Summary of Contents for STRAPBINDER POW'R-WRAP TOOL HBPW8201
- Page 1 STRAPB POW'R-WRAP TOOL Contents 2 Technical Data 3 Safety Instructions 5 Operation Instructions 6 Adjustment & Maintenance 7 Schematic & Parts List MANUFACTURER PART NUMBER RSA-590...
- Page 2 TECHNICAL DATA Length 7.89” Width 0.99” Height 6.38” Weight 1.17 lbs Strapping Dimensions Width ¼” Thickness .015” Material Smooth stainless-steel...
- Page 3 SAFETY INSTRUCTIONS Read and follow operation instructions carefully. Failure to follow these warning can result in severe personal injury. eye injury hazard When handling RSA-590 and stainless-steel strap, always wear protective glasses. Failure to wear safety glasses with side shields can result in severe eye injury or blindness. Always wear safety glasses with side shields that conform to ANSI Standard Z87.1.1 protective gloves When handling RSA-590 and stainless-steel strap, always wear protective gloves.
- Page 4 cutting tensioned strap When cutting strapping, use the proper strapping cutter and keep other bystanders and yourself at a safe distance from the strap. Always stand to side of strap, away from the direction in which the loosened strap will release. tool hazard A well maintained and inspected tool can optimize safety! Check tool daily for broken or warn parts.
- Page 5 OPERATION INSTRUCTIONS RSA-590 works with ¼ smooth stainless steel strapping. 1. Preset desired tension (0-8) by turning the knob at the rear of the tool – the higher the number, the tighter the tension capacity. 0 = 15 lbs 1 = 20 lbs 2 = 30 lbs 3 = 40 lbs 4 = 50 lbs...
- Page 6 ADJUSTMENTS & MAINTENANCE tension adjustment Preset desired tension (0-8) by turning the knob at the rear of the tool – the higher the number, the tighter the tension capacity. 0 = 15 lbs 1 = 20 lbs 2 = 30 lbs 3 = 40 lbs 4 = 50 lbs 5 = 60 lbs...
- Page 7 SCHEMATIC & PARTS LIST...
