85MIR / 85MIR-L
Chapter 1 Specification ............................................. 9
1-2 Mainboard Specifications ..................................................... 11
1-2.1 CPU Socket ................................................................................... 11
1-2.2 System Chipsets ........................................................................... 11
1-2.3 Memory ......................................................................................... 11
1-2.4 AMI BIOS ..................................................................................... 11
1-2.6 VGA on board .............................................................................. 12
1-2.7 Advanced System Power Management: ................................... 12
1-2.8 Multi-I/O Functions : .................................................................. 12
1-2.9 Expansion Slots ............................................................................ 13
1-2.11 Hardware Monitor on board ................................................... 13
1-2.12 AC'97 Audio Codec on board ................................................. 13
1-2.13 6-channel Audio-out Support (optional) ............................... 13
1-2.14 Form Factor ................................................................................ 13
1-3 Mainboard Specification Table ........................................... 14
1-4 Chipset System Block Diagram ........................................... 15
Chapter 2 Hardware Setup ..................................... 16
2-1 Pentium 4 CPU and Installation ......................................... 17
2-1.1 To Identify a Pentium 4 CPU ..................................................... 17
2-2 Pentium 4 CPU Fan Installation ......................................... 19
2-3 Memory Installation ............................................................. 20
2-3.2 To Remove a DIMM .................................................................... 21
Contents
4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 85MIR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOLTEK 85MIR

Summary of Contents for SOLTEK 85MIR

  • Page 1: Table Of Contents

    1-2.7 Advanced System Power Management: ........12 1-2.8 Multi-I/O Functions : ..............12 1-2.9 Expansion Slots ................13 1-2.10 LAN (Local Area Network) on board (85MIR-L only) ..13 1-2.11 Hardware Monitor on board ........... 13 1-2.12 AC’97 Audio Codec on board ..........13 1-2.13 6-channel Audio-out Support (optional) .......
  • Page 2 2-9.2 Connector AUX1 ................32 2-9.3 CD-ROM Audio Connectors (CD 1) ......... 32 2-9.4 Chassis Panel Connectors ............33 2-9.5 LAN Connector RJ45 (85MIR-L only) ........33 2-9.6 Thermal Sensor Connectors RT2 and Jp11 ......34 2-9.7 Complex Header ................35 2-9.8 USB Ports and USB Headers .............
  • Page 3 3-7 Install Hardware Monitor Utility ........50 3-7.1 Installation ................... 50 3-7.2 Verification .................. 51 3-8 Install LAN Drivers (for 85MIR-L only) ......52 3-8-1. RTL8139C LAN driver on Windows 9X ........ 52 3-8-2. RTL8139C LAN driver on Windows NT4.0 ......54 3-8-3.
  • Page 4 Contents 4-6.7 Integrated Peripherals ..............77 4-6.8 Hardware Monitor Status ............80 4-6.9 Frequency/Voltage Control ............82 4-6.10 Set Supervisor Password ............84 4-6.11 Load Optimized Defaults ............86 4-6.12 Save & Exit Setup ..............86 4-6.13 Exit Without Saving ..............86 APPENDICES ............
  • Page 5 85MIR / 85MIR-L ITEM CHECKUP Mainboard Support CD Bundled Bonus Pack CD Bundled Bonus Pack Manual Thermal Sensor Cable (optional) ATA 33/66/100 IDE Cable FDD Cable User’s Manual RS232 Cable (optional) USB Cable (optional)

  • Page 6: Chapter 1 Specification

    Chapter 1 Specification Chapter 1 Specification Introduction This mainboard features an integration of the powerful processor In- tel Pentium 4 and the single-chip North Bridge Intel 845G. The Intel P4 processor is a rapid execution engine providing 533/400MHz system bus, while North Bridge Intel 845G is a high performance integrated chipset providing processor interface, DDR266/200 SDRAM memory interface, Hub interface, AGP interface as well as an integrated Graph- ics device with CRT display port.

  • Page 7: 85Mir / 85Mir-L Components Locations

    85MIR / 85MIR-L 1-1 SL-85MIR / 85MIR-L Components Locations LAN Controller for Mainboard 85MIR-L only RJ45 connector PS/2 Mouse FAN1 (on top) PS/2 K/B (underside) RJ 45 (on top) USB0 (middle) USB1 (underside) LED1 +12V Power Intel Intel RG82845 i845G...

  • Page 8: Mainboard Specifications

    Chapter 1 Specification 1-2 Mainboard Specifications 1-2.1 CPU Socket CPU Socket 478 on board, supporting Intel ® Pentium 4 processors in 478-pin package for : -- 533/400MHz System Bus; -- Hyper-pipelined technology; -- Advanced dynamic execution; -- Advanced transfer cache; 1-2.2 System Chipsets North Bridge Intel 845G plus South Bridge Intel ICH4 working with Intel Pentium 4 Processor for managing and arbitrating operations between...

  • Page 9: 1-2.6 Vga On Board

    85MIR / 85MIR-L 1-2.6 VGA on board • Built-in VGA Graphics Controller in i845G, supporting one 15-pin con- nector on board for CRT 2D, 3D VGA display • VGA display to be safeguarded by jumper setting (see Jumper Setting section for VGA select) •...

  • Page 10: 1-2.9 Expansion Slots

    • 3 PCI bus Master slots • 1 AGP 4X slot • 2 DDR DIMM slots 1-2.10 LAN (Local Area Network) on board (85MIR-L only) PCI local bus single-chip Fast Ethernet Controller RTL8139C on board: • Supporting 10/100Mb data transfer •...

  • Page 11: Mainboard Specification Table

    85MIR / 85MIR-L 1-3 Mainboard Specification Table SL-85MIR / 85MIR-L Specifications and Features Socket 478B for Intel Pentium 4 CPUs North Bridge Intel 845G, supporting 533/400MHz System Bus South Bridge Intel ICH4 BIOS AMI BIOS Memory Supporting DDR 266/200 SDRM, up to 2GB...

  • Page 12: Chipset System Block Diagram

    Chapter 2 Hardware Setup 1-4 Chipset System Block Diagram Intel Pentium 4 CPU System Bus 533/400MHz Monitor DDR Memory Interface System AGP 4X Intel 845G AGP Slot Memory DDR 266/ North Bridge 200 SDRAM Bi-directional 16-bit Data Bus, 266MHz 3 PCI Slots PCI Bus ICH4 ATA 100/66/33...

  • Page 13: Chapter 2 Hardware Setup

    85MIR / 85MIR-L Chapter 2 Hardware Setup To Get things ready for hardware setup ! 1. We recommend to install your CPU before any other components. For detailed installation instructions of processor, you can also refer to the pamphlet enclosed in your CPU package.

  • Page 14: Pentium 4 Cpu And Installation

    Chapter 2 Hardware Setup 2-1 Pentium 4 CPU and Installation 2-1.1 To Identify a Pentium 4 CPU Intel pentium 4 2.4 GHz / 512 / 533 / 1.5V 4) CPU Voltage Vcore 3) System Clock 2) CPU L2 Cache 1) CPU Working Frequency On the heatsink side of a Pentium 4 CPU, there printed a line of figures to identify its specifications.

  • Page 15: 2-1.2 Pentium 4 Cpu Installation With Socket 478

    85MIR / 85MIR-L 2-1.2 Pentium 4 CPU Installation with Socket 478 This mainboard is built with CPU Socket 478 (with 478 pins) supporting the Intel Pentium 4 CPU: • Follow the steps described in this section to install the 478-pin Pentium CPU into the on board Socket 478.

  • Page 16: Pentium 4 Cpu Fan Installation

    Chapter 2 Hardware Setup 2-2 Pentium 4 CPU Fan Installation CPU Fan Connector Pentium 4 Fanbase Press down 4 corners to lock fan to fanbase Connect Fan Connector to CPU FAN connector...

  • Page 17: Memory Installation

    85MIR / 85MIR-L 2-3 Memory Installation How to tackle the memory Modules: • Make sure to unplug your power supply before adding or removing memory module. Failure to do so may cause severe damage to both your mainboard and the memory module.

  • Page 18: 2-3.2 To Remove A Dimm

    Chapter 2 Hardware Setup 2-3.2 To Remove a DIMM To remove a DIMM Module, first power off system and then press down the holding latches on both sides of slot to release the module from the DIMM slot. PS/2 Mouse (on top) FAN1 PS/2 K/B (underside)

  • Page 19: Install Vga / Agp4X With Led1 & Jp4 Safeguard

    85MIR / 85MIR-L 2-4 Install VGA / AGP4X with LED1 & Jp4 Safeguard 1. To install on-board VGA, please connect your monitor directly to VGA connector on board. Default Jp4 (2-3 closed) is designed to assure booting system with 1.5V on-board VGA or 1.5V AGP4X add-on card.

  • Page 20: Ide Connector Installation

    Chapter 2 Hardware Setup 2-5 IDE Connector Installation To install IDE Connector, you may connect the blue connector of IDE cable to the primary (IDE1) or secondary (IDE2) connector on board, and then connect the gray connector to your slave device and the black connector to your master device.

  • Page 21: Floppy Drive Connector ( Fdc ) Installation

    85MIR / 85MIR-L 2-6 Floppy Drive Connector ( FDC ) Installation To install FDC, you should connect the end of FDC cable with single connector to the board , and connect the other end with two connectors to the floppy drives.

  • Page 22: Atx V 2.03 Power Supply Installation

    Chapter 2 Hardware Setup 2-7 ATX V 2.03 Power Supply Installation +12V Power Connector -12V PWR OK PS ON# PS/2 Mouse (on top) FAN1 PS/2 K/B (underside) +3.3V -12V RJ 45 (on top) USB0 (middle) +3.3V +3.3V USB1 (underside) Pin1 Pin11 LED1 Main Power Connector...

  • Page 23: Jumper Settings

    85MIR / 85MIR-L 2-8 Jumper Settings The following diagrams show the locations and settings of jumper blocks on the mainboard. Keyboard / Mouse / Power Jp4: VGA/AGP4X Safeguard Jp3: Button Select 1-2 closed for 1.5V AGP 4X only; (Warning: 3.3V AGP 2X 1-2 closed (default) card will not boot system.)

  • Page 24: 2-8.1 How To Tackle The Jumpers

    Chapter 2 Hardware Setup 2-8.1 How to tackle the Jumpers: A 2-pin Jumper A 3-pin Jumper If a pin-header (of 2 or more pins) is designed in such a way that its pins can be closed or linked together to The conductor inside the cap set up a specific function, this header links two header-pins together.

  • Page 25: 2-8.3 Jp8: Cpu Clock/Overclock Select

    85MIR / 85MIR-L 2-8.3 Jp8: CPU Clock/Overclock Select Jp8 is designed on board as a jumper for CPU clock select and 100MHz to 133MHz CPU overclocking. With Jp8, user can choose the way for a 100MHz CPU to run an overclock on board.

  • Page 26: 2-8.4 Jagp1 & Jagp2: Agp Voltage Select

    Chapter 2 Hardware Setup 2-8.4 JAGP1 & JAGP2: AGP Voltage Select The default voltage 1.5V at AGP slot is for normal operation of the supported JAGP1 & JAGP2 AGP Voltage Select AGP 4X. In some case, when you try to do CPU overclocking, you then may Jumper Setting also need to raise the transfer rate of...

  • Page 27: 2-8.7 Jp4: Vga/Agp4X Safeguard

    85MIR / 85MIR-L 2-8.6 Jp3: Keyboard / Mouse / Power Button Select Jp3 is designed to select keyboard or the Power button as the power- on controller. Setting Jp3 to 1-2 closed will allow user to power on sys- tem by power button. Setting Jp3 to 2-3 closed will allow user to power up system by keyboard.

  • Page 28: Other Connectors Configuration

    Chapter 2 Hardware Setup 2-9 Other Connectors Configuration This section lists out all connectors configurations for users’ reference. 2-9.1 On-board FAN Connectors Void +12V PS/2 Mouse (on top) FAN1 +12V PS/2 K/B (underside) RJ 45 (on top) SENSOR USB0 (middle) USB1 (underside) Sensor Conn.

  • Page 29: 2-9.2 Connector Aux1

    85MIR / 85MIR-L 2-9.2 Connector AUX1 This connector connects to the Video Tuner Card and acts as Audio Input connector. PS/2 Mouse (on top) FAN1 PS/2 K/B (underside) RJ 45 (on top) USB0 (middle) USB1 (underside) Connector AUX 1 LED1...

  • Page 30: 2-9.4 Chassis Panel Connectors

    Chapter 2 Hardware Setup 2-9.4 Chassis Panel Connectors A : PS/2 Mouse F : USB0 (middle) B : LAN Port RJ45 (85MIR-L G : COM1 only) H : VGA C : LPT1 Port : Line Out / Front Speaker Out...

  • Page 31: 2-9.6 Thermal Sensor Connectors Rt2 And Jp11

    85MIR / 85MIR-L 2-9.6 Thermal Sensor Connectors RT2 and Jp11 PS/2 Mouse (on top) FAN1 PS/2 K/B (underside) RT2 is mounted RJ 45 (on top) USB0 (middle) with Thermal Resistor USB1 (underside) by default. LED1 +12V Power Jp11 Intel Intel RG82845...

  • Page 32: 2-9.7 Complex Header

    Chapter 2 Hardware Setup 2-9.7 Complex Header This complex Header consists of the following connectors for various supports: PS/2 Mouse FAN1 (on top) PS/2 K/B (underside) RJ 45 (on top) USB0 (middle) USB1 (underside) LED1 +12V Power Intel Intel RG82845 i845G Peripheral Power AGP 4X...
  • Page 33 85MIR / 85MIR-L (1) SMI Connector (Optional): Connection: Connected to the case-mounted Suspend Switch. Function: Manually selecting DOS system into the Suspend Mode or “Green Mode” by System mangement interrupt. (2) Power Switch Connector: Connection: Connected to a momentary button or switch.

  • Page 34: 2-9.8 Usb Ports And Usb Headers

    Chapter 2 Hardware Setup 2-9.8 USB Ports and USB Headers This mainboard provides two USB ports USB0 and USB1 on board supporting various USB devices. In addition, two USB headers are added on board to provide expansion of four more optional USB ports by us- ing two additional USB Cables.

  • Page 35: 2-9.9 Connector Cn14: Wake On Lan

    85MIR / 85MIR-L 2-9.9 Connector CN14: Wake On LAN 1. This connector connects to a LAN card with a Ring signal output. The connector powers up the system when it receives a wake-up packet or signal through the LAN card.

  • Page 36: 2-9.11 Pin-Header Dcom1: For One External Serial Port

    Chapter 2 Hardware Setup 2-9.11 Pin-header DCOM1: for one external serial port PS/2 Mouse (on top) FAN1 DCOM1 Header is built on board , PS/2 K/B (underside) RJ 45 (on top) which requires a serial COM2 cable USB0 (middle) USB1 (underside) to provide a 9-pin serial connector LED1 for a serial device connection.

  • Page 37: Irq Description

    85MIR / 85MIR-L 2-10 IRQ Description Function Description Priority IRQ 0 System Timer IRQ 1 Keyboard Controller IRQ 2 Programmable Interrupt IRQ 3 Serial Port (COM 2) IRQ 4 Serial Port (COM 1) IRQ 5 Free IRQ 6 Floppy Disk Controller...

  • Page 38: Chapter 3 Software Setup

    3-2 Intel Chipset Software Installation Utility ( INF Utility ) 3-3 Intel Application Accelerator ( IAA ) 3-4 DirectX 3-5 Graphics Drivers 3-6 AC’97 Audio Drivers 3-7 Hardware Monitor Utility 3-8 LAN Drivers (for 85MIR-L only) 3-9 Intel USB2.0 Drivers...

  • Page 39: Open Up The Support Cd

    Chapter 3 Software Setup 3-1 Open up the Support CD 1. Please put the Support CD enclosed in your mainboard package into the CD-ROM drive. In a few seconds, the Main Menu will automatic- ally appear, displaying the contents to be installed for this series: 2.

  • Page 40: Install "Intel Chipset Software Installation Utility

    85MIR / 85MIR-L 3-2 Install “Intel Chipset Software Installation Utility” 1. Following the procedures of opening the Support CD, click to “ Install Intel Chipset software installation Utility” to proceed. 2 . T h e I n t e l S e r v i c e P a c k...

  • Page 41: Install "Intel Application Accelerator

    Chapter 3 Software Setup 3-3 Install “Intel Application Accelerator” IAA supports all Windows 98/98se/Me/NT4/2000/XP with Pentium III / 4 processor. Installations of this software for these operating systems are similarly programed to an auto-run mode. Iit is typically designed to improve performance of the storage sub-system and overall system performance.
  • Page 42 85MIR / 85MIR-L 4. On ”Choose Destination Location” screen, press “Yes” to continue. C:\Program Files\Intel\Intel Application Accelerator 5. On ”InstallShield Wizard Com- plete” screen, choose “Yes, I want to restart my computer now” Yes, I want to restart my computer now and press “finish”...

  • Page 43: Directx Installation

    Chapter 3 Software Setup 3-4 DirectX Installation Following the installation of IAA, you have to restart system so that your system can be reconfigured with the driver just installed. When restarting procedures finish, please open the Support CD with your CD- ROM to enter the Main Installation Menu.

  • Page 44: Graphics Driver Installation

    85MIR / 85MIR-L 3-5 Graphics Driver Installation Following the installation of DirectX, you have to restart system so that your system can be reconfigured with the utility. When restarting pro- cedures finish, please open the Support CD with your CD-ROM to en- ter the Main Installation Menu.

  • Page 45: Ac'97 Audio Driver Installation

    Chapter 3 Software Setup 3-6 AC’97 Audio Driver Installation Avance AC97 Audio Codec on board, AC’97 2.2 compatible stereo audio code for PC multimedia systems. Avance AC’97 Audio Codec Driver is pro- vided in Support CD for user’s installation. 1. Following the procedures of opening the Support CD, click to “ AC’97 Audio Driver”...

  • Page 46: Install Hardware Monitor Utility

    85MIR / 85MIR-L 3-7 Install Hardware Monitor Utility 3-7.1 Installation Hardware Monitor is built in chip IT8712F of this series. Its in- stallation is programed to a fully automated mode on Windows 9X/ Me/NT4/2000/XP. User can follow the model installation below for its installation on various Windows System.

  • Page 47: 3-7.2 Verification

    Chapter 3 Software Setup 3-7.2 Verification 1. After restarting your computer, click “Start” and choose the path \ P r o g r a m s \ I T E S m a r t Accessories\ITE Smart Guardian to open the main window of the Hardware Doctor.

  • Page 48: Install Lan Drivers (For 85Mir-L Only)

    85MIR / 85MIR-L 3-8 Install LAN Drivers (for 85MIR-L only) 3-8-1. RTL8139C LAN driver on Windows 9X The LAN driver contained in the Support CD is not included in the Autorun Menu. To install RTL8139C LAN driver on Windows 9X, please follow the steps shown below: 1.
  • Page 49 Chapter 3 Software Setup 5. In the “Update device Driver Wizard” screen, click “Next” to continue until you see a dialog box asking you to “Specify a location” for the driver. You should now insert the Support CD into your CD-ROM. 6.

  • Page 50: Rtl8139C Lan Driver On Windows Nt4.0

    85MIR / 85MIR-L 3-8-2. RTL8139C LAN driver on Windows NT4.0 1. When you newly install Win NT4, the Setup program will ask you whether your computer will participate on a network. please check “Do not connect this computer to a network at this time” and continue with your installation.

  • Page 51: Rtl8139C Lan Driver On Win Me / 2000 / Xp

    Chapter 3 Software Setup 10. To verify that the onboard RTL8139C Controller has been set up in system, please click “Start”, then “Control Panel”, then “Network”. 11. In the “Network” screen, click the “Adapter” bar. You can now see the “Realtek RTL8139(A/B/C/8130) PCI Fast Ethernet Adapter is already installed in system.

  • Page 52: Install Usb 2.0 Driver For Win2000 Or Winxp

    85MIR / 85MIR-L 3-9 Install USB 2.0 Driver for Win2000 or WinXP USB V2.0 with its 480Mb/s transfer rate supports operating system Win2000 and WinXP with Intel USB drivers and Microsoft USB drivers. USB Driver installation procedures are of similar steps in Win2000 and WinXP.
  • Page 53 Chapter 3 Software Setup 6. When a dialog box pops out, asking user to key in the correct path for Intel_USB2.0 driver, please type the following path and mouse click “OK” button to install the Intel_USB 2.0 driver: For both Win2000 and Win XP: d:\driver\usb20\Intel_USB20 (supposing the CD-ROM Drive holding the Support CD is Drive D) 7.

  • Page 54: Chapter 4 Ami Bios Setup

    85MIR / 85MIR-L Chapter 4 AMI BIOS Setup THE BIOS BIOS stands for Basic Input and Output System. It was once called ROM BIOS when it was stored in a Read-Only Memory (ROM) chip Now manufacturers would like to store BIOS in EEPROM which means Electrically Erasable Programmable Memory.

  • Page 55: About Bios Setup

    Chapter 4 BIOS Setup 4-1 About BIOS Setup BIOS setup is an interactive BIOS program that you need to run when: 1. Changing the hardware of your system. (For example: installing a new Hard Disk etc.) 2. Modifying the behavior of your computer. (For example: changing the system time or date, or turning special features on or off etc.) 3.

  • Page 56: To Update Bios

    85MIR / 85MIR-L 4-5 To Update BIOS • System BIOS is incorporated into a Flash memory component. Flash BIOS allows user to upgrade BIOS without the need to replace an EPROM component. • The Update Utility can be loaded on a floppy diskette for upgrading saving, and verifying the system BIOS.
  • Page 57 Chapter 4 BIOS Setup Step 4. Type AMIFLASH *.ROM and then press <Enter> to run BIOS update program. (*.ROM will vary, depending on your mainboard model and version code. Instead of typing “*”, you should type specific file name for your specific mainboard. For example: AMIFLASH(space) 85MIR11.ROM)..

  • Page 58: Bios Setup

    85MIR / 85MIR-L 4-6 BIOS SETUP --- CMOS Setup Utility 4-6.1 CMOS Setup Utility This mainboard comes with the AMI BIOS from American Megatrends Inc. Enter the CMOS Setup Utility Main Menu by: 1. Turn on or reboot your system. After a series of diagnostic checks, the following message will appear: PRESS <Del>...

  • Page 59: 4-6.2 Standard Cmos Setup

    Chapter 4 BIOS Setup 4-6.2 Standard CMOS Setup Standard CMOS Setup records some basic system hardware configuration and sets the system clock and error handling. Modify the configuration values of this option if you want to change your system hardware configuration or after you clear CMOS data. Run the Standard CMOS Setup as follows: 1.
  • Page 60 85MIR / 85MIR-L System Time The BIOS shows the time of the day in the format: hh:mm:ss. Choose the field with the Arrow keys and change the time with the Page Up/Page Down +/- keys. System Date The BIOS shows the date of the day in the format: mm:dd:yy :day of the Week.
  • Page 61 Chapter 4 BIOS Setup Type This option shows the types of configuration for the IDE devices: 1-50: Predefined types USER: set Parameters by User Auto: Set parameters automatically CD-ROM: Use for ATAPI CD-ROM drives Double click [Auto] to set all HDD parameters automatically, including “Cylinders, Heads, Write Precompensation, Sectors, Maximum Capacity and 32 Bit Transfer Mode.

  • Page 62: 4-6.3 Advanced Bios Features

    85MIR / 85MIR-L 4-6.3 Advanced BIOS Features Advanced BIOS Features improves your system performance or sets up system features according to your preference. Run the Advanced BIOS Features as follows: 1. Choose “Advanced BIOS Features” from the Main Menu and a screen with a list of options will appear: AMIBIOS NEW SETUP UTILITY - VERSION 3.31a...
  • Page 63 Choises: Yes; No Initial Display Mode If option is “Silent”, the initial display mode will be set to one with Soltek logo. If option is “BIOS”, the normal BIOS display mode will be shown. Choices: silent (default); BIOS If the item “Initial Display Mode”...
  • Page 64 85MIR / 85MIR-L Bootup Num-lock Allows you to toggle between On or Off to control the state of the NumLock keys when the system boots. If On, the numeric keypad is in numeric mode. If off, the numeric keypad is in cursor con- trol mode.

  • Page 65: 4-6.4 Advanced Chipset Features

    Chapter 4 BIOS Setup 4-6.4 Advanced Chipset Features Advanced Chipset Features is used to modify the values of chipset buffers. These buffers control the system options. Run the Advanced Chipset Features as follows: 1. Choose “Advanced Chipset Features” from the Main Menu and a list of option will appear: AMIBIOS NEW SETUP UTILITY - VERSION 3.31a Advanced Chipset Features...
  • Page 66 85MIR / 85MIR-L SDRAM Frequency Allows you to set the SDRAM frequency. Choices: Auto; 200MHz; 266MHz Configure SDRAM SPD (Serial presence detect) is a device in memory Timing by SPD module for storing the module information such as DRAM timing and chip parameters. If this option is enabled, BIOS will access SPD automatically to configure module timing.
  • Page 67 Chapter 4 BIOS Setup Internal Graphic Mode Allows you to set the internal graphic mode. Select Choices: 512KB; 1MB; 8MB; Disabled AGP Aperture Size Allows you to set the AGP Aperture Size. Choices: 4MB; 8MB; 16MB; 32MB; 64MB; 128MB; 256MB; USB Controller Allows you to set the USB Controller on the USB port(s).

  • Page 68: 4-6.5 Power Management Features

    85MIR / 85MIR-L 4-6.5 Power Management Features Power Management Features allows you to set the system’s power saving functions. Run the Power Management Features as follows: 1. Choose “Power Management Features” from the Main Menu and a list of options will appear: AMIBIOS NEW SETUP UTILITY - VERSION 3.31a...
  • Page 69 Chapter 4 BIOS Setup ACPI Standby State This item supports S1 (POS) for Power on Suspend mode under Windows 98 and up. Allows you to enable / disable the Power manage- Power Management/ ment / Advanced Power Management function. Allows you to select the Video Power Down Mode. Video Power Down Choices: Disabled;...
  • Page 70 85MIR / 85MIR-L Resume On RTC Alarm Allows you to enable / disable the Resume On RTC Alarm function. RTC Alarm Date / Hour If resume On RTC Alarm is enabled, this field al- / Minute / Second lows you to set the Alarm date Hour, Minute and second.

  • Page 71: 4-6.6 Pnp / Pci Configurations

    Chapter 4 BIOS Setup 4-6.6 PNP / PCI Configurations PNP/PCI Configuration allows you to modify the system’s power saving functions. Run the PNP/PCI Configurations as follows: 1. Choose “PNP/PCI Configurations” from the Main Menu and a screen with a list of options will appear: AMIBIOS NEW SETUP UTILITY - VERSION 3.31a PNP/PCI Configurations Setup Help...
  • Page 72 85MIR / 85MIR-L Clear NVRAM Allows BIOS to clear the NVRAM data. Choices: No (default); Yes PCI Latency Timer (PCI Allows you to set the PCI Latency Time. Clocks) Choices: 32; 64; 96; 192; 128; 160; 192; 224; 248; Init. Graphics Adapter Allows you to select the initial Graphics Adapter.

  • Page 73: 4-6.7 Integrated Peripherals

    Chapter 4 BIOS Setup 4-6.7 Integrated Peripherals Integrated Peripherals option allows you to get some information inside your system when it is working. Run the Integrated Peripherals as follows: 1. Choose “Integrated Peripherals” from the Main Menu and a list of options will appear: AMIBIOS NEW SETUP UTILITY - VERSION 3.31a Integrated Peripherals...
  • Page 74 85MIR / 85MIR-L Onboard IDE Allows you to choose the Onboard IDE Mode. Choices: Disabled; Primary; Secondary; Both (Optional)Onboard If there is built-in LAN on board, this item allows you to enable / disable onboard LAN. Choices: Enabled; Disabled Onboard AC‘97 Audio Allows you to disable AC’ 97 Audio.
  • Page 75 Chapter 4 BIOS Setup OnBoard MIDI Port Allows you to configure onboard MIDI port address. The choices: Disabled; 300h; 330h MIDI Port IRQ If the onboard MIDI port is set at 300h or 330h, this item shows up to allow you to configure the MIDI Port IRQ to IRQ 5.

  • Page 76: 4-6.8 Hardware Monitor Status

    85MIR / 85MIR-L 4-6.8 Hardware Monitor Status This menu helps you to read only and get more information on the working CPU temperature, FAN speed and voltage. 1. Choose “Hardware Monitor Status” from the Main Menu and a screen with a list of current status of your working system will appear: AMIBIOS EASY SETUP UTILITY - VERSION 3.31a...
  • Page 77 Chapter 4 BIOS Setup Temperature 1 Shows current CPU internal temperature. Temperature 2 Shows current CPU external temperature. Temperature 3 Shows current system temperature. Fan 1 / 2 /3 Displays the current speed of CPU Fan, and other two onboard devices which user has connected to the onboard Fan Connectors.

  • Page 78: 4-6.9 Frequency/Voltage Control

    85MIR / 85MIR-L 4-6.9 Frequency/Voltage Control Run the “Frequency/Voltage Control” as following: 1. Choose “Frequency/Voltage Control” from the Main Menu and a screen with a list of options will appear: AMIBIOS EASY SETUP UTILITY - VERSION 2.01a Frequency/Voltage Control Setup Help RedStorm Overclocking Tech (Optional) (Press “Enter”)
  • Page 79 Chapter 4 BIOS Setup (Optional) Redstorm Press <Enter> to start RED STORM OVERCLOCK- Overclocking Tech ING TECH. This option gives user an easy way to overclocking. It will increase CPU external clock automatically. When CPU external clock increases to an unacceptable value, BIOS will restart your system, then running at an acceptable CPU exter- nal clock.

  • Page 80: 4-6.10 Set Supervisor Password

    85MIR / 85MIR-L 4-6.10 Set Supervisor Password This option allows you to set a Supervisor password for the system: 1. Choose “Set Supervisor Password” in the Main Menu and press <Enter>. Then the following message appears: [ Enter new supervisor password ] 2.
  • Page 81 Chapter 4 BIOS Setup 8. To change or remove a current supervisor password, choose “Set Supervisor Password” and press <Enter>. An instruction box appears on the screen, prompting you to enter the current password first: [ Enter current supervisor password ] 9.

  • Page 82: 4-6.11 Load Optimized Defaults

    85MIR / 85MIR-L 4-6.11 Load Optimized Defaults When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: [ Load Optimized Defaults ] Press [Enter] to continue or [ESC] to abort Press <Enter> now to load Optimal values for all the Setup options.
