spots will be projected on the screen and reduce the image quality. Please contact the dealer or professional technicians before replacing any part. Make sure to power off the Product and unplug the power line prior to cleaning of any part of the Product.
Specification Dimensions 300mm 107mm 270mm Hoisting Installation 170mm 160mm Note: It is suggested to use M4/L7 screws to fix the project which uses M4 screw holes for hoisting. (M4/L7×4)
Annex Annex Troubleshooting Please refer to the fault phenomenon and troubleshooting methods below before sending the Product for maintenance. If the problem remains, please contact the local dealer or service center. Startup If indicator lamps are off: •Make sure to firmly connect one end of power line to the Product and connect another end to the electrified power socket.
RS-232 Command and Configuration RS-232 Command and Configuration (ASCII) RS-232: 9-PIN Type D interface applies to connection of PC control system and continuous connection of the Product RS-232 (RS-232 control): Connect the Product to PC or control system to realize remote control of the Product through standard 9-pin cables (through serial cable directly).
Page 40
RS-232 Command and Configuration ASCII code Function Command return remark Power Off [POWR0] Power On [POWR1] Power read [POWR?] [POWR*] *=0~1 Color Mode_standard [DPMO0] Color Mode_computer [DPMO1] Color Mode_ Presentation [DPMO2] Color Mode_ Photo [DPMO3] Color Mode_Movie [DPMO4] Color Mode_ read [DPMO?] [DPMO*] *=0~4...
Page 42
RS-232 Command and Configuration Function Command return remark Color managemwnt Green Hue - [HGGH-] Color managemwnt Green Hue [HGGH***] ***=-99~99 Color managemwnt Green Hue read [HGGH?] [HGGH***] ***=-99~99 Color managemwnt Green [HGGS+] Saturation + Color managemwnt Green [HGGS-] Saturation - Color managemwnt Green [HGGS***] ***=0~199...
Page 43
RS-232 Command and Configuration Function Command return remark Color managemwnt Cyan Hue read [HGCH?] [HGCH***] ***=-99~99 Color managemwnt Cyan [HGCS+] Saturation + Color managemwnt Cyan [HGCS-] Saturation - Color managemwnt Cyan [HGCS***] ***=0~199 Saturation Color managemwnt Cyan [HGCS?] [HGCS***] ***=0~199 Saturation read Color managemwnt Cyan Gain + [HGCG+]...
Page 44
RS-232 Command and Configuration Function Command return remark Color managemwnt Yellow [HGYS-] Saturation - Color managemwnt Yellow [HGYS***] ***=0~199 Saturation Color managemwnt Yellow [HGYS?] [HGYS***] ***=0~199 Saturation read Color managemwnt Yellow Gain + [HGYG+] Color managemwnt Yellow Gain - [HGYG-] Color managemwnt Yellow Gain [HGYG***] ***=5~195...
Page 45
RS-232 Command and Configuration Function Command return remark Corner Left Top Y - [TLCY-] ***=0~200 According to the angle of DMD & Corner Left Top Y [TLCY***] Keystone & input source ***=0~200 According to the angle of DMD & Corner Left Top Y read [TLCY?] [TLCY***] Keystone &...
Page 46
RS-232 Command and Configuration Function Command return remark ***=0~200 According to the angle of DMD & Corner Right Bottom Y read [BRCY?] [BRCX***] Keystone & input source Position V + [VPOS+] Position V - [VPOS-] Position V [VPOS**] *=-5~5 Position V read [VPOS?] [VPOS**] *=-5~5...
Page 47
Command return remark 3D Sync Invert Off [TDIV0] 3D Sync Invert On [TDIV1] 3D Sync Invert read [TDIV?] {TDIV*] *=0~1 DLP Link Off [TDDL0] DLP Link On [TDDL1] DLP Link read [TDDL?] [TDDL*] *=0~1 Audio Mute [AMUT0] Audio Mute [AMUT1]...
Page 48
RS-232 Command and Configuration Function Command return remark Timer Counting Direction Down [TMCD0] Timer Counting Direction Up [TMCD1] Timer Counting Direction read [TMCD?] [TMCD*] *=0~1 Start Counting No [TMSC0] Start Counting Yes [TMSC1] Start Counting read [TMSC?] [TMSC*] *=0~1 Pattern Off [TPRN0] Pattern On [TPRN1]...
Page 50
RS-232 Command and Configuration Function Command return remark Language French [LANG1] Language German [LANG2] Language Italiano [LANG3] Language Spanish [LANG4] Language Russian [LANG5] Language Chinese [LANG6] Language Simple Chinese [LANG7] Language Japanese [LANG8] Language Korean [LANG9] Language Swedsh [LANG10] Language Dutch [LANG11] Language Turkish [LANG12]...
Page 51
RS-232 Command and Configuration Function Command return remark Projector Position read [PJPS?] [PJPS*] *=0~3 Menu Display Time [MUDT*] Menu Display Time read [MUDT?] [MUDT*] *=0~5 Menu Position TOPLEFT [MUPS0] Menu Position TOPRIGHT [MUPS1] Menu Position CENTER [MUPS2] Menu Position BOTTOMLEFT [MUPS3] Menu Position BOTTOMRIGHT [MUPS4]...
Page 52
RS-232 Command and Configuration Function Command return remark Password acitive [PINP******] ******=password 1~4 Setting [KYPA1] Back [KYPA2] Home [KYPA3] [KYPA4] Down [KYPA5] Left [KYPA6] Right [KYPA7] Volume + [KYPA8] Volume - [KYPA9] Mute [KYPA10] Source [KYPA11] Enter [KYPA12] Auto [KYPA13] Fast Forward [KYPA14] Fast Reverse...
Page 53
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
