Summary of Contents for Nuvo NV-M3
-
Page 2: Important Safety Instructions
ENGLISH Danger Exposure to extremely high noise levels may cause a permanent hearing loss. Individuals vary considerably to noise induced hearing loss but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient time. The U.S. Government's Occupational Safety and Health Administration (OSHA) has specified the following permissible noise level exposures: DURATION PER DAY (HOURS) 8 6 4 3 2 1... -
Page 3: Importantes Instructions De Securite
FRENCH Danger L‘exposition a des niveaux eleves de bruit peut provoquer une perte permanente de l’audition, Chaque organisme humain reagit differemment quant a la perte de l’audition, mais quasiment tout le monde subit une diminution de I’acuite auditive lors d’une exposition suffisamment longue au bruit intense. - Page 4 CONNECT TO CONNECT TO SIX SOURCE EIGHT ZONE AUDIO DISTRIBUTION SYSTEM NV-I8EZP1 NV-I8X 120V 60Hz 500W FUSE:T5 A USE NV-NC1 USE NV-SLC1 NuVo Technologies Cincinnati Ohio USA www.nuvotechnologies.com CABLE CABLE CONFORMS TO SUM2 EXT. MUTE UL STD.6500 CERTIFIED TO SYSTEM NETWORK DIGITAL LINK CAN/CSA STD.E60065...
-
Page 5: Front Panel Features
6. RS232: This DB9 port is used for bidirectional communication with third party home automation systems. The necessary communication protocol is available on the NuVo website Prozone. 7. AC Power: A standard IEC 2-wire power cable is used to connect the M3 to an available AC power source. - Page 6 I. Installing the M3 Server Audio Connections The M3 has three independent analog audio outputs. Although all the available music files are stored on a single 160 gig hard drive, each of the audio outputs is treated as a separate audio source. The connection to the audio output is made with a standard stereo RCA cable, fig.
- Page 7 II. Making the NuVoNet Connection Communication with Grand Concerto's NuVoNet is done with a single CAT5 cable. A 10' pre-terminated Network cable is included with the package. Note that this cable is terminated using standard 568A network wiring and can be a long cable if necessary for the installation.
- Page 8 IV. Getting Acquainted with Windows Media Player Media Player is the resident music archiving and cataloging software with Microsoft's XP operating system. It is important to know that Media Player 11 was developed for the new Vista operating system. When a CD is inserted into the CD tray of a computer running XP, it will automatically prompt you to rip the files to Media Player.
- Page 9 V. Syncing Music Files with the M3 Server Any music files stored in Media Player, whether ripped from a CD or downloaded from an online music store, can be synced and enjoyed through the M3. The sync process is accomplished with a single USB cable connection. By design when the USB connection is made from the M3 to a computer using the Microsoft XP operating system, the computer will recognize the M3 and prompt you to sync, fig.
- Page 10 Fig. 13 Fig. 14 Fig. 15...
-
Page 11: Specifications
NOTE - IR capability not implemented in versions prior to 1.10 Front panel, center Wired IR input via 3.5 mm 2-circuit jack,- 3 V peak to 12V peak, 38 KHz modulated pulse pattern NuVo pulse definitions, NEC format IR Pass-through parallelled with wired IR input 160 Gigabyte Full-scale digital output = 1.12 Vrms (4.5 V peak - to - peak) - Page 12 NuVo Technologies LLC 2395 Arbor Tech Dr. Hebron, Kentucky USA 859-817-7200 www.nuvotechnologies.com M3 0705...
