Page 1: Table Of Contents
DIGI-SHOCK Digital Impact and Temperature Recorder USER MANUAL for Digi Shock Models G, GT and XT Package Contents Loading the Software Setting up a New Mission Digi-Shock During the Mission Retrieving Mission Data from a File or the Digi-Shock Replacing the Battery and Helpful Information Technical and Sales Support Contact Information DIGI-SHOCK | USER MANUAL...
Page 2: Package Contents
Package Contents Please be sure the following contents are in this package: 1. Digi-Shock Device 2. USB Cable 3. Lithium Primary Battery - C Cell (Installed in Digi-Shock device) 4. USB Flash Drive: Contains the software and PDF of the manual 5.
Page 3: Loading The Software
Loading the Mission Control Software 1. Connect the supplied USB to your desk-top or laptop computer 2. Select and run the “Setup.exe” file Mission Control Program for Windows 7 and 10. 3. For Windows 8 users, use the “Save as” command and copy the file to the desktop then run the set-up file to install.
Page 4 Loading the Mission Control Software, cont. Click “Next” to continue the installation. We recommend leaving the installation location set to the default folder. Click “Next” to continue the installation. DIGI-SHOCK | USER MANUAL...
Page 5 Loading the Mission Control Software, cont. Click “Install” to install the application. Click “Finish” to complete the installation and run the application. DIGI-SHOCK | USER MANUAL...
Page 6: Setting Up A New Mission
Setting Up A New Mission Connect the Digi-Shock device to the PC via the supplied USB cable. The application will highlight the “Program Device” tab in the window when the drive is available to the PC. Click on this tab to begin Mission Setup. From the Mission Summary screen below, click on the “Program a Mission”...
Page 7 Setting Up A New Mission, cont. The “Set up Mission” window provides the parameters that can be set for each mission. 1. Start and End Date and Time* of the mission can be set. Typical battery life of the Digi-Shock months, so the start and end times should not exceed this when using a fresh battery.
Page 8 Setting Up A New Mission, cont. When the parameters have been successfully saved to the Digi-Shock, the following window will appear. Click “OK” and unplug the device from the USB cable. Attach the Digi-Shock to your shipment. After programming a mission the device will perform a self check and calibration. This will be evident by about 35 seconds of continuous LED blinking.
Page 9: Digi-Shock During The Mission
During the Mission For the first 30 minutes of a mission, the device will add a log entry every minute as an indication that the device is running. After this time frame, the Digi-Shock will add a log entry every 8 hours to indicate the device is running properly in the event there are no actual events to record.
Page 10: Retrieving Mission Data From A File Or The Digi-Shock
Retrieving Mission Data From a File or Digi-Shock If you do not have a Digi-Shock device connected via the USB port you will see the following window. You can see that the only option currently is to load a data file stored on the PC or sent to you via email.
Page 11 Retrieving Mission Data, cont. Should you choose to retrieve data from a connected device, click on the “Program Device” box in the window. You will receive the following response on the screen. Click “OK” to continue. You will then be presented with the following screen as shown below. Mission Summary: The Mission Summary tab shows the start and end date of the mission, the maximum and minimum temperature, and the largest impacts detected on each axis.
Page 12 Retrieving Mission Data, cont. If you prefer the temperature to be displayed in Celsius, click on the “Switch to Metric Units” icon in the upper right corner. Should further examination of the mission be necessary, click the “Graphs” tab to see the graph of the entire mission.
Page 13 Retrieving Mission Data, cont. Graphs: The Graphs tab can show two different sets of data at one time or you can view each set of data individually. The graph will default to the temperature displayed in red and the “X” axis data displayed in blue as shown below.
Page 14 Retrieving Mission Data, cont. To change the displayed data, click the button you want displayed. For instance, when you click the “Y Impact”, the data for the “Y Impact” is shown instead of the “Z Impact”. DIGI-SHOCK | USER MANUAL...
Page 15 Retrieving Mission Data, cont. To narrow down a more specific time of a single impact, click the “Zoom” icon for instructions on how to zoom in on an event. To zoom in on an event, click just to the left of the event(s) you would like to see and drag the mouse to the right until the purple overlay covers everything you would like to see.
Page 16 Retrieving Mission Data, cont. Should further review be desired, the actual recorded data can be accessed from the Recorded Data tab. Clicking on this tab will result in the following: The data is displayed in a spreadsheet format showing the exact date and time of each impact, Impact vector, impact duration and temperature reading stored by the Digi-Shock.
Page 17: Replacing The Battery And Helpful Information
Replacing the Battery and Other Useful Information Battery Replacement: Battery replacement can be done in the field, but preferably will be done between missions while the device is connected to the PC. A super capacitor installed on the Printed Circuit Board (PCB) will provide power to the circuitry during field battery replacement.
Page 18 Other Useful Information, cont. Device Storage: When the device is not in use, it is good practice to keep the Digi-Shock power up via the USB port during storage. This will save the installed battery and keep the super capacitor charged. Mission Control Updates: For your convenience, the latest Mission Control software version is available for download at no cost on our website under the Support Section.
Page 19: Technical And Sales Support Contact Information
Technical and Sales Support Contact Information Technical Support: Phone: 818-350-5070 Fax: 818-350-5090 Email: support@iogproducts.com Website: www.impactograph.com/support/ Sales Support: Phone: 610-251-6963 Email: sales@iogproducts.com Corporate Office / Manufacturing: IOG Products 9735 Lurline Avenue Chatsworth, CA 91311 DIGI-SHOCK | USER MANUAL...

This manual is also suitable for:

Digi-shock gt Digi-shock xt
