COMPONENT IDENTIFICATION
■FRONT VIEW
RUN LED
ERR LED
■ STATUS INDICATOR LED
RUN indicator: Bi-color (red/green) LED;
Red when the bus A operates normally;
Green when the bus B operates normally;
Amber when both buses operate normally.
ERR indicator: Bi-color (red/green) LED;
Red with the input circuit abnormality (AD
converter response failure);
Green in normal operating conditions.
■ SIDE DIP SW
• Input Range: SW1, SW2 (selectable per 4 channels)
INPUT 1 through INPUT 4 (SW1)
INPUT 5 through INPUT 8 (SW2)
1 2
OFF OFF
ON OFF
ON ON
OFF OFF
ON OFF
• Conversion Rate: SW3
CONVERSION RATE
SW
100 ms (*) 50 ms
SW3-1 OFF
SW3-2 OFF OFF
(*)Factory setting
■SIDE VIEW
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
3 4
OFF OFF
OFF OFF
OFF OFF
ON OFF
ON OFF
20 ms 10 ms
ON OFF ON
ON ON
SW3
4
3
2
1
ON
RANGE
-10 – +10V (*)
-5 – +5V
0 – 10V
0 – 5V
1 – 5V
R3-SV8N
Functions
SW2 SW1
8 8
7 7
6 6
Conv.
Rate 5 5 Range
4 4
Input 1-4 (SW1)
3 3
or
2 2
Input 5-8 (SW2)
1 1
ON ON
